Additional Keypad and Magnetic Lock Wiring
Back of Keypad camera
Additional Keypad and Yale-release Wiring
Back of Keypad camera
EMERGENCY
BREAK
GLASS
EGR
Ov
EXIT
BUTTON
*For a voltage-free contact: Keypad requires
and additional 12VDC relay (not supplied)
EGR
Ov
N.O
EXIT
BUTTON
*For a voltage-free contact: Keypad requires
and additional 12VDC relay (not supplied)
–
COM
N.C
Keypad PSU provided
COM
Yale Release
Keypad PSU provided
MAGLOCK
AC240
–
AC240
7
