Summary of Contents for Chroma 62000H Series

  • Page 1 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual...
  • Page 3 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Version 1.7 March 2015...

  • Page 4: Legal Notices

    The information in this document is subject to change without notice. Chroma ATE INC. makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 5 Chroma’s obligation under this warranty is limited solely to repairing any such instrument, which in Chroma’s sole opinion proves to be defective within the scope of the warranty when returned to the factory or to an authorized service center. Purchaser is responsible for the shipping and cost of the service item to Chroma factory or service center.
  • Page 6 Material Contents Declaration The recycling label shown on the product indicates the Hazardous Substances contained in the product as the table listed below. : See <Table 1>. : See <Table 2>. <Table 1> Hazardous Substances Lead Mercury Cadmium Hexavalent Polybrominated Polybromodiphenyl Part Name Chromium...
  • Page 7 “” indicates that the level of the specified chemical substance exceeds the threshold level specified in the standards of SJ/T-11363-2006 and EU 2005/618/EC. Chroma is not fully transitioned to lead-free solder assembly at this moment; however, most of the components used are RoHS compliant.

  • Page 9: Safety Summary

    Failure to comply with these precautions or specific WARNINGS given elsewhere in this manual will violate safety standards of design, manufacture, and intended use of the instrument. Chroma assumes no liability for the customer’s failure to comply with these requirements.

  • Page 10: Safety Symbols

    Safety Symbols DANGER – High voltage. Explanation: To avoid injury, death of personnel, or damage to the instrument, the operator must refer to the explanation in the instruction manual. High temperature: This symbol indicates the temperature is hazardous to human beings. Do not touch it to avoid any personal injury.

  • Page 11: Revision History

    Revision History The following lists the additions, deletions and modifications in this manual at each revision. Date Version Revised Sections May 2010 1.0 Complete this manual. Aug. 2010 1.1 Modify the following sections to add new model 62150H-1000S and I-V Curve Programming function: –...

  • Page 13: Table Of Contents

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Table of Contents Overview ......................1-1 Introduction ......................1-1 System Functions ....................1-1 1.2.1 Operation Mode ..................1-1 1.2.2 Protection ....................1-1 1.2.3 Output/Indication ..................1-2 1.2.4...
  • Page 14 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 3.3.3.5 Setting Parallel Parameters ..............3-32 3.3.3.6 Setting Procedure for APG in Series or Parallel ........3-34 3.3.4 DISPLAY ....................3-36 3.3.4.1 BRIGHTNESS ..................3-36 3.3.4.2 DISPLAY SELECTION ................
  • Page 15 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 4.1.1.4 Setting PROG CHAIN ................4-5 4.1.1.5 Setting CLEAR PROGRAM ..............4-8 4.1.2 Setting Sequence ..................4-9 4.1.2.1 Setting Sequence Number..............4-10 4.1.2.2 Setting Sequence Type ................. 4-10 4.1.2.3...
  • Page 16 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 5.3.5.5 Program Header Separator (:) ............... 5-20 5.3.5.6 Program Message ................. 5-20 5.3.5.7 Program Message Unit ................5-21 5.3.5.8 Program Message Unit Separator (;) ............. 5-21 5.3.5.9...

  • Page 17: Overview

    Overview Overview Introduction Chroma 62000H Series with Solar Array Simulation are high power density DC Power Supplies that can provide stable DC output and accurate measurement for voltage and current. The features of 62000H Series with Solar Array Simulation DC Power Supply are: (1) The output is able to simulate the I-V curve of solar panel module with Programming Mode provided.

  • Page 18: Output/Indication

    (4) 10 programs and 100 sequences to edit I-V curve waveform output. Specifications Chroma 62000H Series High Power Density DC Power Supplies with Solar Array Simulation contain 2KW (62020H), 5KW (62050H), 10KW (62100H) and 15KW (62150H) 4 sub-series by the output power and the power supply of each sub-series has various output specifications.
  • Page 19 Overview Table 1-1 62000H Series with Solar Array Simulation Operating Specification Model 62020H-150S 62050H-600S 62100H-600S 62150H-600S Output Ratings Output Voltage 0-150V 0-600V 0-600V 0-600V Output Current 0-40A 0-8.5A 0-17A 0-25A Output Power 2000W 5000W 10000W 15000W Voltage Measurement Range 60V / 150V...

  • Page 20: Other Specifications

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual A620027 Slave Unit A620028 Slave Unit Model 62150H-1000S (15kW) (15kW) Output Ratings Output Voltage 0-1000V 0-600V 0-1000V Output Current 0-15A 0-25A 0-15A Output Power 15000W 15000W...
  • Page 21 Overview Table 1-2 62000H with Solar Array Simulation Other Specifications (without model A620027 & A620028) Model 62000H Series with Solar Array Simulation Line Regulation Voltage +/- 0.01% F.S. Current +/- 0.05% F.S. Load Regulation Voltage +/- 0.05% F.S. Current +/- 0.1% F.S.
  • Page 22 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual ?Volt, ? Current Under GPIB command using Measure <25ms Analog Interface (I/O) Voltage and Current 0-10Vdc / 0-5Vdc / 0-5k ohm / 4-20 mA of F.S.
  • Page 23 Overview AC frequency range 47-63 Hz 62020H: 0.95 (200/240Vac) (200/220Vac) 62050H: 0.5 (380/400Vac) (440/480Vac) (200/220Vac) Power factor 62100H: 0.55 (380/400Vac) (440/480Vac) (200/220Vac) 62150H : 0.6 (380/400Vac) (440/480Vac) General Specification Maximum Remote Sense 2% of full scale voltage per line (4% total) Line Drop Compensation 62020H : Approx.
  • Page 24 There is parallel mode for DC Power Supply when the I-V Curve function is enabled. 17. Varied by local voltage regulation, all models of 5KW, 10kW & 15kW in the 62000H Series with Solar Array Simulation have 200/220 Vac, 380/400 Vac...
  • Page 25 Overview and 440/480 Vac 3 types of input voltage for selection. There is also a single phase power supply 200/240 Vac, 2KW model available for selection. The user can follow the local voltage regulation to select a proper voltage spec. The Power Supply is set with the required input voltage when shipped and when the input voltage is not within the range, it will show AC_fault protection and shut down the output.

  • Page 26: Function Keys

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 62020H-150S ±250 62050H-600S ±1200 62100H-600S ±1200 62150H-600S ±1200 62150H-1000S ±1200 A620028 ±1200 A620027 ±1200 If the voltage exceeds the above range it may result damage to the DC Power Supply.
  • Page 27 Overview Figure 1-5 Front Panel of 62020H-150S with Solar Array Simulation Table 1-5 Description of Front Panel Item Symbol Description Display: VFD Display: it shows the output settings and measured result. Numeric and Decimal Point: ● Users can use the numeric keys and the decimal point key to enter digital data.

  • Page 28: Rear Panel

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Item Symbol Description Function Page”. Cursor Movement Keys: Use “ ” and “ ” keys to move the cursor to the parameter to be modified. Voltage Rotary Knob: The user can turn the knob “...
  • Page 29 Overview Figure 1-7 Rear Panel of Slave Model A620027/A620028 Figure 1-8 Rear Panel of 62020H-150S with Solar Array Simulation Table 1-6 Description of Rear Panel Item Name Description It is a 9-pin D type male connector. The control commands are RS-232C /RS-485 transmitted between remote and PC for remote control.
  • Page 30 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual The callout 8 in Figure 1-6 is the cover plate for standard configuration. When GPIB/ETHERNET interface is selected as shipping default, it will be installed before shipment as Figure 1-9 (a) & (b) shows.

  • Page 31: Installation

    Checking the Package (1) Check if there is any damage or any missing accessories after unpacking it. (2) Should any damage be found, contact “Chroma RMA” immediately to request return shipment. Figure 2-1 (a), (b), (c), (d), (e), (f), (g) and (h) are the accessories.

  • Page 32: Maintenance & Cleaning

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Please keep all of the packing materials in case the device has to be returned for repair. Do not return the instrument to the factory without obtaining prior RMA acceptance from Chroma.

  • Page 33: Normal Environment Conditions

    Installation 2.2.1 Normal Environment Conditions (1) In door use. (2) Altitude up to 2000 meters. (3) Temperature 0C to 40C. (4) Maximum relative humidity is 65% at 25C and increasing linearly to 90% relative humidity for temperature up to 40C. ...
  • Page 34 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Secure the safety cover latch and safety cover to prevent the cable from falling or the electric terminal from exposing. Figure 2-3 Figure 2-4 Connect the green or green/yellow metal wire to terminal.
  • Page 35 Installation Connect the white or blue metal wire of Model 62020H-150S to the “N” terminal. Connect the black or brown metal wire of Model 62020H-150S to the “L” terminal. To protect the operators, the wire connected to the GND terminal WARNING ) must be connected to the earth.

  • Page 36: Remote Sensing

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Remote Sensing 2.4.1 Correct Connection Connecting remote sensing wire correctly can ensure the output voltage is the set voltage. The DC Power Supply is able to compensate maximum 4% of F.S. line voltage drop.

  • Page 37: Reverse Connection Of Remote Sensing Wire Polarity

    Output Connection The output connector of 62000H Series DC Power Supply with Solar Array Simulation is located at the upper middle area on the rear panel and for Model 62020H-150S it is on the left side of rear panel. The load is connected to “+” and “–” output terminal.
  • Page 38 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual (2) The output cable must be rated 85C at least. (3) Assembly  see Figure 2-9 (a) & (b) and Figure 2-11 (c), (d), (e), (f) and (g) for 62020H-150S.
  • Page 39 Installation Figure 2-11 To meet the safety requirement, the safety cover must be tightly CAUTION secured. The diameter of the wire connected to load must be able to carry the maximum current applied. It is no need to use the 62020H-150S 9PIN current sharing cable when using the device as a standalone.

  • Page 40: Specification Of Connecting Wire

    Do not use the wire with extra thin diameter to avoid overheating and causing hazard. Figure 2-12 2.5.3 Specification of Parallel Capacitance The parallel capacitance for output varies with the 62000H Series Models as Table 2-2 shows. Table 2-2 Model Max. Parallel Capacitance for Output (uF)

  • Page 41: Installing The Handle (62150H For Example)

    Installation 2.5.4 Installing the Handle (62150H for example) Use M4X12 flat head screws to secure the handle to the rack mounting kit as shown in Figure 2-13. Figure 2-13 Installing the Handle Power On Procedure Plug in the power cord and turn on the power switch on front panel. The DC Power Supply will run a series of self-tests.
  • Page 42 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual M O D E L : 6 2 1 5 0 H – 6 0 0 S S E R I A L N O :1 D I S P L A Y <...

  • Page 43: Manual Operation

    Manual Operation Manual Operation Introduction The DC Power Supply can be operated manually or remotely via GPIB/ETHERNET (option) or USB or RS-232/RS-485 or APG interface which is described in Chapter 5 and section 3.3.1.1. The manual operation for using the front panel keyboard or rotary knobs to input the data is described in this chapter.

  • Page 44: Setting Configuration

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual To set the current (CC MODE): Press “ ” and the rest of the settings are the same as for voltage as Figure 3-2 shows. CURR (Please note that in order to remain in CC mode the voltage setting must be larger than the load voltage, otherwise the output current will not be equal to the set current.)
  • Page 45 Manual Operation ) or “Rotary” ( Use the numeric keys ( ) knob to select the item to be set. Press “ ” to confirm. ENTER Press “ ” to return to the MAIN PAGE. EXIT To cancel the setting, press “ ”...
  • Page 46 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Figure 3-4...

  • Page 47: System Setup

    Manual Operation 3.3.1 SYSTEM SETUP In Config setup page, press “ ” and “ ” will display the screen of Figure 3-5. ENTER Use “ ”, “ ” keys to move the cursor to desired selection. [S Y S T E M S E T U P] A P G V S E T N O N E _ A P G I S E T...
  • Page 48 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Press “ ” to confirm. ENTER or “Rotary” ( For APG ISET, use the numeric keys ) to set the mode. There are 5 selections for APG ISET which are NONE / Vref(0-5V) / Vref(0-10V) / Iref(4-20mA) / Rref(0-5KOhm), where: NONE: It means not using the programming function.
  • Page 49 Manual Operation 0V ~ 600V/0A ~ 25A will map to 0~10V as Figure 3-7 (b) shows. c. When selecting Iref=4-20mA  it means the DC Power Supply’s output 0V ~ 600V/0A ~ 25A will map to 4-20mA as Figure 3-7 (c) shows.
  • Page 50 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 600V/25A 600V/25A APG OUTPUT 5V APG OUTPUT 10V 600V/25A APG OUTPUT 4mA~20mA Figure 3-8 When using APG, in case the error is too large be sure to calibrate the APG settings and measurements first.
  • Page 51 Manual Operation +12VAPI API GND AVO_SET_R AIO_SET_R AVO_SET_C AIO_SET_C AVO_SET_V AIO_SET_V AVO_MEAS_C AIO_MEAS_C AVO_MEAS_V AIO_MEAS_V sensing sensing sensing sensing Figure 3-10 Following lists the definition of each pin: Auxiliary power Vcc: This pin outputs a +12Vdc power with maximum output current 10mA (output port).

  • Page 52: Buzzer

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Current programming: It inputs the analog current (4-20mA) from this pin to APIGND that can control the output current (CC mode) linearly. Current programming: It inputs the analog voltage (0-10Vdc or 0-5Vdc) from this pin to APIGND that can control the output current (CC mode) linearly.
  • Page 53 Manual Operation Use “ ”, “ ” keys to move the cursor to the column to be set as Figure 3-12 shows. [S Y S T E M S E T U P] A P G V S E T N O N E A P G I S E T N O N E...

  • Page 54: Output Setup

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual [S Y S T E M S E T U P] A P G V S E T N O N E A P G I S E T...

  • Page 55: Voltage Limit Setting

    Manual Operation 3.3.2.1 VOLTAGE LIMIT SETTING Use “ ”, “ ” keys to move the cursor to the column to be set as Figure 3-16 shows. Figure 3-16 ) or “Rotary” ( Use the numeric keys ( ) knob to set the value. Use this option to narrow down the range by setting the MIN and MAX.

  • Page 56: Current Limit Setting

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 3.3.2.2 CURRENT LIMIT SETTING Use “ ”, “ ” keys to move the cursor to the column to be set as Figure 3-18 shows. Figure 3-18 ) or “Rotary”...

  • Page 57: Voltage Slew Rate

    Manual Operation 3.3.2.3 VOLTAGE SLEW RATE Use “ ”, “ ” keys to move the cursor to the column to be set as Figure 3-20 shows. Figure 3-20 ) or “Rotary” ( Use the numeric keys ( ) knob to set the value. Take example by 62150H-600S, the output voltage slew rate of the DC Power Supply is set as Figure 3-21 shows.

  • Page 58: Current Slew Rate Setting

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 3.3.2.4 CURRENT SLEW RATE SETTING Use “ ”, “ ” keys to move the cursor to the column to be set. Figure 3-22 ) keys or “Rotary” ( Use the numeric ( ) knob to set the value.

  • Page 59: Setting Dc_On

    Manual Operation 3.3.2.5 Setting DC_ON DC_ON has two settings for selection. One is when the output of DC power supply is ON and the voltage is over VDC_R, the pin10 DCOUT_ON of ANALOG INTERFACE on the rear panel will turn to HIGH. When the output of DC power supply is OFF and the voltage is lower than VDC_F, the pin10 DCOUT_ON of ANALOG INTERFACE on the rear panel will turn to LOW for other usages as Figure 3-24 shows.

  • Page 60: Setting Iv Curve Parameters

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Figure 3-26 ) keys or “Rotary” ( Use the numeric ( ) knob to set DCOUT ON MODED to ON/OFF making the pin10 of ANALOG INTERFACE to receive command from the OUTPUT button on the front panel.
  • Page 61 Manual Operation Iset2 Iset2 Iset2 Iset1 Iset1 Iset1 Vset2 Vset2 Vset1 Vset1 (a) CC Mode (a) CC Mode (b) CV Mode (b) CV Mode Figure 3-28 Set CONTROL MODE as described below: Use “ ”, “ ” keys to move the cursor to the column to be set as Figure 3-27 shows.
  • Page 62 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 3.3.2.6.3 Setting OUTPUT SPEED OUTPUT SPEED is to set the output response speed of IV Curve to FAST, MIDDLE or SLOW. The setting of output response speed is in the sequence of FAST > MIDDLE >...

  • Page 63: Series/Parallel

    3.3.3 SERIES/PARALLEL 62000H Series DC Power Supplies with Solar Array Simulation are able to operate in series or parallel when in the common CV/CC MODE. The voltage is up to 1200V if connecting in series and the current is up to 250A if connecting in parallel. When the IV curve function is enabled that is in TABLE Mode, SAS Mode and IV PROGRAM Mode, only parallel connection is supported with no series connection.

  • Page 64: Connecting Series/Parallel Output Cable

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 3.3.3.1 Connecting Series/Parallel Output Cable Figure 3-32 and Figure 3-33 show the connections of serial and parallel output cables. SVO+ SVO+ 62150H- 600S SVO+ SVO+ 62150H-600S...
  • Page 65 A620028 and A620027 SLAVE models only work when the MASTER firmware version is 1.30 or above for communication. For firmware upgrade, please contact the agent of Chroma. A620028 and A620027 SLAVE models have a 1 to 2 ANALOG communication cable labeled with SLAVE. This standard accessory is for A620028 and A620027 use only.
  • Page 66 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Figure 3-36 Each DC Power Supply has two RS485 interface female connectors. They need to be connected either in series or parallel operation. There is no difference between left and right; just to connect one after another as the solid lines shown in Figure 3-34 or Figure 3-35.

  • Page 67: Setting Series/Parallel Operation Mode

    It is necessary to set the SLAVE first and the MASTER last when CAUTION operating a 62000H Series DC Power Supply with Solar Array Simulation in series or parallel mode, or it may not be able to operate due to communication error.
  • Page 68 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual [ S E R I E S / P A R A L L E L ] M A S T E R O R S L A V E...
  • Page 69 ” to confirm. ENTER Description of M/S TERMINATOR When the 62000H Series Models with Solar Array Simulation are operating in MASTER OR SLAVE mode, please be aware of the M/S TERMINATOR setting. Assuming the connection is as Figure 3-40 shows, the M/S TERMINATOR of the first and last devices must be ENABLED with 120Ω...
  • Page 70 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual [ S E R I E S / P A R A L L E L ] M A S T E R O R S L A V E...
  • Page 71 Manual Operation [ S E R I E S / P A R A L L E L ] M A S T E R O R S L A V E M A S T E R M / S T E R M I N A T O R D I S A B L E P A R A L L E L O R S E R I E S...
  • Page 72 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 3. Press “ ENTER to confirm, it will skip to the series/parallel MASTER page automatically as Figure 3-45 shows. ∑ V = 6 0. 0 0 _ V = 1 0.

  • Page 73: Setting Series Parameters

    Manual Operation 3.3.3.4 Setting Series Parameters When the software communication and hardware settings for series are completed, the settings of following windows are introduced in the sections underneath - (1) MAIN PAGE, (2) SYSTEM SETUP, (3) OUTPUT SETUP and (4) PROTECTION. 3.3.3.4.1 Setting MAIN PAGE MAIN PAGE is mainly used to set voltage (V) and current (I).

  • Page 74: Setting Parallel Parameters

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 3.3.3.4.3 Setting OUTPUT SETUP for Series The V LIMIT MAX in OUTPUT SETUP of MASTER for series connection will increase following the number connected in series. It is indicated by ΣV LIMIT MAX: for easy identification as Figure 3-50 shows below.
  • Page 75 Manual Operation to MASTER, MST will appear at the window’s upper right corner as Figure 3-52 shows below. ∑ I V = 6 0. 0 0 _ V = 1 0. 0 0 M S T O F F 0 . 0 0 0 0 V 0 .

  • Page 76: Setting Procedure For Apg In Series Or Parallel

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual [O U T P U T S E T U P] L I M I T : M A X = 6 0 0 . 0 _ V M I N = 0 .
  • Page 77 Manual Operation As to the voltage setting, the inputted analog voltage 0~5V maps to the actual output voltage 0~1200V; and for the current setting, the inputted analog voltage 0~5V maps to the actual output current 0~25A as Figure 3-57(a) shows. Set the APG option to APG VSET/APG ISET = Vref(0-10V) means the inputted analog voltage 0~10V maps to the actual output 0~1200V for APG voltage also maps to the actual output 0~25A for APG current as Figure 3-57(b) shows.

  • Page 78: Display

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 600V/125A 600V/125A APG INPUT 5V/5V APG INPUT 10V/10V Figure 3-59 3.3.4 DISPLAY DISPLAY setting has 4 options: (1) BRIGHTNESS (2) DISPLAY SELECTION (2) READING AVERAGE TIMES (4) AVERAGE METHOD.

  • Page 79: Display Selection

    Manual Operation There are 3 selections for BRIGHTNESS: HIGH /NORMAL/ DIMMED, the system default is HIGH. Shortcuts and brightness description: Press “ ”, BRIGHTNESS = HIGH. Press “ ”, BRIGHTNESS = NORMAL. Press “ ”, BRIGHTNESS = DIMMED. The lower the backlight brightness, the longer the display panel life. Thus, it is suggested to turn the backlight brightness to DIMMED when the device is doing burn-in to prolong the product life of the VFD display.
  • Page 80 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual V = 6 0. 0 0 = 1 0. 0 0 _ O F F 0 . 0 0 0 0 V 0 . 0 0 0 0 A 0 .

  • Page 81: Reading Average Times

    Manual Operation 3.3.4.3 READING AVERAGE TIMES READING AVERAGE TIMES option can set the average times the MAIN PAGE displays. The default is 2 as Figure 3-65 shows. When changing the READING AVERAGE TIMES default, the average method can be changed. [ D I S P L A Y S E T U P ] B R I G H T N E S S = H I G H...

  • Page 82: Protection

    3.3.5 PROTECTION Chroma 62000H Series DC Power Supplies with Solar Array Simulation have complete protection functions divided into two classes. The first type protection includes over voltage, over current, over power and FOLDBACK; while the second type protection includes over temperature, fan failure and over/under input voltage.

  • Page 83: Ocp Protection

    Manual Operation ) or “Rotary” ( Use the numeric keys ( ) knob to set the value. Press “ ” to confirm. ENTER Press “ ” to return to the MAIN PAGE. EXIT This function sets the protection point for Over Voltage. Once the output voltage exceeds the range, it will turn off the output that is OUTPUT = OFF to protect the unit under test.

  • Page 84: Opp Protection

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual This function sets the protection point for Over Current. Once the output current exceeds the range, it will turn off the output that is OUTPUT = OFF to protect the unit under test.

  • Page 85: Remote Inhibit

    Manual Operation This function sets the protection point for Over Power. Once the output power exceeds the range, it will turn off the output that is OUTPUT = OFF to protect the unit under test. Table 3-4 shows the power range of OPP. Table 3-4 Model Min.
  • Page 86 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Selecting DISABLE: It closes the function. Selecting ENABLE: It sets the REMOTE INHIBIT to ENABLE. The DC Power Supply’s ON/OFF is still controlled by “ ” key. When...

  • Page 87: Safety Int.lock

    Manual Operation _INHIBIT SIGNAL Output INHIBIT =DISABLE Output INHIBIT =ENABLE Figure 3-77 3.3.5.5 SAFETY INT.LOCK This function allows users to control the DC Power Supply to be OFF temporary through the Pin 21 (INTERLOCK) of the ANALOG INTERFACE. Use “ ”...
  • Page 88 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Pin21 of the ANALOG INTERFACE is returned to low level, the DC Power Supply will continue to output normally. Press “ ” to confirm. ENTER Press “...

  • Page 89: External On/Off

    Manual Operation 3.3.5.6 EXTERNAL ON/OFF This function allows users to control the DC Power Supply’s ON/OFF through Pin22 (_EXT_ON) of the ANALOG INTERFACE. Use “ ”, “ ” keys to move the cursor to the column to be set as Figure 3-81 shows.

  • Page 90: Foldback

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Furthermore, Pin22 is an input pin of TTL Level and is able to set the initial state to PULL=HIGH or PULL=LOW. When the DC Power Supply is set to OUTPUT = ON, the detail actions of EXTERNAL ON/OFF are as shown in Figure 3-83.
  • Page 91 Manual Operation DISABLE: Ignore the output off function. CV TO CC: Active in CV MODE only. Once the work mode changed to CC MODE the system will turn off the output to protect the UUT. CC TO CV: Active in CC MODE only. Once the work mode changed to CV MODE the system will turn off the output to protect the UUT.

  • Page 92: Otp

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual CV MODE DC SOURCE OPERATION MODE DELAY TIME Time FOLDBACK PROTECTION CC MODE Figure 3-87 Assuming the FOLDBACK is set to CV TO CC, the solid line in Figure 3-87 will create Foldback protection while the dotted line will not.

  • Page 93: Ac Fault

    Manual Operation 3.3.5.9 AC FAULT The AC FAULT protection will activate when the internal input voltage is not within the model’s range, or when a certain input voltage is having an under voltage condition. The output will turn off that is OUTPUT = OFF for protection. When AC FAULT occurs the main page will prompt a protection message as Figure 3-89 shows: V = 6 0.

  • Page 94: 3.3.5.11 Fanlock Protection

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual (1) When the connection is wrong, for instance the VOLTAGE SENSING polarity is reversed that means the UUT’s “–” terminal is connected to the “+” of output terminal, and UUT’s “+”...

  • Page 95: 3.3.5.12 D/D Fault Protection

    (2) If D/D FAULT protection happens again, please contact the local agent of Chroma to return it for repair. 3.3.5.13 CURR. SHARING ERR Protection This protection occurs when the current sharing is not even in parallel state. The output will close that is OUTPUT = OFF to protect the DC Power Supply.

  • Page 96: 3.3.5.14 Fpga Update! Protection

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Figure 3-93 Troubleshooting: (1) When CURR. SHARING ERR protection occurs, please turn off the Power Supply first, remove the load and check if the connections are correct and then power it on again.

  • Page 97: 3.3.5.15 C/S Cable Err. Protection

    Manual Operation 3.3.5.15 C/S CABLE ERR. Protection This protection occurs under the following three conditions. The first condition is when the DC Power Supply is in single unit mode and the rear panel connects the CURR. SHARING cable as Figure 3-95 shows. The second condition is when the DC Power Supply is in series mode and the CURR.

  • Page 98: 3.3.5.16 Match Warning

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual (3) For hardware upgrade, please contact the agent of Chroma. The DC Power Supply could be malfunctioned or damaged if the WARNING CURRENT SHARING cable is connected incorrectly when in parallel mode.

  • Page 99: Calibration

    Figure 3-99 3.3.7 CALIBRATION Chroma 62000H Series DC Power Supplies with Solar Array Simulation provide (1)~(5) calibration functions while A620028/A620027 provides the previous (1)(2)(3) calibration functions and the 62020H-150S model provide (1)~(7) calibration functions: (1) VOLTAGE: the actual voltage output (CV mode) and its measurement accuracy.
  • Page 100 [ P R O G . / M E A S . ] Figure 3-101 The slave model A620028/A620027 of Chroma 62000H Series DC Power Supplies with Solar Array Simulation has 3 CALIBARTION functions which are: (1) VOLTAGE: the actual voltage output (CV mode) and its measurement accuracy.
  • Page 101 Manual Operation Figure 3-102 When the address of to be calibrated SLAVE is confirmed, keep in parallel mode and go to the CONFIG setting page, press “ ” and “ ” to enter into CALIBRATION ENTER for password input as shown in Figure 3-100. Select MASTER OR SLAVE via “Rotary Knob”...

  • Page 102: Voltage Output & Measurement Calibration

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual suggested to do the calibration once every other year. For further requirements, please contact Chroma to arrange for calibration again. 3.3.7.1 Voltage Output & Measurement Calibration 3.3.7.1.1...
  • Page 103 Manual Operation [ V O L T A G E C A L I B R A T I O N ] R E M O V E E X T E R N A L L O A D A N D P R E S S [ E N T E R ] _ S E T T I N G O U T P U T...

  • Page 104: Current Measurement Calibration

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Now the voltage calibration is done. To save the calibration data, press “ ” will SAVE prompt a confirmation page as Figure 3-109 shows. Press “...
  • Page 105 Manual Operation 3.3.7.2.2 SETUP Figure 3-110 is the diagram for connecting current calibration devices.  Current Shunt       62000H Electronic Load DC Power Supply    Breaker Figure 3-110 Before using ULTRASTAB SATURN for current calibration, it needs to calibrate the offset voltage of ULTRASTAB SATURN first.
  • Page 106 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual current read by Current Shunt (DVM) to position [1] and press “ ” to confirm and ENTER wait for it to end. [ C U R R E N T...
  • Page 107 Manual Operation [ C U R R E N T M E A S C A L I B R A T I O N ] S E T L O A D I N G C U R R E N T = 7 .

  • Page 108: Current Output (Prog.) Calibration

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual The calibration point may be different for other models (non 62150H-600S), please operate it following the instructions displayed. 3.3.7.3 Current Output (PROG.) Calibration 3.3.7.3.1 Hardware Requirements Table 3-8 lists the hardware requirements for current output calibration.
  • Page 109 Manual Operation 3.3.7.3.3 Calibration Procedure (Example: Model 62150H-600) Set the Electronic Load to CV mode 48V. In CALIBRATION page, press “ ” or turn “Rotary” ( ) knob to set CHOICE=3. Press “ ENTER to confirm and entering into current calibration options as Figure 3-118 shows.
  • Page 110 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Press “ ” will perform 4.5A calibration. The system will set the output current to 4.500A automatically and the cursor will stop at position [2] as Figure 3-121 shows.

  • Page 111: Apg Voltage Calibration

    Manual Operation [ C U R R E N T S E T T I N G C A L I B R A T I O N ] S E T T I N G O U T P U T C U R R E N T = 1 9 .
  • Page 112 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 3.3.7.4.2 SETUP Figure 3-125 shows the wire connection for APG voltage calibration. AVO_MEAS +12VAPI API GND AVO_SETV       DC Power DVM 1...
  • Page 113 Manual Operation It will ask the user to input about 0.5V voltage signal (Pin 4). The cursor stops at position [1] as Figure 3-127 shows after pressed “ ” for the above step. Adjust the Power ENTER Supply to 0.5V±0.2V and use DVM1 to measure the reading of Power Supply. Input the voltage read by DVM1 to position [1] and press “...

  • Page 114: Apg Current Calibration

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual [ S A V E A R G U M E N T ] S A V E = N O Figure 3-129 Press “ ” to return to the MAIN PAGE.
  • Page 115 Manual Operation When conducting the APG current calibration, each calibration point has to key in at least 4 Arabic numerals to ensure the Power Supply accuracy after calibration. 3.3.7.5.3 Calibration Procedure (Example: Model 62150H-600S) In CALIBRATION page, press “ ” or turn the “Rotary” ( ) knob to set CHOICE = Press “...
  • Page 116 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Power Supply. Input the voltage read by DVM1 to position [2] and press “ ” to ENTER confirm. Press “ ” again the system will set the output voltage of Pin 19 on the rear panel to 0.5V and the cursor stops at position [3] as Figure 3-133 shows.

  • Page 117: Voltage Output & Measurement Calibration (62020H-150S Only)

    Manual Operation 3.3.7.6 IV Voltage Output & Measurement Calibration (62020H-150S Only) 3.3.7.6.1 Hardware Requirements The hardware required is shown in Table 3-11. Table 3-11 Device Suggest Model or Capacity HP 34401A or equivalent DVM 3.3.7.6.2 Setup The wiring is shown in Figure 3-135. Figure 3-135 For device to perform calibration, its accuracy has to higher than the specification.
  • Page 118 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual In the CALIBRATION page, press “ ” or turn the “Rotary” ( ) knob to set CHOICE=1. Press “ ” to confirm entering into Voltage Calibration as Figure 3-137 shown ENTER below.

  • Page 119: Current Calibration (62020H-150S Only)

    Device Suggest Model or Capacity HP 34401A or equivalent DVM DCCT ULTRASTAB SATURN ELECTRICAL LOAD CHROMA 63204 or equivalent LOAD BREAKER Capable current>=100A The BREAKER capacity listed in the table above is for 62150H-600S CAUTION use only. For other models, see the OUTPUT CURRENT spec in...
  • Page 120 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Table 1-1 for selecting the appropriate BREAKER. 3.3.7.7.2 SETUP The connecting diagram for current calibration is shown in Figure 3-141.  ULTRASTAB  SATURN  ...
  • Page 121 Manual Operation Open the Breaker to ensure the DC Power Supply is in no load state and press “ ” ENTER to confirm. Next, the screen appears as shown in Figure 3-143. Press “ ” to do the low ENTER current range calibration first.
  • Page 122 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual [C U R R E N T M E A S C A L I B R A T I O N ] A P P L Y...

  • Page 123: Remote Setup

    Manual Operation 3.3.8 REMOTE SETUP 3.3.8.1 GPIB ADDRESS This DC Power Supply supports remote operation via GPIB function. It is necessary to set the GPIB address before operating remotely. Use “ ”, “ ” keys to move the cursor to the column of GPIB ADDR as Figure 3-148 shows.
  • Page 124 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Manual detection: or “Rotary” ( Move the cursor to DHCP and use numeric keys ) to set the DHCP to OFF. Move the cursor to IP ADDRESS and use numeric keys to set the IP address.

  • Page 125: Rs232/Rs485

    Manual Operation 3.3.8.3 RS232/RS485 Use “ ”, “ ” keys to move the cursor to the column of RS232/RS485 as Figure 3-151 shows. Figure 3-151 or “Rotary” ( Use numeric keys ) to select RS232 or RS485. Press “ ” to confirm. ENTER Press “...

  • Page 126: Baudrate

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 3.3.8.4 BAUDRATE The DC Power Supply is also able to operate remotely via RS-232. Before use it is necessary to set the RS-232 baudrate. Use “...

  • Page 127: Rs485 Terminator

    Manual Operation Press “ ” to confirm. ENTER Press “ ” to return to the MAIN PAGE. EXIT The valid address range is 1~30. 3.3.8.6 RS485 TERMINATOR When using the remote operation via RS485 function, it needs to set the terminator status. Use “...

  • Page 128: Output Mode

    Please contact Chroma’s agent for firmware upgrade. 3.3.9 OUTPUT MODE Chroma 62000H Series DC Power Supply with Solar Array Simulation has 3 operating modes, which are: (1) CV/CC MODE: It is the common CV MODE and CC MODE of a DC Power Supply.

  • Page 129: Cv/Cc Mode

    3.3.9.1 CV/CC MODE In addition to the function of Solar Array Simulation the models of Chroma 62000H Series DC Power Supplies with Solar Array Simulation can also be used as general DC Power Supply. Thus the operating mode still has CV mode and CC mode as Figure 3-157 shows.
  • Page 130 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Figure 3-158 Figure 3-159 is the screen displayed by single unit when using Solar Array Simulation Soft Panel. The user cannot change the settings from the single unit directly.

  • Page 131: Sas Mode

    3.3.9.3 SAS MODE Chroma 62000H Series DC Power Supply with Solar Array Simulation not only able to simulate the Solar Cell curve via the Solar Array Simulation Soft Panel but also has built in model to provide solar cell curve simulation function that is called SAS Mode. Please see Britton, Lunscher, and Tanju, "A 9 KW High-Performance Solar Array Simulator",...
  • Page 132 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual are presented on the DC Power Supply screen, the result obtained from the formula will be presented. Setting procedure: keys or “Rotary” ( Use the numeric ) knob to select SAS_MODE as Figure 3-161 shows.
  • Page 133 Manual Operation Figure 3-163 Press “ ” again for execution. It will jump to the SAS MODE main screen as ON/OFF Figure 3-164 shows. To quit, press “ ” to return to the MAIN PAGE. EXIT Figure 3-164 Figure 3-164 shows the screen when the SAS MODE outputs. The EQ_PMP, EQ_VMP and EQ_IMP are the actual operating points that are calculated from the settings of user VMP and IMP via the hardware built-in formula.
  • Page 134 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual I-V Curve Programming Response Time (Typical) 62050H-600S Delta V= 600 to 0V (1s @ No Load) (40ms @ 500W ) (8ms @ 2500W ) Delta V=350 to 250V (160ms @ No Load) (6.6ms @ 500W )

  • Page 135: En50530 Mode

    3.3.9.4 EN50530 MODE Chroma 62000H Series Programmable DC Power Supply (with Solar Array Simulation) besides can simulate the solar cell curve via Solar Array Simulation Soft Panel, it also has EN50530 built in to provide solar cell curve simulation function.

  • Page 136: Sandia Mode

    3.3.9.5 SANDIA MODE Chroma 62000H Series Programmable DC Power Supply (with Solar Array Simulation) besides can simulate the solar cell curve via Solar Array Simulation Soft Panel, it also has SANDIA_MODE built in to provide solar cell curve simulation function.
  • Page 137 Manual Operation Press “ ” to return to the MAIN PAGE. EXIT Figure 3-169 When in SANDIA _MODE, the screen shows as Figure 3-170. Figure 3-170 Setting Procedure: Move the cursor to VMP and use the numeric keys ( ) to set the maximum power voltage.

  • Page 138: Error Message

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Figure 3-171 10. Press “ ” again to confirm the execution and it will go to the SANDIA_MODE main ON/OFF screen as Figure 3-172 shows. To quit, press “...
  • Page 139 Manual Operation Figure 3-173 When in EN50530 or SANDIA_MODE setting screen, if the parameter shows negative after calculation, the screen will show as Figure 3-174. Please press “ ” to return to EXIT OUTPUR_MODE for setting again. Figure 3-174 3-97...

  • Page 141: Program Sequence

    Program Sequence Program Sequence 62000H Series DC Power Supply with Solar Array Simulation allows the user to program the sequence for output in LIST MODE, V_STEP MODE and IV PROGRAM. LIST MODE and IV PROGRAM both have 10 Programs and each Program can add new sequences liberally that total 100 sequences, while IV PROGRAM is used to edit the IV Curve waveform in particular.

  • Page 142: Description Of Program Settings

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual [ PROGRAM ] EXT._TRIG PULL HIGH PROG NO. COUNT PROG CHAIN = NO CLEAR PROG = NO [ SEQUENCE ] TYPE = AUTO TIME = 0.000(S) VOLTAGE = 0.00V...

  • Page 143: Setting Ext._Trig Pull

    Program Sequence 4.1.1.1 Setting EXT._TRIG PULL Use “ ”, “ ” keys to move to the cursor to the column to be set as Figure 4-3 (1) shows. or “Rotary” ( Use numeric keys ) to set HIGH or LOW. Press “...
  • Page 144 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Each PROGRAM has a RUN COUNT that sets the execution number. The following table lists the RUN COUNT range: Table 4-1 RUN COUNT TIMES 15000 Ex.1: Set RUN COUNT for a PROGRAM Set PROG #1 to NEXT TO PROG NO =3, RUN COUNT=2.

  • Page 145: Setting Prog Chain

    Program Sequence 4.1.1.4 Setting PROG CHAIN Use “ ”, “ ” keys to move the cursor to the column to be set as Figure 4-3 (4) shows. or “Rotary” ( Use numeric keys ) knob to set YES or NO. The PROGRAM CHAIN indicates the link among programs.
  • Page 146 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual START PROG #1 PROG #6 PROG CHAIN NO = 3 PROG CHAIN NO = 0 SEQ 1_1 ~ SEQ 1_10 SEQ 6_1 ~ SEQ 6_10 PROG #2...
  • Page 147 Program Sequence START PROG #1 PROG CHAIN NO. = 1 SEQ 1_1 ~ SEQ 1_10 Figure 4-6 Ex.4: Use multiple PROGRAMS to form an infinite loop Set PROG #1 to NEXT TO PROG NO =3, RUN COUNT=1 PROG #3 to NEXT TO PROG NO =4, RUN COUNT=1 PROG #4 to NEXT TO PROG NO =6, RUN COUNT=1 PROG #6 to NEXT TO PROG NO =1, RUN COUNT=1 The program execution flow is listed as Figure 4-7shows.

  • Page 148: Setting Clear Program

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual START PROG #1 PROG #6 PROG CHAIN NO. = 3 PROG CHAIN NO. = 1 SEQ 1_1 ~ SEQ 1_10 SEQ 6_1 ~ SEQ 6_10 PROG #2 PROG #7 PROG CHAIN NO.

  • Page 149: Setting Sequence

    Program Sequence Clear Program has two options, which are CLEAR PROG. = YES / NO. The main function of Clear Program is to clear all sequences in that program. Press “ ” to confirm. ENTER Press “ ” to return to Figure 4-1. EXIT 4.1.2 Setting Sequence...

  • Page 150: Setting Sequence Number

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 4.1.2.1 Setting Sequence Number Use “ ”, “ ” keys to move the cursor to the column to be set as Figure 4-8 (1) shows. When the cursor is in Figure 4-8 (7), press “...
  • Page 151 Program Sequence [ S E Q U E N C E ] S E Q S E Q T Y P E = A U T O _ T I M E 0 . 0 0 0 ( S ) V O L T A G E 0 .
  • Page 152 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual A5: Execution step: (1) SEQ#1: Since SEQ TYPE = AUTO is set for SEQ#1, it begins to execute the settings in SEQ#1. During SEQ#1 voltage rise, the maximum loading current is 1A and does not exceed the current setting 20A;...
  • Page 153 Program Sequence [ S E Q U E N C E ] S E Q S E Q T Y P E = M A N U A L _ V O L T A G E 0 . 0 0 V S .

  • Page 154: Setting Time

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 4.1.2.3 Setting Time Use “ ”, “ ” keys to move the cursor to the column to be set as Figure 4-8 (3) shows. or “Rotary” ( Use numeric keys ) to set the value.

  • Page 155: Setting Current Slew Rate

    Program Sequence 4.1.2.7 Setting Current Slew Rate Use “ ”, “ ” keys to move the cursor to the column to be set as Figure 4-8 (7) shows. or “Rotary” ( Use numeric keys ) knob to set the SEQ current conversion slew rate.

  • Page 156: Program List Mode Description

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Press “ ” in Program page (Figure 4-3) or Sequence page ON/OFF (Figure 4-8) will prompt a confirmation page as Figure 4-15 shows. Press “ ” to abort the executing program which means to stop EXIT the Power Supply from output.

  • Page 157: Setting V_Step Mode

    Program Sequence [ P R O G R A M / S T E P] S T A R T _ V O L T A G E = 0 . 0 0 E N D _ V O L T A G E = 0 .

  • Page 158: Setting End_Voltage

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 4.2.1.2 Setting END_VOLTAGE 1. Use “ ”, “ ” keys to move the cursor to the column to be set as Figure 4-19 (2) shows. Set the end voltage of STEP MODE.

  • Page 159: Execution Of V_Step Mode

    Program Sequence 10(MIN) START Figure 4-21 10(MIN) START Figure 4-22 4.2.2 Execution of V_STEP MODE After the setting is done, press “ ” to confirm and start the execution. To abort it, just ON/OFF press “ ”. EXIT 4.2.2.1 Running V_STEP MODE 1.

  • Page 160: Iv Program

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual S T E P S T A T U S = A U T O E L A P S E T I M E =...

  • Page 161: Setting Iv-Program

    Program Sequence [ IV-PROGRAM ] PROG NO. COUNT PROG CHAIN = NO CLEAR PROG = NO [ IV-SEQUENCE ] IV-FILE NO. TYPE = AUTO TIME 0 (S) [ IV-SEQUENCE ] IV-FILE NO. TYPE = AUTO TIME 0 (S) [ IV-SEQUENCE ] IV-FILE NO.

  • Page 162: Setting Iv-Sequence

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 4.3.2 Setting IV-Sequence The number of default IV-SEQUENCE in an IV-PROGRAM is 0 and each IV-PROGRAM can add IV-SEQUENCE freely to 100 sequences in total. In other words, the sum of IV-SEQUENCE set in the total 10 IV-PROGRAMS is 100 maximum.

  • Page 163: Setting Iv-File Number

    Program Sequence number and return to the Sequence Number set previously. An IV-Program is able to add 100 IV-Sequences maximum, so the SEQ NO. range is 1~100. Press “ ” to confirm. ENTER Press “ ” to return to IV-Program Page (Figure 4-26). EXIT 4.3.2.2 Setting IV-FILE Number...

  • Page 164: Setting Time

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual [ I V- S E Q U E N C E ] S E Q N O. I V – F I L E N O. =...

  • Page 165: Execution Of Iv Program

    Program Sequence 4.3.3 Execution of IV PROGRAM Once the waveform completes the editing, press “ ” to confirm it for execution and ON/OFF press “ ” to abort the execution. EXIT 4.3.3.1 Running IV PROGRAM Press “ ” will prompt a confirmation screen as Figure 4-30 shows. ON/OFF Figure 4-30 Press “...

  • Page 166: Iv Program Main Screen

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 4.3.3.2 IV Program Main Screen When the IV PROGRAM is running the main screen will appear as Figure 4-32 shows. The definitions of items (1) ~ (10) in Figure 4-32 are explained below.

  • Page 167: Remote Operation

    5.1.3 Connecting RS-232C The default baudrate of 62000H Series DC Power Supply is 115200 and the parity check is set to None. Only TxD and RxD signal can be used for data transmission. The connector of RS-232C is a 9-pin D type male connector. Table 5-1 lists the pins and signals of RS-232C...

  • Page 168: Connecting Rs-485

    5.1.4 Connecting RS-485 The default transmission baudrate of 62000H Series is set to 115200 and the parity check is set to None. The RS-485 interface is a half-duplex two-wire differential signaling transmission and only RS485_P and RS485_N signals are required for data transmission. The connection is the same as RS-232C that is a 9-pin D type male connector.

  • Page 169: Ethernet Remote Control

    To set the IP address of Chroma 62000H Series, just use the “REMOTE” setting in “CONFIG” menu. This section describes how to use the network interface rapidly and correctly. Be sure to read it clearly and carefully before using the 62000H network interface and ensure the network is connected firmly and correctly to the hardware before execution.

  • Page 170: Selecting The Lan To Be Connected

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 5.1.5.1 Selecting the LAN to be Connected The LAN is divided into Site LAN and Private LAN. Site LAN usually indicates the larger local area network such as Intranet that contains network server (DHCP, WINS, DNS, etc.), Terminator, Router, Firewall and Internet linkage...
  • Page 171 Remote Operation If Site LAN mode is selected, the following two ways can be used to connect the PC. DC Source 62000H Site LAN Site LAN Site LAN DC Source 62000H DC Source 62000H DC Source 62000H Private LAN indicates the smaller local area network that is composed of more than two terminators and Hub or two terminators linked through Crossover Cable.

  • Page 172: Setting Ip, Subnet Mask & Gateway

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual DC Source 62000H DC Source 62000H DC Source 62000H 5.1.5.2 Setting IP, Subnet Mask & Gateway In Site LAN Only the 62000H needs to do network setting. It can set DHCP to ON (Server sets the IP automatically) or OFF (set IP manually.) For Model 62020H-150S, please refer to 7.2.1 for...
  • Page 173 Remote Operation CONFIG PAGE 1. SYSTEM SETUP 2. OUTPUT SETUP 3. SERIES/PARALLEL 4.DISPLAY 5. PROTECTION 6.FACTORYSETTING 7. CALIBRATION 8. REMOTE GPIB ADDR ETHERNET = CONFIG DHCP：ON ：XXX.XXX.XXX.XXX IP ADDRESS GATEWAY ADDR：XXX.XXX.XXX.XXX ：XXX.XXX.XXX.XXX SUBNET MASK APPLY=YES LAN Status RS232/RS485 BAUDRATE STEP 2: Click downward to APPLY and set it to YES to confirm sending out the settings.
  • Page 174 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual SETTING : The network card is setting. CONNECTING : The network card is connecting. NONE_CONNECT : The network is not connected. CONNECTED : The network is connected.
  • Page 175 Remote Operation In Private LAN In common situation, the PC does not have a DHCP Server. So this sections only explains the procedures for setting DHCP=OFF. In Private LAN, the IP of all connected network devices need to be set manually, such as the PC is connected to 62000H through Crossover Cable so these two devices have to set the IP manually.
  • Page 176 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual STEP 3: Double-click “Internet Protocol (TCP/IP)” to enter into its setting screen. 5-10...
  • Page 177 When the setting is done, click OK to return to previous level and click OK again to complete the setting procedure. Procedure for setting DHCP = OFF on Chroma DC Source 62000H: STEP 1: It is required to set the IP, GATEWAY and SUBNET MASK parameters when the DHCP=OFF.

  • Page 178: Confirming Network Connected Successfully

    Confirming Network Connected Successfully When the actions are done it means the environment of local area network is well setup including the Chroma DC Source 62000H network card. Please follow the steps below to make the setting of local area network is correct.

  • Page 179: Communicating With The Instrument

    Remote Operation STEP 3: If MS-DOS environment is opened in STEP2, it can input ping IP address directly, such as ping 10.1.6.209. If there is a response, it means the setting of local area network is done successfully. 5.1.5.4 Communicating with the Instrument The user can use the NI-MAX (Measurement &...
  • Page 180 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual STEP 1: Open the NI-MAX (Ver. 4.3.0F0), right-click the [Devices and Interface] and click [Create New. . .]. STEP 2: Select “VISA TCP/IP Resource” and click Next.
  • Page 181 Remote Operation STEP 3: Select Raw Socket and click Next. STEP 4: Input the IP Address and Port Number (the TCP/IP Port used by 62000H is 2101) and click Validate. 5-15...
  • Page 182 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual STEP 5: The following screen will appear if the connection is successful. Close this message and then click Finish to end it. STEP 6: A VISA TCP/IP Resource will be added to the Configuration list under Devices and Interfaces.
  • Page 183 Remote Operation STEP 7: Select Termination Char Enable for the Attribute Name in Property Node (Write) under “Template” tab. If the Current Value is set to VI_FALSE, please change the New Value to VI_TRUE and click Execute. STEP 8: Click “Basic I/O” tab and use Write to write in the command to 62000H (using *IDN? as the example) and click Execute.

  • Page 184: Gpib Function Of 62000H Series

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual STEP 9: Select “Basic I/O” tab and use Read to read back the 62000H status and click Execute. GPIB Function of 62000H Series Table 5-4 GPIB Function...

  • Page 185: Conventions

    Remote Operation 5.3.1 Conventions The table below lists the convention used in this section. Table 5-5 Angle brackets < > Items in angle brackets are parameter abbreviations. Vertical bar Vertical bar separates alternative parameters. Square Items in square brackets are optional. For example, brackets OUTP [ : STATe] means that : STATe may be omitted.

  • Page 186: Basic Definition

    Instrument-controlled headers are used for all other instrument commands. Each of them has a long form and a short form. 62000H Series only accepts the exact short and long forms. A special notation will be taken to differentiate the short form header from the long one of the same header in this subsection.

  • Page 187: Program Message Unit

    Remote Operation 5.3.5.7 Program Message Unit Program message unit represents a single command, programming data, or query. Example: VOLT?, OUTPut ON. 5.3.5.8 Program Message Unit Separator (;) The separator (semicolon ;) separates the program message unit elements from one another in a program message.

  • Page 188: Commands Of Dc Power Supply

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Commands of DC Power Supply This section describes the syntax and parameters of all commands for DC Power Supply. 5.6.1 Common Command Syntax Commands are defined by IEEE488.2 standard containing common and query commands.
  • Page 189 62150H-600S Model name 123456 Serial No. 01.00 Firmware version Return Example: CHROMA ATE, 62150H-600S,123456,01.00 *OPC Operation Complete Command Type: Device status Description: This command causes the interface to set the OPC bit (bit 0) of the Standard Event Status register when the DC Power Supply has completed all pending operations.
  • Page 190 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual the bit position enable bits are logically ORed to cause Bit 6 (the Master Summary Status Bit) of the Status Byte register to be set. See Status Byte register for detail description.
  • Page 191 Remote Operation Table 5-7 Bit No. Bit Weight Description Operation Status Register Summary Bit Request Service Bit. This bit is set when any enabled bit of the Status Byte Register has been set, which indicates it has at least one reason for requesting service.

  • Page 192: Specific Commands For 62000H Series

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Table 5-8 Bit No. Bit Weight Description Power on Bit. Reboot the Power Supply can set this bit to 1. Always 0. Command Error Bit. This bit is set to 1 if there is any IEEE 488.2 syntax error.
  • Page 193 Remote Operation CONFigure:OUTPut Description: It sets the voltage/current output. Syntax: CONFigure:OUTPut ON CONFigure: OUTPut OFF Parameter: ON|OFF Example: CONFigure: OUTPut The power supply starts output. CONFigure: OUTPut OFF The power supply stops output. Query Syntax: CONFigure: OUTPut? Query Example: CONF: OUTPut? Return Example: ON or OFF CONFigure:FOLDback...
  • Page 194 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual CONFigure:APGISet Description: It sets the action type of APG ISET. Syntax: CONFigure:APGISet NONE CONFigure:APGISet VREF5 CONFigure:APGISet RREF Parameter: NONE | VREF5 | VREF10 | IREF | RREF...
  • Page 195 Remote Operation Example: CONFigure: BRIGhtness HIGH CONFigure: BRIGhtness NOR CONFigure: BRIGhtness DIM Query Syntax:： CONFigure: BRIGhtness? Return Parameter: HIGH | NOR | DIM Query Example: CONFigure: BRIGhtness ? It returns the brightness control status of panel. Return Example: HIGH 13. CONFigure:MSTSLV:ID Description: It sets to Master or Slave.
  • Page 196 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 16. CONFigure:MSTSLV Description: It executes the Master/Slave control. Syntax: CONFigure:MSTSLV ON CONFigure:MSTSLV OFF Parameter: ON | OFF Example: CONFigure:MSTSLV ON CONFigure:MSTSLV OFF Query Syntax: CONFigure:MSTSLV? Return Parameter: ON| OFF...
  • Page 197 Remote Operation 20. CONFigure:INTERLOCK:PULL Description: It controls the internal resistance status of Safety Interlock input signal. Syntax: CONFigure:INTERLOCK:PULL <ARG> Parameter: LOW|HIGH Example: CONFigure:INTERLOCK:PULL LOW CONFigure:INTERLOCK:PULL HIGH Query Syntax: CONFigure:INTERLOCK:PULL? Return Parameter: LOW | HIGH Query Example: CONF:INTERLOCK:PULL? Return Example: 21. CONFigure:EXTON Description: It enables the External ON/OFF control.

  • Page 198: Source Subsystem

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 5.6.2.3 SOURCE Subsystem SOURce:VOLTage Description: It sets the output voltage. Syntax: SOURce:VOLTage <NRf+> Parameter: Refer to individual spec for valid numeric range. Example: SOUR:VOLT 0.01 It sets the output voltage to 0.01 volt.
  • Page 199 Remote Operation SOURce: CURRent Description: It sets the output current (ampere). Syntax: SOURce:CURRent <NRf+> Parameter: Refer to individual spec for valid numeric range. Example: SOUR:CURR 1 It sets the output current to 1 amps. SOUR:CURR 60.00 It sets the output current to 60.00 amps. Query Syntax: SOUR:CURR? Return Parameter: <NRf+>...
  • Page 200 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual SOURce:CURRent:SLEWINF Description: It sets the I Slewrate to INF. Syntax: SOURce:CURRent:SLEWINF ENABLE SOURce:CURRent:SLEWINF DISABLE Parameter: ENABLE/DISABLE Example: SOUR:CURR:SLEWINF ENABLE It sets the I Slewrate to INF.

  • Page 201: Fetch Subsystem

    Remote Operation 5.6.2.4 FETCH Subsystem FETCh:VOLTage? Description: It measures the output of Power Supply and returns real time voltage. Query Syntax: FETCh:VOLTage? Return Parameter: <NRf+> [Unit Volt] Query Example: FETC:VOLT? Return Example: 9.983100e+00 FETCh:CURRent? Description: It measures the output of Power Supply and returns real time current.

  • Page 202: Measure Subsystem

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 5.6.2.5 MEASURE Subsystem MEASure:VOLTage? Description: It returns the voltage measured at the output of Power Supply. Query Syntax: MEASure:VOLTage? Return Parameter: <NRf+> [Unit Voltage] Query Example:...

  • Page 203: Program Subsystem

    Remote Operation 5.6.2.6 PROGRAM Subsystem PROGram: SELected Description: It sets the executed program no. Syntax: PROGram: SELected <NR1> Parameter: 1 to 10 Example: PROG:SEL 10 Query Syntax: PROG:SEL? It returns the program no. in use. Return Parameter: <NR1> Query Example: PROG:SEL? Return Example: PROGram:LINK...
  • Page 204 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Parameter: LOW|HIGH Example: PROGram:PULL LOW PROGram:PULL HIGH Query Syntax: PROGram:PULL? Return Parameter: LOW | HIGH Query Example: PROGram:PULL? Return Example: PROGram:SEQuence:SELected Description: It sets the execution sequence of a program.
  • Page 205 Remote Operation Example: PROG:SEQ:CURR 40.5 Query Syntax: PROG:SEQ:CURR? Return Parameter: <NRf+> Query Example: PROG:SEQ:CURR? Return Example: 4.500000e+01 12. PROGram:SEQuence:CURRent:SLEW Description: It sets sequence for output voltage slew rate. Syntax: PROGram:SEQuence:CURRent:SLEW <NRf+> Example: PROG:SEQ:CURR:SLEW 10 Query Syntax: PROG:SEQ:CURR:SLEW? Return Parameter: <NR1> Query Example: PROG:SEQ:CURR:SLEW? Return Example:...
  • Page 206 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 17. PROGram:MAX? Description: It queries the sequence number of present program. Syntax: PROGram:MAX? Parameter: Example: PROG:MAX? Return Example: 2 means there are two sequences under the present program.
  • Page 207 Remote Operation 21. PROGram:STEP:ENDV Description: It sets the Step Mode end voltage for output. Syntax: PROGram:STEP:ENDV <NRf+> Example: It changes the end voltage of STEP Mode to 50.0 V. PROGram:STEP:ENDV 50 Query Syntax: PROGram:STEP:ENDV? Return Parameter: <NRf+> Query Example: PROGram:STEP:ENDV? Return Example: 5.000000e+01 22.

  • Page 208: Iv Subsystem

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 5.6.2.7 IV Subsystem IVCurve:VOC? Description: It queries the VOC in IV Curve Mode. Query Syntax: IVCurve:VOC ? Return Parameter: <NRf+> Query Example: IVCurve:VOC ? Return Example: 6.000000e+02...
  • Page 209 Remote Operation IVCurve:IT Description: It sets the stored 128 dots current data in IV Curve Mode. Syntax: IVCurve:IT <NRf+>...< NRf+> Example: It sets the current table of IV Curve data. IVCurve:IT <I1>,<I2>,...<I128> Query Syntax: IVCurve:IT? Return Parameter: <NRf+>,...,<NRf+> Query Example: IVCurve:IT? Return Example: <I1>,<I1>,...<I128>...
  • Page 210 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 11. IVCurve:SEQuence Description: It sets all parameters for a Sequence in the IV-Program. Syntax: IVCurve:SEQuence <arg1><,><arg2><,><arg3><,><arg4> Parameter: Arg1: Sequence Number (NR1: 1~100) Arg2: Sequence TYPE (NR1 0:Auto , 1:Manual )
  • Page 211 Remote Operation 14. IVCurve:CONFigure:FILTer Description: It sets the IV-Curve measurement signal which is the cutoff frequency (unit: Hz) of input filter. Syntax: IVCurve:CONFigure: FILTer <NR1> Query Syntax: IVCurve:CONFigure: FILTer? Return Parameter: <NR1> Example: IVC:CONF:FILT 1000 (It sets the input filter in IV-Curve mode to1000Hz.) Query Example: IVC:CONF:FILT? Return Example:...

  • Page 212: Sas Subsystem

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 5.6.2.8 SAS Subsystem SAS:VOC Description: It sets the VOC in SAS Mode. Syntax: SAS:VOC <NRf+> Example: It changes the VOC of SAS to 600.0 V. SAS:VOC 600...
  • Page 213 Remote Operation Example: SAS:VOC 600 SAS:ISC 8 SAS:IMPp 5 SAS:VMPp 400 TRIG SAS:PMPp Description: It sets the PMPp in EN50530 Mode. Syntax: SAS:VMPp <NRf+> Example: It changes the PMPp of SAS to 1500.0 W. SAS:PMPp 1500 Query Syntax: SAS:PMPp ? Return Parameter: <NRf+>...
  • Page 214 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Query Syntax: SAS:SANDIA:IRRREF? Return Parameter: <NR1> Query Example: SAS:SANDIA:IRRREF Return Example: 1000 SAS:SANDIA:TMPREF Description: It sets the temperature reference in SANDIA Mode. Syntax: SAS:SANDIA:TMPREF <NRf+> Parameter: <NRf+>...

  • Page 215: Output Subsystem

    Remote Operation SAS:SANDIA:TMP -100 Query Syntax: SAS:SANDIA:TMP? Return Parameter: <NRf+> Query Example: SAS:SANDIA:TMP? Return Example: -1.000000e+02 SAS:SANDIA:PMPp Description: It sets the PMPp in SANDIA Mode. Syntax: SAS:SANDIA:VMPp <NRf+> Example: It changes the PMPp of SANDIA to 1500.0 W. SAS:SANDIA:PMPp 1500 Query Syntax: SAS:SANDIA:PMPp? Return Parameter: <NRf+>...
  • Page 216 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual IVCurve:SELect <NR1> OUTPut ON 5-50...

  • Page 217: 5.6.2.10 System Subsystem

    Remote Operation 5.6.2.10 SYSTEM Subsystem SYSTem:ERRor? Description: It returns the error message and code of Power Supply. Query Syntax: SYSTem:ERRor? Query Example: SYST:ERR? -203, “Data out of range” Return Example: Table 5-9 Code Error Message Code Error Message "No error" -101 "Invalid character"...

  • Page 219: Theory Of Operation

    Overview The 62000H Series DC Power Supply with Solar Array Simulation has A, C, D, E, F, G, H, I, K, L, NO, R, S, U, Y, YE, YG, Z a total of 18 circuit boards (62150H for example) as listed below.
  • Page 220 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Figure 6-2 shows the input stage structure. V_DCBUS STAGE EMI Filter GND_DCBUS Auxiliary Power +5VD +16VD +18V2 GND2 +12VO -12VO (Fan Power) 220V INPUT: Capacitor in Parallel...

  • Page 221: Function Description

    Theory of Operation Figure 6-4 shows the digital stage structure. K Board U Board RS232/RS485 Keyboard USB,System BUS G Board GPIB D Board Ethernet Isolated APG Z Board Fan signal +5VD +1.26VD Linear +1.2VD Regulator A Board DGND +3.3VD AC_Fault signal C Board Driver signal FPGA...

  • Page 222: Auxiliary Power

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 6.2.2 Auxiliary Power The auxiliary power is the AC source input goes through the bridge rectifier and passes the flyback converter to get the desired output voltage.

  • Page 223: Ethernet Functions (62020H-150S Only)

    ETHERNET Functions (62020H-150S Only) ETHERNET Functions (62020H-150S Only) Usage of Web Page 7.1.1 Home Page (index.html) (1) LOGO display area. (2) Function page switch area for switching Configuration, Soft Panel and SCPI 3 pages. (3) Functions setting area that can set the associate function buttons and messages based the page selected.

  • Page 224: Configuration Page

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 7.1.2 Configuration Page When in Configuration page, the present network configuration will be read automatically and displayed on the message block [1]. (1) Message block [1]: It displays the network configuration for editing. The IP address, Subnet mask, Default Gateway and DNS Server(s) are defined by TCP/IP Configuration Mode for editing.
  • Page 225 ETHERNET Functions (62020H-150S Only) A message window will prompt as shown below after entered the password correctly. Click OK and LAN Configuration Initialize button again, a confirmation window will appear as shown below. Click OK to start the initialization. A “Please wait 10 seconds.” message will appear during initialization. After waited for 10 seconds, close the web browser and reconnect it.

  • Page 226: Soft Panel

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 7.1.3 Soft Panel (6) (7) (4) (5) The Soft Panel simulates the actual device panel functions that 7 commands interfaces are provided for setting. If there is a system password, a window will prompt to request for the password.

  • Page 227: Scpi

    ETHERNET Functions (62020H-150S Only) 7.1.4 SCPI The SCPI sends the command strings to the device to activate the function. See the device user’s manual for the associate commands. (1) SCPI command: The command input area. (2) Send (password required): It sends the command strings to the device to activate the function.

  • Page 228: 62020H-150S Ethernet Simple Operation

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 62020H-150S ETHERNET Simple Operation 7.2.1 ETHERNET SETUP Page Power on the DC Power Supply and wait for a few seconds to enter into the MAIN PAGE.

  • Page 229: Power Indicator & Mac Address Display

    ETHERNET Functions (62020H-150S Only) 7.2.2 Power Indicator & MAC Address Display Continue to press ↓→ in ETHERNET CONFIG 1/2 page to skip the setting items to ETHERNET CONFIG 2/2 page. This page shows the Power Status and MAC address. Press ←↑ to return to ETHERNET CONFIG 1/2 page. LAN Configuration Initialize (LCI) Function Continue to press ↓→...

  • Page 230: Ip Settings

    Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual 7.3.1 IP Settings The IP settings can be changed in ETHERNET CONFIG 1/2 page. The settings of each item can be adjusted by the rotary knob and the←↑ ↓→ keys can be used to switch the item desired for modification.

  • Page 231: Self Test & Troubleshooting

    Follow the actions described in this chapter to inspect the instrument and troubleshoot the problem first when the 62000H Series DC Power Supply with Solar Array Simulation is unable to operate normally. Please consult the sales agent or distributor if the information provided in this manual is unable to resolve the problem.
  • Page 232 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual Problem Cause Resolution 2. The current sharing cable sales agent for further is not connected when assistance. used in parallel. 3. The current sharing cable is connected when used in standalone mode.

  • Page 233: Appendix Aapg & System Status Pin Assignment

    Appendix A APG & System Status Pin Assignment Appendix A APG & System Status Pin Assignment The 25-pin connector is located at rear panel in green as shown in Figure A-1. Figure A-1 PIN NO. PIN Definition PIN NO. PIN Definition +12VAPI APIGND AVO_SET_R...
  • Page 234 Programmable DC Power Supply (with Solar Array Simulation) 62000H Series Operating & Programming Manual (12) PIN 12: N.C. (13) PIN 13: DGND. (14) PIN 14: APIGND, +12V auxiliary power ground potential for APG only, see section 3.3.1.1 for detail description.

  • Page 235: Appendix B List Of Protection

    Appendix B List of Protection Appendix B List of Protection Protection Message on Panel Protection Message on Panel Over voltage protect OVP Input voltage AC FAULT abnormal protect Over current protect OCP Remote sense SENSE FAULT abnormal protect Over power protect CV TO CC mode CV TO CC FOLDBACK change protect...
  • Page 236 66 Huaya 1st Road, Guishan, Taoyuan 33383, Taiwan 台灣桃園市 33383 龜山區 華亞一路 66 號 T +886-3-327-9999 F +886-3-327-8898 Mail: info@chromaate.com http://www.chromaate.com Copyright by CHROMA ATE INC. All Rights Reserved. All other trade names referenced are the properties of their respective companies.

Table of Contents

Save PDF
