Parts List - Outback Spectrum Flamer Assembly And Operating Instructions Manual

A. Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more
details on hardware, please see 'Hardware Reference Diagram'.
CODE
BODY
TROLLEY
HARDWARE
Pre-Assembled Component
PART
A1 Grill Lifting Handle
A2 Cast Iron Grill
A3 Charcoal Basket Handle
A4 Charcoal Basket
A5 Barbecue Body
A6 Front Panel
A7 Ash Tray Handle
A8 Ash Tray
B1 Side Shelf
B2 Front Left Leg
B3 Rear Left Leg
B4 Front Right Leg
B5 Rear Right Leg
B6 Leg Endcap
B7 Wheel
B8 Hubcap
B9 Axle
B10 Trolley Base
C1 Trolley Bolt
C2 Body Support Bolt
C3 Spacer
C4 Wing Nut
C5 Washer
C6 Locknut
QTY
2
2
2
1
1
1
1
1
2
1
1
1
1
2
2
2
1
1
24
8
8
8
2
2
2
Outback®
Spectrum Flamer
