Assembly and Operating Instructions for Outback®
MS4461-6
Photographs are not to scale.
Specifications subject to change
without prior notice.







WARNING


FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Senator 4 and 6 Burner Gas BBQ
For outdoor use only. Not for commercial use.
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young children and pets away.
Do not move the appliance during use.
Turn off the gas supply at the gas bottle after use.
Any modification of the appliance, misuse, or failure to follow the instructions may be
dangerous and will invalidate your warranty. This does not affect your statutory rights.
Retain these instructions for future reference.
Leak test annually, and whenever the gas bottle is removed or replaced. Check that the
hose connections are tight and leak test each time you reconnect the gas bottle.
For Flare-up control please refer to the 'OPERATION' section of this manual.
MS5661-6
FOR YOUR SAFETY
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

loading
Need help?

Need help?

Do you have a question about the Senator 4 and is the answer not in the manual?

Questions and answers

Related Manuals for Outback Senator 4

Summary of Contents for Outback Senator 4

  • Page 1 Assembly and Operating Instructions for Outback® Senator 4 and 6 Burner Gas BBQ MS4461-6 MS5661-6 Photographs are not to scale. Specifications subject to change 0359 without prior notice.  For outdoor use only. Not for commercial use.  Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.

  • Page 2: Parts List

    Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram’. Outback® Outback® CODE PART Senator 4 Burner Senator 6 Burner Gas BBQ Gas BBQ Hood (Pre-Assembled to Body) ...

  • Page 3: Parts Diagrams

    Parts Diagrams Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see hardware pack page.
  • Page 4 Hardware Reference Diagram Specifications subject to change without prior notice.
  • Page 5 Assembly IMPORTANT! TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver,  adjustable spanner or metric spanner set. Remove any internal components or packaging from the barbecue body.  Whilst every care is taken in the manufacture of this product, care must be taken during assembly in ...
  • Page 6 ① ② Step Step Unscrew the Locknut (C23x2pcs) from both ends of the Axle (C20). Insert the axle through the corresponding holes in the left legs, then slide one Wheel (C21) over each end of the axle. Secure the wheels into place with the locknuts. Place the Hubcap (C22) onto the outside of the wheels.
  • Page 7 FRONT REAR FRONT REAR Attach the Drip Tray Left Bracket (B11) to the left legs using ST4.0x10 Screws (D1x2pcs) as shown. Repeat above process for Drip Tray Right Bracket (B12). NOTE: Please make sure that before and after installing drip tray bracket position such as enlarge figure.
  • Page 8 Attach the Magnet (C19) onto the bottom panel and upper support using M4x15 Bolts (D3x4pcs), Washer (D4x4pcs) and M4 Nuts (D5x4pcs) as shown. ① ② Step Step Fit the Left Door (C14) and Right Door (C15) to the cabinet by depressing the spring pins and placing into the cabinet, as shown.
  • Page 9 Body supports Carefully place the Barbecue Body (B1) onto the body supports and fix using M6x15 Bolts (D6x4pcs) as shown. WARNING: DO NOT RELEASE THE BARBECUE BODY WHILE THE BARBECUE HAS NOT BEEN PROPERLY SEATED. THIS MAY RESULT IN INJURY OR DAMAGE TO YOUR BARBECUE.
  • Page 10 step1 step2 step3 step4 Attach the side shelf assembly to the barbecue body using ST4.0x10 Screws (D1x2pcs) and M6x15 Bolts (D6x4pcs) as shown. Attach the Tool Hook (C10) onto the Side Shelf (C8) using M6x15 Bolts (D6x2pcs) and M6 Nut (D8x2pcs), as shown.
  • Page 11 step1 step2 step4 step3 Attach the side burner shelf assembly to the barbecue body using ST4.0x10 Screws (D1x2pcs) and M6x15 Bolts (D6x4pcs) as shown.   Correct hose layout diagram Attach the side burner valve and Side Burner Knob Bezel (C5) onto side burner shelf using M4x10 Bolts (D2x2pcs) as shown.
  • Page 12 ① Step ② ③ ④ Step Step Step Unscrew the pre-assembled nut of the Ignition Pushbutton (B13). Insert the ignition pushbutton into the hole at the side burner shelf panel and secure with the pre- assembled nut. Connect the Main Burner Wire (B14) and Side Burner Wire (C7) to the ignition pushbutton as shown.
  • Page 13 Place Side Burner Grid (C3) into the Side burner shelf. Note: Only use cookware with a base diameter of 150-220mm on the side burner. LEFT ① Step ② Step RIGHT ③ Step ④ Step Attach the Warming Rack (A4) to the Hood (A1) and Barbecue Body (B1) as shown. Make sure that the swing legs fix to the body of the barbecue and the shorter fixed legs go through the holes in the hold.
  • Page 14 Remove the retaining bolts from Drip Tray Handle (B9), and then attach it onto the Drip Tray (B10) using the retaining bolts. Insert the Drip Trap (B10) by sliding it underneath the barbecue body. MS4461-6 MS5661-6...

  • Page 15: Leak Testing

    Leak Test Diagram 1. Maximum diameter or breadth is 320mm. 2. Maximum height (regulator included) is 700mm. ASSEMBLY IS NOW COMPLETE. PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON OPERATION AND MAINTENANCE ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BARBECUE.
  • Page 16 Important Information to detect any gas leaking from joints and connections of the barbecue after assembly. Please read these instructions carefully  Leak test annually, and whenever the gas before assembly and use of your barbecue. bottle is removed or replaced. ...

  • Page 17: Installation

    Installation Preparation Before Cooking To prevent foods from sticking to the cooking surface, please use a long handled brush to Selecting a Location apply a light coat of cooking or vegetable oil This barbecue is for outdoor use only and before each barbecuing session.
  • Page 18  Insert lit match through the right match- lost every time the hood is opened. If the hood is opened during cooking please allow extra lighting hole on the right side of the time for the barbecue to regain its temperature barbecue body and place near rightmost and complete the cooking.

  • Page 19: Care And Maintenance

    it out. The time between cleaning may need to the winter months. Heavy-duty barbecue covers be reduced if very fatty foods or cheap meat and other accessories are available from your products are being cooked. Failure to do this local stockist. may result in a fat fire, which may cause injury and could seriously damage the barbecue.
  • Page 20 Drip Tray Fixings After every use, empty and clean the drip tray All screws and bolts, etc. should be checked (and foil liner, if applicable) of any fat or food and tightened on a regular basis. particles, using a plastic or wooden scraper if necessary.

  • Page 21: Technical Specifications

    0.84mm Burner Propane: 37mbar Gas Consumption: Outback® Senator 4 Burner Gas BBQ: 943g/hr Outback® Senator 6 Burner Gas BBQ: 1258g/hr Side Burner: 214g/hr Countries of Use: BE, CH, CY, CZ, ES, FR, GB, GR, IE, IT, LT, LU, LV, PT, SK, 3+ (28-30/37) Specifications are subject to change without prior notice.

  • Page 22: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Burner will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets or gas hose Clean jets and gas hose Electrode or ignition button wire is loose Reconnect wire...
  • Page 23 Other parts are warranted for a period of one (1) year from the date of purchase.  OUTBACK® will, within above periods, supply replacements for defective parts free of charge provided that: The product has not been used for trade, professional or hire purposes.
