Step 5
Use assembly parts to fix HDD with the bracket.
1.
HDD Bracket x1
2.
2.5 inch Hard-disk
3.
Screw x 4
4.
Assembly the HDD with the bracket.
ATTENTION Please follow the direction of Hard-disk installation.
"Hard-disk PCB facesup".
Hardware Installation
IFO2175-830 Series Panel PC User's Manual
15
