- Page 1 MSE PSE-SW3G 3 Port PoE Switch & Extender (Repeat Ethernet and PoE) USER’S MANUAL MSTRONIC CO., LTD.
-
Page 2: Table Of Contents
User’s Manual MSE PSE-SW3 series 1. General Information.............. 2. Hardware Description............LED Indicators..................Power Wiring ..................Ethernet Port Wiring................PD Port Wiring..................Network Application……………………………………......3. Model Information............4. Technical Specification............MSTRONIC CO., LTD. -
Page 3: General Information
Installation of the PoE switch is very easy and you will begin to operate as soon as you are powered 2. Hardware Description *LED Indicator There are 8 LEDs on the PoE switch to indicate the status of power and signal. The following section describes the functions of each LED indicator. Front panel detail MSTRONIC CO., LTD. - Page 4 1000Mbps. Yellow A network device is detected (10Mbps or 100Mbps), but no communication activity is detected. Yellow This port is transmitting to, or receiving Blinking package from another device at 10Mbps or 100Mbps. No device is detected. MSTRONIC CO., LTD.
-
Page 5: Power Wiring
* Data pair A on line 1 and 2 * Data pair B on line 3 and 6 * Data pair C plus V+ on line 4 and 5 * Data pair D plus V- on line 7 and 8 MSTRONIC CO., LTD. - Page 6 If the PSE-SW3G42CN is not powered in above designated input voltage, it will only functioning as an Ethernet switch without PoE output. For full load operation, make sure your power supply may offer 60W for 2x 24V/1A PoE ports. MSTRONIC CO., LTD.
- Page 7 No input (regulated) 24VDC PSE-SW3G42CN No input 42-57VDC (regulated) 24VDC 36-57VDC 42-57VDC (regulated) 42-57VDC 42-57VDC No input (As input voltage) (non-regulated) 42-57VDC PSE-SW3G44DN No input 42-57VDC (As input voltage) (non-regulated) Higher voltage 42-57VDC 42-57VDC output (REAR or UPLINK) MSTRONIC CO., LTD.
-
Page 8: Ethernet Port Wiring
Straight-through Cabling Pin 1 Pin 1 Pin 2 Pin 2 Pin 3 Pin 3 Pin 6 Pin 6 Pin 4 Pin 4 Pin 5 Pin 5 Pin 7 Pin 7 Pin 8 Pin 8 MSTRONIC CO., LTD. - Page 9 If a port LED is off, go back and check for connectivity problems between that port and the network device connected. The maximum cable length for 10/100/1000BaseT with Cat 5 twisted pair cables is typically 100m (328 ft.). MSTRONIC CO., LTD.
-
Page 10: Pd Port Wiring
DC power to PD. The yellow PoE LED will light up when the cable is correctly connected. Refer to the LED Indicator section for descriptions of each LED indicator. If a port LED is off, go back and check for connectivity problems between that port and the network device connected. MSTRONIC CO., LTD. -
Page 11: Network Application
IEEE 802.3af/at standard in the network. The PoE Switch can be installed in a more appropriate position for better performance to extend Ethernet to 200 meters. The following figure is an example of a network application for PoE Switch. MSTRONIC CO., LTD. -
Page 12: Model Information
Isolated (REAR) (UP LINK) 12-57VDC PSE-SW3G11CN 12-57VDC 12-57VDC (non-regulated) 24VDC PSE-SW3G42CN 36-57VDC 42-57VDC (regulated) 42-57VDC PSE-SW3G44DN 42-57VDC 42-57VDC (non-regulated) AC/DC Adapter (Option) MS-A150-18 MS-A150-24 MS-A150-48 Maximum output 18VDC/7.5A 24VDC/6.25A 48VDC/3.125A PSE-SW3G11CN PSE-SW3G11CN PSE-SW3G11CN Related model PSE-SW3G42CN PSE-SW3G44DN MSTRONIC CO., LTD. -
Page 13: Technical Specification
V+(4,5),data pair D plus V-(7,8) Port 3(UPLINK), 4 pairs PD (PSE-SW3G42CN, PSE-SW3G44DN) Maximum PoE power Port 1&2:PSE-SW3G44DN--- IEEE802.3af (16.8W),IEEE802.3at(35W) PSE-SW3G11CN--- Current limited – 2A PSE-SW3G42CN---24V/1A Port 3(UPLINK): 90W (802.3at 2 event classification) PSE disconnect mode DC disconnect MSTRONIC CO., LTD. - Page 14 0.190A 0.104A 0.104A 0.104A 0.061A 0.061A 0.061A 0.056A 0.056A 0.056A Power efficiency 80% at full load (@48V typical) Operating temperature -20℃~+70℃ Operation humidity 90% relative humidity, non-condensing Storage temperature -40℃~+85℃ Dimension 40mm(H)x118mm(W)x90mm(D) available for DIN RAIL Mounted MSTRONIC CO., LTD.
