MSTRONIC PSE-SW8 series User Manual

Pse-sw8 series 8 port poe switch (endspan) (extend ethernet and poe)
Hide thumbs Also See for PSE-SW8 series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
PSE-SW8 series
8 Port PoE Switch (Endspan)
(Extend Ethernet and PoE)
USER'S MANUAL
MSTRONIC CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSE-SW8 series and is the answer not in the manual?

Questions and answers

Related Manuals for MSTRONIC PSE-SW8 series

Summary of Contents for MSTRONIC PSE-SW8 series

  • Page 1 PSE-SW8 series 8 Port PoE Switch (Endspan) (Extend Ethernet and PoE) USER’S MANUAL MSTRONIC CO., LTD.

  • Page 2: Table Of Contents

    User’s Manual MSE PSE-SW8 Series 1. General Information.............. 2. Hardware Description............LED Indicators..................Power Wiring ..................Ethernet Port/PD Port Wiring……………………………………………… 3. Network Application……………………………………………. 4. Technical Specification............MSTRONIC CO., LTD.

  • Page 3: General Information

    User’s Manual MSE PSE-SW8 Series 1. General Information The PSE-SW8 POE Switch family provides a PoE/Data input port that is compatible with 802.3af and 802.3at (Type 1 and Type 2) and it has seven 10M/100M TX ports with PoE PSE function. In...
  • Page 4 User’s Manual MSE PSE-SW8 Series *PWR Indicator STATUS Description Power Green LED ON if power input has valid power supplied. (via the terminal block on rear panel or Port 8 on front panel) LED ON if the following condition happens.

  • Page 5: Power Wiring

    User’s Manual MSE PSE-SW8 Series *PoE indicator (the left LED on RJ45) STATUS Description P1~P7 Yellow LED ON when PoE power output. PoE PSE No PoE output Yellow 4 pairs power source receive. PoE PD Yellow 2 pairs power source receive.
  • Page 6 User’s Manual MSE PSE-SW8 Series The output of PSE-SW8S, the output voltage is the same as input voltage, non- regulated, maximum 2A/port, The output voltage of PSE-SW8D is the same as the higher voltage between rear terminal and port 8, non-regulated, maximum 35W/port.

  • Page 7: Ethernet Port/Pd Port Wiring

    User’s Manual MSE PSE-SW8 Series *Ethernet Port/PD Port Wiring The PoE Switch supports Port 1 to Port 8 with automatic MDI/MDI-X crossover, autosense of the speed and duplex for 10Base-T or 100Base-TX connections. Automatic MDI/MDI-X crossover allows you to connect to other devices (switches, hubs, or workstations etc.), without regard to using straight-through or crossover cabling.

  • Page 8: Network Application

    User’s Manual MSE PSE-SW8 Series LED Indicator section for descriptions of each LED indicator. If a port LED is off, go back and check for connectivity problems between that port and the network device it is connected to. The maximum cable length for 10/100BaseT with Cat 5 twisted pair cables is typically 100 meters (328 ft.).

  • Page 9: Model Information

    User’s Manual MSE PSE-SW8 Series 3. Model Information Input Voltage Input Voltage Model Output voltage (REAR) (Port 8) 12-57VDC (As input voltage) PSE-SW8S 12-57VDC No Input (non-regulated) (non-802.3at compliant) Higher input voltage 42.5-57VDC (As input voltage) PSE-SW8D 40-57VDC (802.3at compliant) (non-regulated) (802.3at compliant)
  • Page 10 User’s Manual MSE PSE-SW8 Series Connect RJ-45 PoE port Port 1-7, Pin assignment: TX(1,2), RX(3,6), V+(4,5), V-(7,8) Port 8, 4 pairs PD Maximum PoE power Port 1-7: 2 A per port with 12-57V input power supply, 10 A Maximum total power Port 8: 90W (802.3at 2 event classification)

This manual is also suitable for:

Pse-sw8sPse-sw8d

Table of Contents
