MSTRONIC PSE-SW5B15DBHM-IP66 User Manual

Ip66 waterproof 5 port poe switch & extender
Hide thumbs

Advertisement

Quick Links

Download this manual
PSE-SW5B15DBHM-IP66
IP66 Waterproof
5 Port PoE Switch & Extender
(Repeat Ethernet and PoE)
USER'S MANUAL
MSTRONIC CO., LTD.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PSE-SW5B15DBHM-IP66 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MSTRONIC PSE-SW5B15DBHM-IP66

Summary of Contents for MSTRONIC PSE-SW5B15DBHM-IP66

  • Page 1 PSE-SW5B15DBHM-IP66 IP66 Waterproof 5 Port PoE Switch & Extender (Repeat Ethernet and PoE) USER’S MANUAL MSTRONIC CO., LTD.

  • Page 2: General Information

    LED indicator. Front panel detail *POWER LED STATUS Description Power Green LED ON when power input (DC IN on rear panel or UPLINK on front panel) has valid power supplied. No power supplied. MSTRONIC CO., LTD.
  • Page 3 Powered from another PoE, UPLINK (P5) Powered via all 4 pairs. PoE In Yellow Powered via 2 pairs, data pairs (pin 1,2,3,6) or Blinking spare pairs (pin 4,5,7,8) are all acceptable. No power is detected on this port. MSTRONIC CO., LTD.
  • Page 4 * Data pair A plus V+ /V- on line 1 and 2 * Data pair B plus V-/V+ on line 3 and 6 * Data pair C plus V+/V- on line 4 and 5 * Data pair D plus V-/V+ on line 7 and 8 MSTRONIC CO., LTD.
  • Page 5 4 pairs or 2 pairs PoE. The following tables describe the wiring diagram of straight-through and crossover cabling. The crossover cables simply cross-connect the transmit lines at each end to the receive lines at the opposite end. MSTRONIC CO., LTD.
  • Page 6 If a port LED is off, go back and check for connectivity problems between that port and the network device connected. The maximum cable length for 10/100/1000BaseT with Cat 5 twisted pair cables is typically 100m (328 ft.). MSTRONIC CO., LTD.
  • Page 7 DC power to the PD. The yellow PoE LED will light up when the cable is correctly connected. Refer to the LED Indicator section for descriptions of each LED indicator. If a port LED is off, go back and check for connectivity problems between that port and the network device connected. MSTRONIC CO., LTD.
  • Page 8 IEEE 802.3af/at/bt standard in the network. The PoE Switch can be installed as a PoE+Ethernet repeater to extend Ethernet to 200 meters. The following figure is an example of a network application for the PoE Extender. MSTRONIC CO., LTD.

  • Page 9: Technical Specifications

    PoE power Output Max. from Port 5: af–16.8W x4 / at–35W x2 / bt–60W(Type3) x1 (total:71W) from rear terminal : at–35W x4 or bt–75W x2 (total:150W) PoE power Input(Port 5) Active: 71W min. for system, Current limited –1.62A@44-57V (compliant to 802.3af/at/bt classification at 90W PSE input.) Passive: Current limited –2.0Amax.@44-57V MSTRONIC CO., LTD.
  • Page 10 291mA/3.492W 140mA/3.36W 67.2mA/3.226W Power efficiency 85% at full load (@24V typical) Operating temperature -20℃~ +70℃ Operation humidity 90% relative humidity, non-condensing with conformal coating Storage temperature -40℃~+85℃ Dimension 207mm(H)x268mm(W)x88mm(D) With 6” hose clamp for light pole mounting MSTRONIC CO., LTD.
  • Page 11 User’s Manual PSE-SW5B15DBHM *Surge Protection on data pairs MSTRONIC CO., LTD.
  • Page 12 User’s Manual PSE-SW5B15DBHM IP class: IP66, anti-UV MSTRONIC CO., LTD.
  • Page 13 User’s Manual PSE-SW5B15DBHM MSTRONIC CO., LTD.
  • Page 14 User’s Manual PSE-SW5B15DBHM MSTRONIC CO., LTD.
  • Page 15 User’s Manual PSE-SW5B15DBHM MSTRONIC CO., LTD.
