PSE-SW8 series
8 Port PoE Switch (Endspan)
(Extend Ethernet and PoE)
USER'S MANUAL
MSTRONIC CO., LTD.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PSE-SW8 series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MSTRONIC PSE-SW8 series

  • Page 1 PSE-SW8 series 8 Port PoE Switch (Endspan) (Extend Ethernet and PoE) USER’S MANUAL MSTRONIC CO., LTD.
  • Page 2: Table Of Contents

    User’s Manual MSE PSE-SW8 Series 1. General Information.............. 2. Hardware Description............LED Indicators..................Power Wiring ..................Ethernet Port/PD Port Wiring……………………………………………… 3. Network Application……………………………………………. 4. Model Information..............5. Technical Specification............MSTRONIC CO., LTD.
  • Page 3: General Information

    User’s Manual MSE PSE-SW8 Series 1. General Information The PSE-SW8 PoE Switch family provides a PoE/Data input port that is compatible with 802.3af and 802.3at (Type 1 and Type 2) and it has seven 10M/100M TX ports with PoE PSE function. In addition to the ability to accept 48VDC PoE input on Port 8, the model provides secondary DC wire terminal input for PoE switch operation from 12V to 57VDC.
  • Page 4 User’s Manual MSE PSE-SW8 Series *PWR Indicator STATUS Description Power Green LED ON if power input has valid power supplied. (via the terminal block on rear panel or Port 8 on front panel) LED ON if the following condition happens.
  • Page 5: Power Wiring

    User’s Manual MSE PSE-SW8 Series *PoE indicator (the left LED on RJ45) STATUS Description P1~P7 Yellow LED ON when PoE power output. PoE PSE No PoE output Yellow PSE-SW8D:4 pairs power source receive. PoE PD PSE-SW8S:2 or 4 pairs power source receive.
  • Page 6: Ethernet Port/Pd Port Wiring

    User’s Manual MSE PSE-SW8 Series The Port 8 may get power over the signal pair or spare pairs, the connection as: * Data pair A plus V+ /V- on lines 1 and 2 * Data pair B plus V-/V+ on lines 3 and 6...
  • Page 7 User’s Manual MSE PSE-SW8 Series Port 1 to port 7 also provides PSE function which delivers DC power through the spare pairs (pair 4,5 and pair7,8) to the PD. Port 8 provides PD function that receive power from 4 pairs or 2 pairs Ethernet cable.
  • Page 8: Network Application

    User’s Manual MSE PSE-SW8 Series 3. Network Application The PoE Switch can receive power from PoE midspan and provide power to the PD. It will power 802.3af compliant devices if it is powered at 48VDC although it will not perform the 802.3af handshake with the client device.
  • Page 9: Model Information

    User’s Manual MSE PSE-SW8 Series 4. Model Information Input Voltage Input Voltage Model Output voltage (REAR) (Port 8) 12-57VDC (As input voltage) 12-57VDC No input (non-regulated) (non-802.3at compliant) 12-57VDC (As input voltage) PSE-SW8S No input 12-57VDC (non-regulated) (non-802.3at compliant) Higher input voltage...
  • Page 10: Technical Specification

    User’s Manual MSE PSE-SW8 Series 5. Technical Specifications Standards IEEE802.3/IEEE802.3u standards (10 base-T/100base-T) Ports 8 ports with 7 PoE PSE & 1 PoE PD, supports auto-crossover & auto-polarity Transmission speed 100 Mbps(100base-T),10 Mbps(10base-T) Auto-negotiation Switch technology store-and-forward Protocols CSMA/CD Flow control IEEE802.3x(full-duplex),back pressure(half-duplex)
  • Page 11 User’s Manual MSE PSE-SW8 Series LEDs *Link/Activity (Green ON/ Green Blinking @100Mbps/ Yellow/Yellow Blinking @10Mbps) *PoE (Yellow) port 1-7 ON - PD detect Port 8 PSE-SW8D:ON – 4 pair power, Blinking-2 pair power PSE-SW8S:ON – 2 or 4 pair power...
  • Page 12 User’s Manual MSE PSE-SW8 Series Surge Protection on data pairs (Materials) Signal Operating Voltage Data 5V Clamping Voltage Data 16.5V (@I PP =5A, t p =8/20μs, I/O pin to GND) Peak Pulse Current 20A (tp=8/20μs) Pin Protected 4 pin protected (signal pairs) <3pF (VR = 0V, f = 1MHz, I/O pin to GND)
