- Page 1 PSE-SW5B44DB 5 Port PoE Switch & Extender (Repeat Ethernet and PoE) USER’S MANUAL MSTRONIC CO., LTD.
-
Page 2: General Information
PSE-SW5B44DB 1. General Information The PoE (Power Over Ethernet) Switch PSE-SW5B44DB provide four 10M/100M/1000M TX ports with PoE PSE(BT) function plus one 10M/100M/1000M TX up-link port with PoE PD function. It allows to be powered from PoE power souring equipment (PSE) and deliver power to PoE powered device (PD), which are compliant with IEEE802.3af ,IEEE802.3at and IEEE802.3bt standard to... - Page 3 Blanking power via 2 data pairs on this port. No PD is detected on this port. Yellow Power via another PoE PSE(2 data pairs or 4 data pairs) UPLINK (P5) No power is detected on this port. MSTRONIC CO., LTD.
- Page 4 802.3bt type 4 operation, the input voltage range must in 53V to 57VDC. The PoE switch PSE-SW5B44DB allow powered by another PoE source on port 5 (UPLINK) as a PoE repeater or extender. From port 5 (UPLINK) input can get up to 71W (802.3bt Type 4 PD).
- Page 5 Straight-through Cabling Pin 1 Pin 1 Pin 2 Pin 2 Pin 3 Pin 3 Pin 6 Pin 6 Pin 4 Pin 4 Pin 5 Pin 5 Pin 7 Pin 7 Pin 8 Pin 8 MSTRONIC CO., LTD.
- Page 6 Ethernet cable. The PoE switch follows the IEEE802.3af Alternative A(MDI-X) + B mode connector assignment. The following table shows pin assignment of alternative A and B for the Power Source Equipment. MSTRONIC CO., LTD.
- Page 7 IEEE 802.3af/at/bt standard in the network. The PoE Switch can be installed in a more appropriate position for better performance to extend Ethernet to 200 meters. The following figure is an example of a network application for the PoE Switch. MSTRONIC CO., LTD.
- Page 8 User’s Manual PSE-SW5B44DB Application: MSTRONIC CO., LTD.
-
Page 9: Technical Specifications
※ Maximum PoE power Please refer the description of *Power wiring part. (page.4) (PSE) Port 1-4: IEEE802.3af – 16.8W IEEE802.3at – 35W IEEE802.3bt class 8 – 90W (PD) Port 5: 71W (802.3bt) PSE disconnect mode DC disconnect MSTRONIC CO., LTD. - Page 10 Port 5 (UPLINK) from network switch or midspan, or optional DC power supply. Power consumption less than 5W when without PD loading Operating temperature -20℃~ +70℃ Operation humidity 90% relative humidity, non-condensing Storage temperature -40℃~+85℃ Dimension 40mm(H)x118mm(W)x150mm(D) DIN RAIL Mountable MSTRONIC CO., LTD.
