. 2. Hardware Description *LED Indicator There are 12 LEDs on the PoE switch to indicate the status of power and signal. The following section describes the functions of each LED indicator. Front panel detail MSTRONIC CO., LTD.
Page 3
10Mbps or 100Mbps. No device is detected. *PoE LED (the left indicator on RJ45) P1~P4 Yellow A valid Powered Device (PD) is detected and PoE Out delivering power on this port. No PD is detected on this port. MSTRONIC CO., LTD.
Page 4
For PoE operation, total output is 35W (802.3at) x 2 or 17W (802.3af) x 4. Please note that the full load output is only when using 24VDC (or above) input voltage. If your input is 12VDC, then the total load should be de-rated. Ports 1~4 will deliver DC power over the Ethernet cable as detailed below: MSTRONIC CO., LTD.
Page 5
When you connect both green connector and DIN 4P connector, the higher voltage source takes priority. *Ethernet Port Wiring The PoE switch family supports one RJ-45 uplink (port 5 with PoE PD) and four RJ-45 ports (port 1~4 with PoE PSE) with automatic MDI/MDI-X crossover, auto-sense for speed and duplex for MSTRONIC CO., LTD.
Page 6
Pin 4 Pin 8 Pin 5 Connect an Ethernet cable into any switch port and connect the other side to your attached device. The Link/Act LED (green or yellow) will light up when the cable is correctly MSTRONIC CO., LTD.
Page 7
DC power to the PD. The yellow PoE LED will light up when the cable is correctly connected. Refer to the LED Indicator section for descriptions of each LED indicator. If a port LED is off, go back and check for connectivity problems between that port and the network device connected. MSTRONIC CO., LTD.
Page 8
IEEE 802.3af/at standard in the network. The PoE Switch can be installed as a PoE+Ethernet repeater to extend Ethernet to 200 meters. The following figure is an example of a network application for the PoE Switch. MSTRONIC CO., LTD.
A (1,2), data pair B (3,6), data pair C plus V+(4,5), data pair D plus V-(7,8) Port 5, 4 pairs PD Maximum PoE power Port 1-4: IEEE802.3af – 16.8W IEEE802.3at – 35W Total power – 70W MSTRONIC CO., LTD.
Page 10
PoE source on Port 5 (UPLINK), and/or optional DC power supply on rear terminal. Power consumption less than 5W when without PD loading Input PSE-SW5G25B4 0.340A 0.170A Power efficiency 85% at full load (@24V typical) Operating temperature -30℃~ +70℃ MSTRONIC CO., LTD.
Page 11
IEC COMPATIBILITY (EN61000-4) IEC61000-4-4 (EFT) 40A (5/50ns) IEC61000-4-5 (Lightning) 20A (8/20μs) Operation humidity 90% relative humidity, non-condensing with conformal coating Storage temperature -40℃~+85℃ Dimension 206mm(H)x268mm(W)x88mm(D) With 6” hose clamp for light pole mounting IP class IP66, anti-UV MSTRONIC CO., LTD.
