- Page 1 PSE-SW5G-25B4HM 5 Port PoE Switch & Extender (Repeat Ethernet and PoE) USER’S MANUAL MSTRONIC CO., LTD.
-
Page 2: General Information
LED indicator. Front panel detail *POWER LED STATUS Description Power Green LED ON when power input (DC IN on rear panel or UPLINK on front panel) has valid power supplied. No power supplied. MSTRONIC CO., LTD. - Page 3 Powered from another PoE, UPLINK (P5) Powered via all 4 pairs. PoE In Yellow Powered via 2 pairs, data pairs (pin 1,2,3,6) or Blinking spare pairs (pin 4,5,7,8) are all acceptable. No power is detected on this port. MSTRONIC CO., LTD.
-
Page 4: Power Wiring
* Data pair C plus V+ on line 4 and 5 * Data pair D plus V- on line 7 and 8 Port 5 (UPLINK) may receive DC power over the Ethernet cable, as detailed below: * Data pair A plus V+/V- on line 1 and 2 MSTRONIC CO., LTD. - Page 5 The DIN-4P connector on the rear panel can also be used for power input, you can use an AC/DC adapter with DIN-4P connector directly, recommend 150W adaptor MS-180-24. (OPTION) When you connect both green connector and DIN 4P connector, the higher voltage source takes priority. MSTRONIC CO., LTD.
-
Page 6: Ethernet Port Wiring
Pin 8 Pin 8 Cross-over Cabling Pin 1 Pin 3 Pin 2 Pin 6 Pin 3 Pin 1 Pin 6 Pin 2 Pin 4 Pin 7 Pin 5 Pin 8 Pin 7 Pin 4 Pin 8 Pin 5 MSTRONIC CO., LTD. -
Page 7: Pd Port Wiring
The yellow PoE LED will light up when the cable is correctly connected. Refer to the LED Indicator section for descriptions of each LED indicator. If a port LED is off, go back and check for connectivity problems between that port and the network device connected. MSTRONIC CO., LTD. -
Page 8: Network Application
IEEE 802.3af/at standard in the network. The PoE Switch can be installed as a PoE+Ethernet repeater to extend Ethernet to 200 meters. The following figure is an example of a network application for the PoE Switch. MSTRONIC CO., LTD. -
Page 9: Technical Specifications
C plus V+(4,5), data pair D plus V-(7,8) Port 5, 4 pairs PD Maximum PoE power Port 1-4: IEEE802.3at – 140W OUTPUT (35W/each) @24VDC input 70W OUTPUT (17W/each) @12VDC input Port 5: 90W (802.3at 2 event classification PD) INPUT MSTRONIC CO., LTD. - Page 10 PoE source on Port 5 (UPLINK), and/or optional DC power supply on rear terminal. Power efficiency 85% at full load Operating temperature -40℃~ +70℃ Operation humidity 90% relative humidity, non-condensing Storage temperature -40℃~+85℃ Dimension 40mm(H)x139mm(W)x147mm(D) DIN RAIL Mountable MSTRONIC CO., LTD.
- Page 11 <3pF (VR = 0V, f = 1MHz, I/O pin to GND) Max. Shunt Capacitance < 1.5 pF (VR = 0V, f = 1MHz, Between I/O pins) IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact) IEC COMPATIBILITY (EN61000-4) IEC61000-4-4 (EFT) 40A (5/50ns) IEC61000-4-5 (Lightning) 20A (8/20μs) MSTRONIC CO., LTD.
