Installing the Choke
Copyright © 2007, 2008 AudioNote Kits
www.AudioNoteKits.com
audionotekits@rogers.com
Here, you can see how they look from the underside.
You can see in this picture how the countersunk screws
that are securing the hardware tags under the chassis are
flush with the top of the chassis.
This is important so that we can fit a transformer on top!
Install the CHOKE -165 next.
Thread the wires through the grommet and secure onto the
chassis with an M4 nut and m4 washer on top and a m4
serrated and m4 nut underneath.
Page 11
