General Overview - Audio Note Mono Block 300b/2A3 Instruction Manual

In each kit bag is a parts list that you can check over – let us know if any parts are missing.

General Overview

The general order of the build is as follows:
Install all the transformers on the kit (we will call this the mechanical section).
•
The IEC section where we hook up the IEC inlet and rocker switch.
•
Build the hard-wired power supply followed the filament board.
•
Fit and wire the front insert plate where we will do most of the work out side the chassis.
•
Install the front insert plate in the chassis and complete all of the final inter-wiring and checks.
•
Take your time on the kit build – savor the build experience and do not be in too much of a hurry to turn on your kit!
Feel free to contact us for any questions or even moral support! Best of luck
Regards
Brian Smith and Audio Note Engineering
Copyright © 2007, 2008 AudioNote Kits
www.AudioNoteKits.com
audionotekits@rogers.com
Page 4
