DMX OPERATOR 384

Operation Guide

Joystick Set Up

"Assign Joystick"
(1) Press and hold down the Program button for approximately 2 seconds or until the
PROG indicator in the LED-display flashes. Once the indicator is flashing, record
mode is engaged and you may release the Program button.
(2) Press and hold down the MODE button and then tap the FINE button. The "Assign"
and "Pan" LED's should illuminate.
(3)
Select the fixtures that you wish to assign the "Pan" for by pressing the FIXTURES
# buttons, 1-12, so the selected fixture LED's illuminate.
(4) Press the Tap/Disp button to switch between "PL.XX" & "PH.XX". "PL.XX"
represents the Low Byte or Fine channel, generally listed as the Pan Fine channel
and PH.XX represents the High Byte or Coarse channel, generally listed as the
Pan channel. Set it to "PH.XX" and press and hold down the MODE button and
then tap the SCENE button that corresponds to the Pan channel of your fixture.
For example, if your fixtures Pan channel is 1 then you'd press the SCENE #1
button . Please refer to the fixtures DMX chart. If your fixture includes a pan fine
channel, press the Tap/Disp button so the display reads "PL.XX". Press and hold
down the MODE button and then tap the SCENE button that corresponds to the
Pan Fine channel of your fixture. For example, if your fixtures Pan Fine channel is
2 then you'd press the SCENE #2 button .
(5) Press the BANK UP or DOWN buttons to switch between "TL.XX" & "TH.XX".
"TL.XX" represents the Low Byte or Fine channel, generally listed as the Tilt Fine
channel and TH.XX represents the High Byte or Coarse channel, generally listed
as the Tilt channel. Set it to "TH.XX" and press and hold down the MODE button
and then tap the SCENE button that corresponds to the Tilt channel of your
fixture. For example, if your fixtures Tilt channel is 3 then you'd press the SCENE
#3 button. Please refer to the fixtures DMX chart. If your fixture includes a Tilt
Fine channel,press the Tap/Disp button so the display reads "TL.XX". Press and
hold down the MODE button and then tap the SCENE button that corresponds to
the Tilt Fine channel of your fixture. For example, if your fixtures Pan Fine channel
is 2 then you'd press the SCENE #4 button.
(6) Press and hold down the Program button for approximately 2 seconds or until the
PROG indicator in the LED-display stops flashing. A flashing Blackout indicator in
the LED-display confirms that the controller is out of Program mode.
7
