DMX OPERATOR 384

Scene Playback

1. Manual trigger:
(1) When powered ON, this console defaults to Manual/Blackout mode. All output will
be in a black-out state until the Blackout button is deselected.To determine blackout
status, there is an indicator light in the display that flashes when engaged and OFF
when disengaged. Press the Blackout button so the indicator stops flashing.
(2) Press the Bank UP/DOWN buttons to select the scene bank that contains the
scene that you want to playback.
(3) Press the Scene # button, 1-8, that you want to playback. The selected scene will
engage. Press the same scene # button again to disable the scene or the
Blackout button to bring all output to a blackout state.
(4) Repeat steps 2 & 3 to manually playback additional scenes.
2. Auto trigger:
(1) Press the AUTO/Del button, the Auto Trigger indicator light will illuminate in the
LED-display. This indicates you that you are now in the Auto trigger mode.
(2)
Press the Bank UP/DOWN buttons to select a desired scene bank, 1-30, for
automatic playback. All eight scenes in the selected scene bank will sequence.
(3) At any time, you can adjust the Speed and Fade fader to the adjust your scene
sequence playback state. You can also press the Tap/Disp button twice to
establish a sequence rate. The rate will be determined by the tempo at which
you press the Tap/Disp button. Pressing the Auto/Del button again will disengage
automatic playback mode.
3. Audio trigger:
(1) Press the Music/Rec button, the Audio Trigger indicator light will illuminate in the
LED-display. This indicates you that you are now in the Audio trigger mode.
(2)
Press the Bank UP/DOWN buttons to select a desired scene bank, 1-30, or
a chase # button, 1-12. The selected scene bank or chases will trigger to audio
via the internal microphone or line level input if connected. Pressing the Music/Rec
button again will disengage audio mode.
12
