Ekofires eko 3070 Installation And User Instructions Manual

Fuel effect gas fire
Hide thumbs Also See for eko 3070:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual and Installation Instructions, Instruction and Installation Manual
installation and user instructions
All instructions must be handed to user for safekeeping
Revision A - 06/09
Country(s) of destination - GB/IE
eko 3070
fuel effect gas fire

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eko 3070 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ekofires eko 3070

Summary of Contents for Ekofires eko 3070

  • Page 1 All instructions must be handed to user for safekeeping Revision A - 06/09 Country(s) of destination - GB/IE eko 3070 fuel effect gas fire...

  • Page 2: Installation Instructions

    INSTALLATION INSTRUCTIONS Eko 3070 Preliminary Notes Before Installation This appliance is an Inset Live Fuel Effect appliance that provides radiant warmth utilising the latest type burner technology. The fire is designed to fit various types of fireplaces and natural draught flues as listed in the Installation Requirements.

  • Page 3: Table Of Contents

    Section Contents Page No. Section Contents Page No. Important Notes 11.0 Fitting the Firebox Appliance Data 11.1 Installation by Cable Fixing Kit Installation Requirements Fuel Bed Layout 12.0 Site Requirements 13.0 Fitting the Firefront Debris Collection Space 14.0 Testing and Commissioning Ventilation 14.1 Operating the Appliance...

  • Page 4: Appliance Data

    APPLIANCE DATA Manual Control Gas Group G20 Natural Gas CAT I2H Inlet Pressure 20 mbar (+/- 2.0mbar) Max Energy Input (gross) 8.75 kW Min Energy Input (gross) 3.5 kW Pilot Energy Input (gross) 166 W Setting Pressure (cold) 16.1 mbar (+/- 1.5mbar) Main Injector Burner Stereo size 95 Gas Inlet Connection...

  • Page 5: Site Requirements

    SITE REQUIREMENTS The fireplace opening should be inspected and repairs made where necessary. Any chair brick or fireback may be left in situ, providing that the dimensional requirements for debris collection space and spigot clear- ances are met. See diagram below.. The opening WIDTH and HEIGHT dimensions should be between 470mm and 530mm wide, and 540mm (see note below) to 575mm high.

  • Page 6: Debris Collection Space

    DEBRIS COLLECTION SPACE The mounting depth of this appliance is 180mm. In accordance with BS 5871 part 2, minimum debris collection volumes are required behind the installed appliance. These are shown in the table below and as dimension X on the fireplace diagram shown previ- ously.

  • Page 7: Component Checklist

    COMPONENT CHECKLIST QUANTITY DESCRIPTION Firebox and burner tray assembly Three piece decorative trim Cast firefront Moulded ceramic fibre combustion matrix Left-hand Moulded ceramic front strip Right-hand Moulded ceramic front strip Individual ceramic coals Ceramic ribbed effect radiant panels Ceramic brick panel retaining clips Cable fixing kit;...

  • Page 8: Fitting The Decorative Frame

    FITTING THE DECORATIVE FRAME The appliance is supplied with a decorative frame. The frame attaches as a three piece clip-on assembly. If the firebox is to be retained by the cable method, this is the most convenient stage at which to fit the three piece clip on frame.

  • Page 9: Fitting The Firebox

    10.0 GAS SUPPLY ROUTING (continued) The gas pipe must be suitably protected where it passes through fireplace openings. Any sleeving should be sealed to the pipe at its ends. This appliance is fitted with an inlet restrictor elbow. The open end of the supply pipe should be sealed temporarily during the installation of the firebox to pre- vent the ingress of dirt and dust.

  • Page 10: Fuel Bed Layout

    12.0 FUEL BED LAYOUT Please see the relevant section of the user instructions. 13.0 FITTING THE FIREFRONT Place the decorative firefront in front of the fire and slide the ashpan door into place. The firefront shown in these instruc- tions may be different to the one supplied with the appliance. 13.1 GAS CONNECTION Purge the gas supply thoroughly to remove air and dirt/debris BEFORE connection.

  • Page 11: Testing For Spillage

    14.4 FLUE SPILLAGE MONITORING SYSTEM (continued) The aeration hole of the pilot must be carefully cleaned out on each annual service to ensure continued func- tion of the ODS. The spillage monitoring system shall not be adjusted, modified, or put out of operation by the installer. Any spare parts fitted MUST be of a type supplied for the purpose by the appliance manufacturer.

  • Page 12: Dismantling The Burner Tray

    15.0 SERVICING (continued) 8. Check the fireplace opening for rubble accumulation and remove. If debris is excessive, initiate remedial work on the flue. 9. Check the flue with smoke pellet for correct operation. 10. Refit firebox using new seals where necessary. 11.

  • Page 13: Troubleshooting Guide

    16.0 TROUBLESHOOTING GUIDE Fire sparks but pilot does not light No gas to fire, check isolators are open. Pipework blockage, clean out. Air not fully purged, repurge supply or wait longer. Spark earthing to metal work, reset gap correctly. Blocked pilot, clean out internally. Pilot lights but then goes out Severe restriction in gas supply, clear obstruction.
  • Page 14 USER INSTRUCTIONS Section Contents Page No. Important Notes Firefront Clearances to Combustibles Ventilation Fuel Bed Layout Servicing Operating Instructions Flue Spillage Monitoring System Cleaning 10.0 Cleaning the Ceramics 11.0 List of spare parts IMPORTANT NOTES The installation of this fire MUST only be carried out by a competent person in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards, Codes of Practice, the Building Regulations and the manufacturers’...

  • Page 15: Clearances To Combustibles

    CLEARANCES TO COMBUSTIBLES A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given below. A non-combustible shelf may be fitted to within 10mm of the top edge of the fireframe. Maximum depth of shelf Minimum distance from finished hearth surface to underside of shelf...
  • Page 16 FUEL BED LAYOUT (continued) 3. Locate the two front coal sections marked ‘L’ and ‘R’ into the slot along the front of the burner tray as shown. The legs of the coals have a slightly tapered front face which is intended to give a tight inter- ference fit into the tray.

  • Page 17: Operating Instructions

    SERVICING The fire and flue should be checked on an annual basis to ensure all of the product of combustion are enter- ing the flue and that there is no excessive build up of soot. The frequency of service will depend on usage, but MUST be carried out at least once annually.
