5.6 PC Adjustment

Overview
The PC Adjustment menu allows you to modify the picture quality and the picture position in the PC mode.
Auto Adjustment
Press the button to automatically adjust the H/V position H/V size and phase.
H Position
Use the H Position to adjust the horizontal position of the image on the monitor screen.
V Position
Use the V Position to adjust the vertical position of the image on the monitor screen.
Use the following steps to adjust the picture quality in the PC mode:
Step Action
1 Press or to move the cursor to the desired PC Menu option.
2
Press ( ) to decrease (increase) the value of the selected item.
3 Press MENU to go to the previous OSD window.
Phase
Use Phase to adjust the focus of the display.
This item allows you to remove any horizontal noise and clear or sharpen the image of characters.
Clock
Use Clock to minimize any vertical bars or strips visible on the screen background.
Resolution
PC Menu
Auto Adjustment
H Position
V Position
Phase
Clock
Resolution 1366 x 768
56
