- Page 1 Installation and User's Guide Installation and Operating Instructions 17.0"/19.0" TFT LCD MONITOR VMC-17LCDM VMC-19LEDM All contents of this document may change without prior notice, and actual product appearance may differ from that depicted herein...
-
Page 2: Safety Instruction
Installation and User's Guide 1. SAFETY INSTRUCTION Follow this safety instruction to use the monitor properly and prevent the damage. This safety instruction has “Warning” & “Caution” as below Warning - If the user does not follow this instruction, it may cause the serious damage to the user. Caution - If the user does not follow this instruction, it may cause the slight damage to the user or cause some damages to the monitor. - Page 3 Installation and User's Guide Warning Do not install this monitor on the outside For cleaning do not use liquid cleaners. and near water. It may cause damage to Never touch the power plug with wet-hands. the product, electric shock and fire. When lightning and thundering, unplug the Unplug this product from the wall outlet, when monitor from the wall outlet and never touch...
- Page 4 Installation and User's Guide Cautions Install this monitor some distance Place this product on a stable place. from the wall and do not install unless If not, it may fall, causing serious proper ventilation is provided. damages to the monitor and people. The openings must not be blocked by When carrying this monitor, be careful curtain, rug or other similar surface.
- Page 5 Installation and User's Guide Cautions Install this monitor about 50cm far from Do not press the LCD panel with hands or the eyes and an angle of 0~15 degrees the sharpened material hardly. below eyes. Too close installation may cause having weak sight. For cleaning, unplug the monitor from the Do not use the chemical liquid for cleaning.
-
Page 6: Fcc Statement
Installation and User's Guide 2. FCC RF INTERFERENCE STATEMENT NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 7: Table Of Contents
Installation and User's Guide TABLE OF CONTENTS 1. SAFETY INSTRUCTION 1-1 Warning 1-2 Caution 2. FCC STATEMENT 3. INSTALLATION 3-1 Parts 3-2 How to Install 4. OSD MENU SETTING 4-1 INPUT Select 4-2 MENU Selection 4-3 PICTURE MENU on OSD 4-4 VOLUME MENU on OSD 4-5 SYSTEM MENU on OSD 4-6 FUNCTION MENU on OSD... -
Page 8: Installation
Installation and User's Guide 3. INSTALLATION 3-1 Parts LCD Monitor Adapter VGA Cable Power Cable Battery Remote Controller User Manual... -
Page 9: How To Install
Installation and User's Guide 3-2 How to Install KEY BUTTON SHORT KEY FUNCTION OSD Key Function Activates and exit the OSD Select input source, and select the OSD menu Move the OSD menu and auto adjustment of RGB source Decrease the level of volume and move the previous menu Increase the level of volume and select rhe OSD menu Turns the power ON or OFF. - Page 10 Installation and User's Guide CONNECTION HDMI HDMI signal input VGA (PC RGB) signal input VIDEO-1 IN / OUT VIDEO-2 IN / OUT VIDEO-2 signal input / looping out VIDEO-1 signal input / looping out AUDIO (VIDEO) S-VIDEO Stereo audio input for VIDEO or S-VIDEO S-VIDEO signal input AUDIO (PC) DC12V...
-
Page 11: Mode Select Menu
Installation and User's Guide REMOTE CONTROLLER MODE SELECT MENU VIDEO1 VIDEO2 Select VIDEO1 mode Select VIDEO2 mode S-VIDEO VGA (RGB) Select S-VIDEO mode Select VGA mode POWER MUTE HDMI VIDEO1 VIDEO2 S-VIDEO Select HDMI mode AUTO COLOR TEMP HDMI S.SET SCAN MODE OSD CONTROL MENU VOL-... -
Page 12: Osd Menu Setting
Installation and User's Guide 4. OSD MENU SETTING 4-1 INPUT Select Inputs can be set to AV1, AV2, S-VIDEO, HDMI and PC mode. A V 1 1. Press the SOURCE button and then ▲/▼ Button to move the source A V 2 2. -
Page 13: Picture Menu On Osd
Installation and User's Guide 4-3 PICTURE MENU on OSD 4-3-1 INPUT SOURCE (AV1, AV2, S-VIDEO, HDMI) OSD Menu is working on after it connects the source signal. PIC TURE C o n t r a s t B r i g h t n e s s T i n t C o l o r S h a r p n e s s... -
Page 14: Volume Menu On Osd
Installation and User's Guide 4-3-2 INPUT SOURCE (PC Mode only) P I C TU R E C o n t r a s t B r i g h t n e s s C o l o r To n e A u t o C o l o r A u t o 1. -
Page 15: System Menu On Osd
Installation and User's Guide 4-5 SYSTEM MENU on OSD AV1, AV2, S-VIDEO, PC, HDMI SY STE M SYSTEM Key Lo ck Key Lo ck OF F L an gu age Englis h La nguag e E ngli sh H- P os itio n H-Pos ition V-P o sitio n V-Positio n... -
Page 16: Function Menu On Osd
Installation and User's Guide 4-6 FUNCTION MENU on OSD PC Mode only FUNCTI ON H-Posi tio n V-Po si ti on Clo ck 1 0 0 Ph a se 1 0 0 1. Press the MENU/EXIT Button and then ◄ / ► Button to select the FUNCTION menu. 2. -
Page 17: Features
Installation and User's Guide 5. FEATURE General Features VMC-17LCDM (208374) VNC-19LEDM (208366) Screen Size 17.0 inches 19.0 inches Resolution 1280*1024 pixels 1280*1024 pixels Pixel Pitch 0.264*0.264 mm 0.293*0.293 mm Brightness 250 cd/m^2 250 cd/m^2 Contrast Ratio 800:1 1000:1 Display Aspect Ratio... -
Page 18: Appendix
Installation and User's Guide 6. APPENDIX 6-1 D-SUB Connector PIN Assignment 12 13 14 15 PIN No. PIN Name PIN No. PIN Name RED VIDEO GREEN VIDEO SIGNAL CABLE DETECT BLUE VIDEO GROUND GROUND SDA (for DDC) GROUND H-SYNC RED GROUND V-SYNC GREEN GROUND SCL (for DDC) -
Page 19: Troubleshooting
Installation and User's Guide 7. TROUBLESHOOTING * When the following troubles are occurred, follow the trouble shooting. Before contacting a service center. Troubleshooting Troubleshooting Tip 1. Make sure if the power supply is connected property The screen doesn’t 2. Turn on the power. show up 3. - Page 20 Videor E. Hartig GmbH ® Exclusive distribution through specialised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 · 63322 Rödermark, Germany Tel. +49 (0) 6074 / 888-0 · Fax +49 (0) 6074 / 888-100 www.videor.com...
