- Page 1 Installation and User's Guide Installation and Operating Instructions TFT LCD MONITOR VMC-27LEDM VMC-32LEDM All contents of this document may change without prior notice, and actual product appearance may differ from that depicted herein...
-
Page 2: Table Of Contents
Installation and User's Guide TABLE OF CONTENTS ITEM Page SAFETY INSTRUCTION - WARNING - CAUTION FCC STATEMENT INSTALLATION - PARTS - HOW TO INSTALL OSD MENU SETTING - MENU STRUCTURE - PICTURE MENU - OPTION MENU - INPUT SOURCE - AUDIO VOLUME FEATURES TROUBLESHOOTING... -
Page 3: Safety Instruction
Installation and User's Guide 1.SAFETY INSTRUCTION * Follow this safety instruction to use the monitor properly and prevent the damage. This safety instruction has “Warning” & “Caution” as below Warning - If the user does not follow this instruction, it may cause the serious damage to the user. Caution - If the user does not follow this instruction, it may cause the slight damage to the user or cause some damages to the monitor. - Page 4 Installation and User's Guide Warning 1.SAFETY INSTRUCTIN Do not install this monitor on the For cleaning do not use liquid outside and near water. It may cause cleaners. Never touch the power plug damage to the product, electric shock with wet-hands. and fire.
- Page 5 Installation and User's Guide Cautions 1.SAFETY INSTRUCTIN Install this monitor some distance Place this product on a stable place. from the wall and do not install unless If not, it may fall, causing serious proper ventilation is provided. damages to the monitor and people. The openings must not be blocked by When carrying this monitor, be careful curtain, rug or other similar surface.
- Page 6 Installation and User's Guide Cautions 1.SAFETY INSTRUCTIN Install this monitor about 50cm far Do not press the LCD panel with from the eyes and an angle of 0~15 hands or the sharpened material degrees below eyes. Too close hardly. installation may cause having weak sight.
-
Page 7: Fcc Statement
Installation and User's Guide 2. FCC RF INTERFERENCE STATEMENT NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 8: Installation
Installation and User's Guide 3. INSTALLATION PARTS User Manual VGA Cable LCD Monitor Power Cable Remote Controller Battery Adapter (Only VMC-27LEDM) -
Page 9: How To Install
Installation and User's Guide HOW TO INSTALL 1) KEY BUTTON SHORT KEY FUNCTION OSD Key Function MENU Activate the menu function / Exit from the menu SOURCE / ▼ Input source menu / Source selection(move down from OSD menu) AUTO / ▲ Auto-fit screen with PC-RGB input / move up from OSD menu ◀(VOL) Decrease the level of volume and move the previous menu... - Page 10 Installation and User's Guide 2) CONNECTION <VMC-27LEDM> ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ① ⑥ HDMI 1 DC12V HDMI signal 1 input DC adapter input ② ⑦ HDMI 2 AUDIO(VIDEO-1) HDMI signal 2 input Stereo audio input for VIDEO-1 ③...
- Page 11 Installation and User's Guide 2) CONNECTION <VMC-32LEDM> ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ① ⑥ HDMI 1 AUDIO(VIDEO-1) HDMI signal 1 input Stereo audio input for VIDEO-1 ② ⑦ HDMI 2 AUDIO(VIDEO-2) HDMI signal 2 input Stereo audio input for VIDEO-2 ③...
- Page 12 Installation and User's Guide 2) REMOTE CONTROLLER ■ MODE SELECT MENU VIDEO1 : Select VIDEO1 mode VIDEO2 : Select VIDEO2 mode HDMI1 : Select HDMI1 mode HDMI2 : Select HDMI2 mode VGA (RGB) : Select VGA mode ■ OSD CONTROL MENU POWER : Turn ON / OFF the monitor MUTE : Turn ON / OFF the sound AUTO : Auto adjust position of the screen (in VGA mode)
-
Page 13: Osd Menu Setting
Installation and User's Guide 4. OSD MENU SETTING MENU STRUCTURE When user presses the menu key, the first “PICTURE” menu is displayed. Select by "◀" key then three types of menu functions are shown as below. PICTURE : Menu related to PICTURE Function OPTION : Other OSD Menu Status Control and Firmware Update If press "▲, ▼"... - Page 14 Installation and User's Guide 1) Picture Mode 4. OSD MENU SETTIN Picture Mode can select 4 modes as Mild, Dynamic, Standard and User as shown in the figure below. Press the "◀, ▶" key to change the mode. Three of the four modes except for User mode are shipped with fixed values at the time of shipment from the factory.
- Page 15 Installation and User's Guide 3) Aspect Ratio 4. OSD MENU SETTIN Aspect Ratio allows user to select the each aspect ratio as shown in the figure below. (However, activated list is according to the input port and the input resolution.) 4) Noise Reduction Noise Reduction can select 5 modes as Off, Low, Middle, High, Default as shown in the figure below.
-
Page 16: Option Menu
Installation and User's Guide 6) Color Range 4. OSD MENU SETTIN Color Range sets the range of color expressions on the display. (Press the “▶ SELECT” key to select either”0~255”, “16~235”) OPTION MENU The Option Menu can be selected from the following 6 modes by pressing the ▲ or ▼ key. OSD Language Selectable OSD Menu Language Blending... - Page 17 Installation and User's Guide 1) OSD Language 4. OSD MENU SETTIN As shown in the figure below, OSD Language can be selected by "▲, ▼ " key. 2) Blending OSD Menu Blending can select 4 modes as Off, Low, Middle, High by pressing the “▶ SELECT” key. 3) OsdDuration OSD menu Duration can select 4 modes as 5, 10, 15Sec and Off by pressing the “▶...
-
Page 18: Input Source
Installation and User's Guide 6) Key Lock 4. OSD MENU SETTIN Key lock default can be selected by pressing the "▶ SELECT" key. 7) DPMS The function can be activated(ON) or deactivated(OFF) with the button ▶. INPUT SOURCE Input Source can be selected from the following four input modes by using the ▲ and ▼ keys when the window as shown below is displayed by pressing the "SOURCE / ▼"... -
Page 19: Features
Installation and User's Guide 5. FEATURE VMC-27LEDM VMC-32LEDM Screen Size 27.0 inches 31.55 inches Resolution 1920*1080 1920*1080 Pixel Pitch 0.311*0.311 mm 0.364*0.364 mm Brightness 250 cd/m² 400 cd/m² Contrast Ratio 1000:1 1300:1 Display Aspect Ratio 16:9 16:9 Viewing Angle (H/V) - Page 20 Installation and User's Guide 5. FEATURE Outline Dimension 25.20*16.89*6.30” 28.82*19.14*6.30” Dimension (w Stand) 640*429*160 mm 732*486.3*160 mm Cabinet color/Base Stand Black/Desktop Stand Black/Desktop Stand Cabinet Cabinet Material Electro-Galvanized Steel Electro-Galvanized Steel AC 100~240V Power Electrical Ratings DC 12V, 5A (50/60Hz) Operating Temperature 0~40 celsius 0~40 celsius...
-
Page 21: Troubleshooting
Installation and User's Guide 6. TROUBLESHOOTING * When the following troubles are occurred, follow the trouble shooting. Before contacting service center. Troubleshooting Troubleshooting Tip 1. Make sure if the power supply is connected property The screen doesn’t 2. Turn on the power. show up 3. - Page 22 Installation and User's Guide MEMO...
- Page 23 Installation and User's Guide MEMO...
- Page 24 VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 · 63322 Rödermark, Germany Tel. +49 (0) 6074 / 888-0 · Fax +49 (0) 6074 / 888-100 Technical changes reserved.
