Summary of Contents for Eneo VMC-27LEDM
- Page 1 QUICK MANUAL Installation and Operating Instructions TFT LCD MONITOR VMC-27LEDM VMC-32LEDM...
- Page 2 KEY BUTTON SHORT KEY FUNCTION OSD Key Function MENU Activate the menu function / Exit from the menu SOURCE / ▼ Input source menu / Source selection(move down from OSD menu) AUTO / ▲ Auto-fit screen with PC-RGB input / move up from OSD menu ◀(VOL) Decrease the level of volume and move the previous menu (VOL)▶...
- Page 3 CONNECTION <VMC-27LEDM> ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ① ⑥ HDMI 1 DC12V HDMI signal 1 input DC adapter input ② ⑦ HDMI 2 AUDIO(VIDEO-1) HDMI signal 2 input Stereo audio input for VIDEO-1 ③ ⑧...
- Page 4 CONNECTION <VMC-32LEDM> ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ① ⑥ HDMI 1 AUDIO(VIDEO-1) HDMI signal 1 input Stereo audio input for VIDEO-1 ② ⑦ HDMI 2 AUDIO(VIDEO-2) HDMI signal 2 input Stereo audio input for VIDEO-2 ③...
- Page 5 PICTURE MENU The PICTURE Menu can be selected from the following 7 modes by pressing the ▲ or ▼ key. Picture Mode Adjust sate of the picture Color Temperature Change color according to the color temperature Aspect Ratio Change the aspect ratio Noise Reduction Adjust noise attenuation of input signal Screen...
- Page 6 PICTURE MENU The Option Menu can be selected from the following 6 modes by pressing the ▲ or ▼ key. OSD Language Selectable OSD Menu Language Blending Adjust blending for OSD Menu and Main window OSD Duration Setting Duration time of OSD Menu Restore Factory Default Software Update(USB) Key Lock...
- Page 7 Videor E. Hartig GmbH Exclusive distribution through specialised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 · 63322 Rödermark, Germany Tel. +49 (0) 6074 / 888-0 · Fax +49 (0) 6074 / 888-100 Technical changes reserved.
