- Page 1 QUICK MANUAL Installation and Operating Instructions TFT LCD MONITOR VMC-27LEDM VMC-32LEDM VMC-42LED...
- Page 2 KEY BUTTON SHORT KEY FUNCTION OSD Key Function Activates and exit the OSD Select input source, and select the OSD menu Move the OSD menu and auto adjustment of RGB source Decrease the level of volume and move the previous menu Increase the level of volume and select rhe OSD menu Turns the power ON or OFF.
- Page 3 CONNECTION HDMI AUDIO (VIDEO-1 / S-VIDEO) HDMI signal 1 / 2 input Stereo audio input for VIDEO-1 or S-VIDEO S-VIDEO IN / OUT DVI signal input S-VIDEO signal input / looping out VIDEO-2 IN / OUT VGA (PC RGB) signal input VIDEO-2 signal input / looping out AUDIO (PC) VIDEO-1 IN / OUT...
- Page 4 MODE SETTING INPUT VIDEO1 VIDEO2 VIDEO1 Select VIDEO1 mode Select VIDEO2 mode VIDEO2 S-VIDEO RGB PC S-VIDEO Select S-VIDEO mode Select VGA mode √ RGB PC HDMI1 Select DVI mode Select HDMI1 mode HDMI 1 HDMI2 COMPONENT HDMI 2 Select HDMI2 mode Select COMPONENT mode COMPONENT ▼/▲:MOVE ▶:ENTER...
- Page 5 SCREEN MENU SCAN MODE : Select the scan mode of screen SCREEN PICTURE PIP : Activates PIP/PBP mode ▶ SCAN MODE ◀ FULL ▶ ◀ SCREEN PIP INPUT VIDEO2 ▶ ◀ ▶ PIP SWAP PIP SIZE SMALL ▶ SETUP ◀ ▶...
- Page 6 SETUP MENU INPUT : Select an input source for main screen SETUP PICTURE LANGUAGE : Set to different language mode ▶ INPUT ◀ VIDEO1 ▶ SOUND MUTE : Turn on/off the sound LANGUAGE ◀ ENGLISH SCREEN SOUND MUTE ▶ ◀ BUTTON LOCK : Locking the button ▶...
- Page 7 CYCLE SETUP MENU CYCLE TIME : Adjust cycle time to displayed on CYCLE SETUP PICTURE the screen CYCLE TIME CYCLE : Selected mode keep change continuously ▶ CYCLE ◀ SCREEN VIDEO1 ▶ ◀ ▶ VIDEO2 ◀ S-VIDEO ▶ SETUP ◀ ▶...
- Page 8 VIDEOR E. Hartig GmbH ® Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 • 63322 Rödermark, Germany Tel. +49 (0) 6074 / 888-0 • Fax +49 (0) 6074 / 888-100 www.videor.com...
