EUROCOM R130T Service Manual page 15

Communication
Built-In 10M/100M/100M Base-TX Ethernet LAN
Bluetooth 2.1 + EDR (Enhanced Data Rate)
Module (Factory Option)
Intel® WiFi Link 5300 Series (3*3 - 802.11a/g/
n) Wireless LAN PCIe interface Half Mini-Card
Module (Option)
802.11a/g/n Wireless LAN PCIe interface Half
Mini-Card Module
2.0M Pixel PC Camera Module with USB
interface (Factory Option)
3.75G Module:
UMTS/HSPDA-based 3.75G Module with
Mini-Card Interface (Factory Option)
Quad-band GSM/GPRS (850 MHz, 900 MHz,
1800 MHz, 1900 MHz)
UMTS WCDMA FDD (2100 MHz)
Note that UMTS modes CAN NOT be used
in North America
GPS Module without Internal Antenna
(Factory Option)
Power Management
Supports Wake on LAN
Supports Wake on Modem Ring
Power
Full Range AC/DC Adapter
AC input 100 - 240V, 50 - 60Hz,
DC Output 19V, 3.42A or 18.5V, 3.5A (65
Watts)
4 Cell Smart Lithium-Ion Battery Pack,
2600mAH
8 Cell Smart Lithium-Ion Battery Pack,
5200mAH (Option)
Security
Security (Kensington® Type) Lock Slot
Fingerprint ID Reader Module
BIOS Password
Trusted Platform Module V1.2
Operating System
Windows® Vista (with Service Pack 2)
Windows® XP (with Service Pack 3)
Environmental Spec
Temperature
° °
Operating: 5 C - 35 C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Dimensions & Weight
317mm (w) * 229mm (d) * 35mm (h)
2.0 kg (full system with 1G RAM, 2.5" HDD,
ODD and 4 Cell Battery)
Optional
Super Multi Optical Device Drive
Intel® WiFi Link 5300 Series (3*3 - 802.11a/g/
n) Wireless LAN PCIe interface Half Mini-Card
Module
802.11a/g/n Wireless LAN PCIe interface Half
Mini-Card Module
8 Cell Smart Lithium-Ion Battery Pack,
5200mAH
Bluetooth 2.1 + EDR (Enhanced Data Rate)
Module (Factory Option)
2.0M Pixel PC Camera Module with USB
interface (Factory Option)
UMTS/HSPDA-based 3.75G Module with
Mini-Card Interface (Factory Option)
GPS Module without Internal Antenna
(Factory Option)
System Specifications 1 - 3
Introduction
