Removing The Removable Hard Drive Cage - Compaq SP700 Reference Manual

Removing the Removable Hard
Drive Cage
To remove the removable hard drive cage:
1. Turn off the workstation and disconnect the power cord from the
grounded AC outlet and from the back of the workstation.
2. Remove the side access panel.
3. Refer to the following illustration to remove the removable hard
drive cage.
Figure 6-5.
1
1
2
Loosening the two thumbscrews and removing the removable
hard drive cage
Compaq Professional Workstation SP700 Reference Guide
6-9
