Output Specifications - Analog way SmartMatriX User Manual

Standard Size
1366x768 1366x768
800p RGB 1280x800
SWXGA+ 1366x800
1152x864 1152x864
900p RGB 1440x900
1600x900 1600x900
960p RGB 1280x960
SXGA 1280x1024
1360x1024 1360x1024
DILA4/3 1364x1024
SXGA+ 1400x1050
WSXGA+ 1680x1050
1080p RGB 1920x1080
2K 2048x1080
Q WXGA 2048x1152
UXGA 1600x1200
WUXGA 1920x1200
Note:
1) Reduced Blanking

4.7 Output specifications

4.7.1 Standard output
The SmartMatriX² has two standard outputs.
The standard output contains:
- Analog Computer/Video (HD15),
- HDMI®output over a DVI-I connector or DVI-I output (DVI-Analog and DVI-Digital).
HD-15 3G-SDI
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
1
Yes No
1
Yes No
1
Yes No
1
Yes No
1
VGA
DVI-I
Single-Link
HDMI
DVI-D
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
1 1
Yes Yes
1 1
Yes Yes
1 1
Yes Yes
1 1
Yes Yes
1 1
4.7 Output specifications
19
