4.10 HDCP management
4.10.1 Input HDCP detection
The input HDCP detection is managed by the input components according to HDCP specification.
4.10.2 Output HDCP detection
The SmartMatriX² manages the output HDCP detection according to one of the following criteria:
- Hot plug,
- 3-second period attempt.
4.10.3 Keys' checking
Keys' checking is performed according to the most restrictive condition among the 2 following ones:
- Every 2 seconds
- Every 128 frames
4.10.4 Output management
HDCP protected content can be displayed only on HDCP protected outputs or displays. Therefore, whenever
an HDCP protected source is placed into a layer routed to a non-protected output, the SmartMatriX² will not
output the protected content on this non-protected output, and the layer will be grayed.
If possible, the SmartMatriX² will allow to display all other non-protected contents, otherwise the entire
output will be muted until the protected content is no longer routed.
4.10.5 HDCP Classification
Class
HDCP Receiver
HDCP Transmitter
HDCP Repeater
HDCP Receiver
The HDCP negotiation can be enabled or disabled on all HDCP inputs.
HDCP Transmitter
The HDCP negotiation can be enabled or disabled on all HDCP outputs.
The SmartMatriX² can manage HDCP repeaters on its outputs: up to 32 display devices can authenticate
simultaneously on each output.
4.10.6 Status
In order to permit quick identification of all the HDCP operations on the device, the SmartMatriX² provides a
full set of status summary to help the user with the HDCP management:
- A front panel menu that displays all the general HDCP status of all inputs and outputs
Support
Yes
Yes
No
