7.2.2 Audio
7.2.2 Audio
In this section, you will setup the audio of your device, you have several modes. In all modes, you have the
7.2.3 Screens
In the screen configuration, you will find the state of your screen. It indicates the screen resolution, the
maximum number of layers you can use.
30
possibility to output the audio in AES3 or SPDIF:
NO AUDIO: the audio of your device is switched off
PRESET MODE:
You have two possibilities:
• Top layer: the sound on the output will follow the audio input of the top
layer.
• Breakaway: when breakaway is activated, the audio on the output is
memorized into the preset. A change of preset, changes the audio on the
output. A change of content into a video layer has no effect on the audio.
ROUTING MODE:
assign it to the output. The audio configuration remains the same during
the show.
In this example input1 is on out1 and input 2 is on out 2
You will find configuration for the Quick Frame and the background color too.
The Quick Frame will be your emergency frame that can be displayed in front of
every layer. Here, select the frame slot number to be displayed as the Quick Frame.
With the SmartMatriX², you have 2 screens status.
the standard mode of use of the device
in this configuration, simply choose an audio input to
