5-2. Memory map
00000h
SYSTEM RAM
2Mb x 1
20000h
40000h
RAM 1Mb x 1
60000h
16Mb FLASH ROM
80000h
A0000h
C0000h
E0000h
EP ROM
1Mb
FFFFFh
Option RAM 1Mb
Option RAM 4Mb
2
1
3
4
5
Bank16 contents
— 19 —
VRAM
256Kb x 2
6
Bank16
VRAM
for LCD1
Control area
for LCD1
VRAM
for LCD2
Control area
for LCD2
40000h
48000h
50000h
58000h
