3. Button operation and menu interface
Button
UP
DOWN
ESC
ENTER
The LCD screen became bright for 15 seconds delay after you press any of the four button. After 60 seconds
stop to press any button, the screen come to a sleeping mode, no word display in screen, you can press any of
the four buttons to let screen become bright.
3.1 Check SD card and scan Bluetooth device
After turn on the switch, RADIUS Log Light first display Gefran logo in screen:
Then going to check SD card status.
Then scan Bluetooth device.
From left to right indicates:
search times, registration times,
cancel times, number of valid
address
1) RADIUS Log Light first display "Gefran" logo when powered on.
2) About 10 seconds later it come to Check SD card status, in check SD card status RADIUS Log Light
start to check whether SD card existence, the process last for 30 to 120 seconds dur to actual situation.
3) Then RADIUS Log Light search for Bluetooth devices. RADIUS Log Light off line time, online time, dis-
covered device, active device will be displayed on screen.
4) a. If no device been searched, RADIUS Log Light will continue searching. Press "ENTER" button to
come to "Main Status" interface.
b. If some device been searched, RADIUS Log Light will display "Check Finish" in the end. You can
press "ENTER" to come to "MainStatus" interface.
Radius Log Light
Function
Optional item move up, move cursor in a item for parameter make change
Optional item down; Increase parameter value
Back to previous menu, end of setting; Interface switching
Enter menu, confirm parameter value setting
>
Table 3.1 Button operation
Gefran
APV Solar
SdSdSdSdSdSdSdSd
SD CARD: NC
Fig 3.1 Check SD status
Bluetooth logo
xx xx xx xx
Active Num: 0
Fig 3.2 Bluetooth scan
<
Display "Gefran" in art words
<
Check SD card
<
Bluetooth Scan Status
<
Number of inverter connected
