R
O
ADAR
VERVIEW
The radar scanner must be connected to the control head to enable radar features. Some of the features also require a
compass/heading sensor.
NOTE: To configure the radar after installation or equipment repair, see Configure Radar.
Radar View with Cursor Active
Radar X-Press Menu
orientation menu
exit cursor
sensor status icons
cursor
distance and bearing to cursor position
cursor position
OR
Move the Joystick to
Tap to Activate the Cursor
Open the Cursor Menu
Activate the Cursor
113
Radar Overview
