Humminbird ONIX Operating Manual page 27

Select Recordings to start a sonar recording or select a save location. You can also watch a sonar recording
from the perspective of a 2D, SI, or DI View, depending on the capabilities of your model. See Sonar
Recording for more information.
Required Equipment: transducer, black box sonar
Select GPS to review the signal strength of the GPS receivers ("sensors") connected to the system. The tool
shows the satellites in the area, the positions, and the signal strength for each one. You can also designate
a primary and secondary GPS source from this tool. See Getting Started, Installation Information, and Set
up your Humminbird Network.
Required Equipment: GPS receiver (internal or external)
Select Files to update the software for the control head or connected accessories. You can also import
and export navigation data from this tool, and you can import and export menu settings. Radar installation
settings can be managed from this tool, but we recommend an authorized technician use this menu only.
See the following sections: Manage your Navigation Data and Manage your Control Head.
Required Equipment: SD card
Select Setup Guide, and the control head will guide you through the basic configuration settings for your
control head, including units of measurement, language, transducer source, map source, and vessel
settings. See your installation guide for details. To change the settings after setup, select Home > Settings.
27 Home Screen
