Humminbird ONIX Operating Manual page 218

When you turn on/off pinging or change the transducer settings, all control heads sharing the transducer are affected.
Select Beams
The instructions in this section are only applicable if the selected sonar source includes more than one beam.
The beams selected in this menu affect all units that are sharing the sonar source. For example, if you select the blended
83/200 kHz beams for one control head, and you select the single 83 kHz beam on another control head, the control head with the
single 83 kHz selection will receive blended information. To access both beams, but view individual frequencies on individual control
heads, see Select Frequencies.
1. Press the HOME key.
2. Select Settings.
3. Select Sonar.
4. Under the sonar source type (2D, Down Imaging, Side Imaging, etc.), select the frequency menu.
5. Select the beam(s) you want to use.
sonar
Humminbird Network Setup
Use the pick list to select a sonar source
for the selected control head.
Selecting 2D Sonar Beams
turn on/off transducer setup
pinging menu
If you change settings here, it will
change the settings across the network.
218
turn on/off
transducer
Beam Select menu
for 2D Sonar
