Set up Autopilot
(ION only)
If you are using a separate-purchase Humminbird autopilot (SC 110) with the ION control head, it is important to review the following:
• Read the autopilot manual completely so you understand the operation requirements before you use the equipment.
• There are many safety precautions that must be considered before you use the equipment. See the autopilot manual for more
information.
• When you initiate navigation from the control head, there are certain controls that are NOT available on the autopilot. See the
autopilot manual for more information.
WARNING! The autopilot system should be installed and configured by a certified Marine Electronics Technician (CMET) or an
authorized Marine Electronics Installer (MEI). See NMEA.org for details. Incorrect installation may affect the system's
performance, which affects the safety of the vessel and its passengers. If you have questions about the installation, please
contact Humminbird Customer Service.
Set up Autopilot
Use the following instructions to set up Autopilot on the ION control head.
1. Select the control head that has the autopilot connected to it.
2. Press the HOME key.
3. Select Settings.
4. Select Network.
5. Under Sensor Port, select the port that is connected to the autopilot (RS-232, NMEA 0183 [1], or NMEA 0183 [2]).
6. Select NMEA Output.
7. Under AutoPilot, select APB. Tap the check box, or press the ENTER key, to add a check mark to it.
8. To enable all modes of the SC 110 with the ION control head, select the NMEA Output sentences as shown in the following
table.
Multisensor
Standby
Auto
Auto-Track
Nav
Wind
NOTE: See the SC 110 manual and the SCP 110 manual for details. To download the manuals, visit our Web site at
humminbird.com.
9. Go to the Autopilot section of this manual to enable autopilot navigation with the control head.
Autopilot Setup
RMC or VTG
n/a
n/a
GGA or GLL or RMC
APA or APB or BOD + RMB or BOD + XTE or BOD + XTR
MWV or VWR
