To mark waypoints and start navigation, the control head must have a GPS fix from a connected or internal GPS receiver. The
navigation menus can be accessed from the X-Press Menu, touch screen, and the key pad.
Mark a Waypoint
Cross Touch allows you to mark a waypoint on the Sonar Views using the touch screen or key pad. You can also mark a waypoint at
the vessel position or the cursor position.
Mark a Waypoint at the Vessel Position
Touch Screen
1. Tap Sonar in the status bar.
2. Select Mark.
3. Select Waypoint.
Mark a Waypoint at the Cursor Position
Touch Screen
1. Press and hold a position on the Sonar View.
2. Select Waypoint.
Sonar & Navigation
V
IEWS
Keypad
1. Press the MARK key twice.
Keypad
1. Use the Joystick to move the cursor to a position on
the Sonar View.
2. Press the MARK key twice.
174
