Radar Transmission Settings - Humminbird ONIX Operating Manual

R T
ADAR RANSMISSION
The Radar Transmit menu can be accessed from the Power X-Press Menu, the Radar X-Press Menu, and the Radar tab in Settings.
Start Transmission
1. Power On: Turn on the radar power source (breaker or switch).
2. Tap the top, right corner of the status bar.
OR
Press the POWER key.
3. Select Radar Transmit, and turn it on.
Set up Timed Transmission Settings
1. Press the HOME key.
2. Select Settings.
3. Select Radar.
4. Select Timed Transmit, and turn it on.
5. Select Transmit Time. Set the the amount of time that the radar will transmit during Timed Transmission mode.
6. Select the Back icon to return to the previous menu.
7. Select Standby Time. Set the amount of time that the radar will pause between transmissions in Timed Transmission mode.
Set the Park Position
Use Park Position to set the stopping point for the open array scanner when it has finished the scan rotation.
1. Press the HOME key.
2. Select Settings.
3. Select Radar.
4. Select Park Position. Press and hold the slider, or turn the Rotary dial, to change the setting.
Stop Transmission
1. Tap the top, right corner of the status bar.
OR
Press the POWER key.
2. Select Radar Transmit, and turn it off.
3. Power Off: Turn off the power source from the breaker or switch.
S
ETTINGS
117 Radar Transmission
