Humminbird ONIX Operating Manual page 21

P /S
PILOT
ILOT TANDBY KEY
STANDBY
Use the PILOT/STANDBY key if there is an autopilot
connected to the system. Press the PILOT/STANDBY
key to open the Settings > Navigation menu and turn
on Autopilot Navigation. See Autopilot Overview for
details.
PANE
KEY
Press the PANE key to open the View Options menu or
to select a pane in a multi-pane view. The selected
pane is highlighted in yellow. See Views for details.
MENU
KEY
To open the X-Press Menu for the on-screen view and
operation mode, press the MENU key once. To open
the Main Menu (Settings tool), press the MENU key
twice. To return to the last-used Main Menu tab,
press and hold the MENU key. See The Menu System
for details.
ENTER
KEY
Press the ENTER key start a command or turn on a
setting. The ENTER key also opens the Info menu and
the Cursor menu.
EXIT
KEY
Press the EXIT key once to close a menu, close a
dialog box, turn off an alarm, or exit Cursor mode.
Press and hold the EXIT key to close all menus at
once.
GO TO/S
GO TO
CREEN
Press this key once to open the Go To menu for
navigation functions. See Routes for details.
Press and hold this key to save the screen image. See
Images Tool for details.
MARK/M
MARK
Press and hold this key to start Man Overboard
Navigation. To mark waypoints, press this key twice.
See Man Overboard (MOB) and Introduction to
Navigation for details.
S
NAPSHOT KEY
O
AN VERBOARD KEY
ARROW
With a view displayed on-screen, press each arrow
key repeatedly until the Favorites view you want to
use is displayed on the screen. See Views for more
information.
Next View: Press the RIGHT ARROW key.
Previous View: Press the LEFT ARROW key.
21
KEYS
R D
OTARY IAL
Turn the Rotary dial to adjust menu
settings. Similar to the ENTER key, you
can press the Rotary dial to enter a
menu setting or start a command.
J
OYSTICK
Move the Joystick to select a view, tool,
or menu. Press the Joystick to open your
selection.
The Joystick is also used to move the
cursor across the view, pan 2D/3D chart
views, and select menu options and
dialog box information.
Press the Joystick to mark a Route
Point. Similar to the ENTER key, you can
press the Joystick to enter a menu
setting or start a command.
ION Control Head
