C451/C550/C650
Copy operations

Advertisement

Table of Contents
loading

Related Manuals for Konica Minolta bizhub C451

Summary of Contents for Konica Minolta bizhub C451

  • Page 1 C451/C550/C650 Copy operations...

  • Page 3: Table Of Contents

    Copy Operations (this manual)......................1-15 Print Operations ..........................1-15 Box Operations ..........................1-15 Network Scanner Operations ......................1-15 PageScope Web Connection Operations ..................1-15 Fax Operations (Option) ........................1-15 Network Fax Operations (Option)....................1-15 Legal restrictions on copying....................... 1-16 bizhub C451/C550/C650 Contents-1...
  • Page 4 To adjust the angle of the control panel ..................3-30 Turning on the main power and the auxiliary power ..............3-32 Turning on the machine ........................3-32 Scanning during warm-up ....................... 3-33 Turning off the machine........................3-34 Contents-2 bizhub C451/C550/C650...
  • Page 5 Storing the desired zoom ratio......................4-43 Selecting an original > copy setting .................... 4-45 Selecting single-sided copies ......................4-46 Selecting double-sided copies......................4-47 Selecting a combined copy setting ..................... 4-49 Copying multiple document pages onto a single page ("Combined Copy" settings)..... 4-50 bizhub C451/C550/C650 Contents-3...
  • Page 6 Clearing a paper misfeed in the ADF (transport section)..............6-11 Clearing a paper misfeed in the ADF (scanning section)..............6-15 Clearing a paper misfeed in the ADF (output section)..............6-18 Clearing a paper misfeed in the ADF (turnover section) ..............6-20 Contents-4 bizhub C451/C550/C650...
  • Page 7 Copy paper............................8-3 Possible paper sizes ......................... 8-3 Paper types and paper capacities ....................8-4 Special paper ............................ 8-6 Precautions for paper........................8-7 Paper storage............................ 8-7 Auto tray switch feature ........................8-8 Order for selecting paper trays ......................8-8 bizhub C451/C550/C650 Contents-5...
  • Page 8 Adding a binding margin to copies ("Page Margin" function) ........... 9-66 9.17 Adjusting the image to fit the paper ("Image Adjust" settings)..........9-69 9.18 Copying with the page layout of a booklet ("Booklet" function)..........9-72 9.19 Erasing specified areas of copies ("Frame Erase" function)............. 9-74 Contents-6 bizhub C451/C550/C650...
  • Page 9 Displaying the current jobs list (stored jobs and active jobs)............12-11 Displaying the job history list ......................12-12 Printing a proof copy of a stored job .................... 12-13 Printing a stored job ........................12-14 Increasing printing priority......................12-16 bizhub C451/C550/C650 Contents-7...
  • Page 10 Cover Sheet Feeder Size Adjustment.................... 13-60 13.9 Color registration adjust ......................13-61 Adjusting the color registration for yellow, magenta and cyan ............. 13-61 13.10 Gradation adjustment........................13-63 13.11 Header/Footer settings ....................... 13-65 Specifying headers/footers......................13-65 Editing headers/footers ......................... 13-67 Contents-8 bizhub C451/C550/C650...
  • Page 11 Conditions of the password rules ....................13-87 13.16 Enhanced security mode ......................13-88 Appendix 14.1 Entering text........................... 14-3 Enlarging the keyboard ........................14-4 To type text ............................. 14-5 List of available characters......................14-5 14.2 Glossary ............................14-6 Index bizhub C451/C550/C650 Contents-9...
  • Page 12 Contents-10 bizhub C451/C550/C650...

  • Page 13: Introduction

    Introduction...

  • Page 15: Openssl Statement

    OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. This product includes cryptographic software written by Eric Young (eay@crypt-Soft.com). This product includes software written by Tim Hudson (tjh@cryptsoft.com). bizhub C451/C550/C650...
  • Page 16 The licence and distribution terms for any publically available version or derivative of this code cannot be changed. i.e. this code cannot simply be copied and put under another distribution licence [including the GNU Public Licence.] All other product names mentioned are trademarks or registered trademarks of their respective companies bizhub C451/C550/C650...

  • Page 17: Available Features

    Copies can be folded at their center ("Half-Fold" setting) or bound with staples after being folded in half ("Center Staple & Fold" setting). Otherwise, the copies can be folded in three ("Tri-fold" setting). For details, refer to "Selecting a folding setting" on page 4-72. bizhub C451/C550/C650...

  • Page 18: Sorting Copies

    Copying multiple original pages onto a single page Multiple pages of the original can be printed together on a single page. For details, refer to "Copying multiple document pages onto a single page ("Combined Copy" settings)" on page 4-50. bizhub C451/C550/C650...

  • Page 19: Copying An Original Containing Various Page Sizes

    For details, refer to "Adding cover pages ("Cover Sheet" function)" on page 9-24. Inserting different paper into copies Different paper (such as colored paper) can be inserted for specified pages in the copies. For details, refer to "Inserting different paper into copies ("Insert Sheet" function)" on page 9-27. bizhub C451/C550/C650...

  • Page 20: Inserting Pages From A Different Original At Specified Locations In A Copy

    For details, refer to "Copying with image colors inversed ("Neg./Pos. Reverse" function)" on page 9-41. Printing a mirror image An original can be copied in its mirror image. For details, refer to "Copying in a mirror image ("Mirror Image" function)" on page 9-43. bizhub C451/C550/C650...

  • Page 21: Copying With A Background Color

    Printing the enlarged image on multiple pages A single original page can be automatically split into parts with each part printed enlarged. For details, refer to "Copying an enlarged image on multiple pages ("Poster Mode" function)" on page 9-60. bizhub C451/C550/C650...

  • Page 22: Creating Booklets From Copies Of Pamphlets

    Copying with the page layout of a magazine Copies can be made with the pages arranged in a layout for center binding, such as for a magazine. For details, refer to "Copying with the page layout of a booklet ("Booklet" function)" on page 9-72. 1-10 bizhub C451/C550/C650...

  • Page 23: Erasing Sections Of Copies

    For details, refer to "Displaying function descriptions (Help)" on page 5-14. Interrupting a copy job The copy job being printed can be interrupted in order for a different copy job to be printed. For details, refer to "Interrupting a copy job (Interrupt mode)" on page 5-8. bizhub C451/C550/C650 1-11...

  • Page 24: Explanation Of Manual Conventions

    Text highlighted in this manner contains references for more detailed information. Special text markings [Stop] key The names of keys on the control panel are written as shown above. MACHINE SETTING Display texts are written as shown above. 1-12 bizhub C451/C550/C650...
  • Page 25 Introduction Note The machine illustrations shown in this manual can vary and depend on the machine configuration. bizhub C451/C550/C650 1-13...

  • Page 26: Descriptions And Symbols For Originals And Paper

    If the width (Y) of the paper is shorter than the length (X), the paper has a vertical or portrait orientation, indicated by w. Crosswise (v) If the width (Y) of the paper is longer than the length (X), the paper has a horizontal or landscape orientation, indicated by v. 1-14 bizhub C451/C550/C650...

  • Page 27: User Manuals

    In order to use the fax functions, the optional fax kit must be purchased separately. Network Fax Operations (Option) This manual contains details on the network fax functions. Refer to this manual for operating procedures on Internet faxing and IP address faxing. bizhub C451/C550/C650 1-15...

  • Page 28: Legal Restrictions On Copying

    In order to prohibit the illegal reproduction of certain originals, such as paper currency, this machine is equipped with a counterfeit prevention feature. Due to the counterfeit prevention feature that this machine is equipped with, images may be distorted. 1-16 bizhub C451/C550/C650...

  • Page 29: Installation And Operation Precautions

    Installation and operation precautions...

  • Page 31: Safety Information

    A diagonal line indicates a prohibited This symbol warns against dismantling course of action. the device. A black circle indicates an imperative This symbol indicates you must unplug course of action. the device. bizhub C451/C550/C650...

  • Page 32: Disassemble And Modification

    Use of a damaged power cord (exposed core wire, broken wire, etc.) could result in a fire or breakdown. Should any of these conditions be found, immediately turn OFF the power switch, un- plug the power cord from the power outlet, and then call your authorized service rep- resentative. bizhub C451/C550/C650...

  • Page 33: Power Source

    Do not unplug and plug in the power cord with a wet hand, as an electrical shock could result. • Plug the power cord all the way into the power outlet. Failure to do this could result in a fire or electrical shock. bizhub C451/C550/C650...

  • Page 34: Grounding

    Should a piece of metal, water, or any other similar foreign matter get inside the prod- uct, immediately turn OFF the power switch, unplug the power cord from the power outlet, and then call your authorized service representative. bizhub C451/C550/C650...

  • Page 35: Ventilation

    Do not keep using this product, if this product has been dropped or its cover damaged. Immediately turn OFF the power switch, unplug the power cord from the power outlet, and then call your authorized service representative. If you keep on using it as is, a fire or electrical shock could result. bizhub C451/C550/C650...

  • Page 36: Consumables

    • When moving this product, always hold it by the locations specified in the user manual or other documents. If the unit falls it may cause severe personal injury. The product may also be damaged or malfunction. bizhub C451/C550/C650...

  • Page 37: Before Successive Holidays

    When the optional Fax Kit FK-502 is not installed: 7 CAUTION Ignoring this cautions could cause injury or damage to property. Do not ignore this safety advices. Caution Symbol • Unplug the product when you will not use the product for long periods of time. bizhub C451/C550/C650...

  • Page 38: Regulation Notices

    This device must be used with a shielded network (10 Base-T/100 Base-TX) cable and a shielded parallel cable. The use of non-shielded cables is likely to result in interference with radio communications and is prohibited under CISPR rules and local rules. 2-10 bizhub C451/C550/C650...

  • Page 39: Laser Safety

    The laser diode and the scanning polygon mirror are incorporated in the print head unit. The print head unit is NOT A FIELD SERVICE ITEM: Therefore, the print head unit should not be opened under any circumstances. Laser Aperture of the Print Head Unit Print Head bizhub C451/C550/C650 2-11...

  • Page 40: Cdrh Regulations

    Om apparaten används på annat sätt än i denna bruksanvisning specificerats, kan användaren utsättas för osynlig laserstrålning, som överskrider gränsen för laserklass 1. Det här är en halvledarlaser. Den maximala effekten för laserdioden är 30 mW och våglängden är 775-800 nm. 2-12 bizhub C451/C550/C650...

  • Page 41: For Norway Users

    Dette en halvleder laser. Maksimal effekt till laserdiode er 30 mW og bølgelengde er 775-800 nm. Laser safety label A laser safety label is attached to the outside of the machine, as shown below. * Only for the U.S.A. bizhub C451/C550/C650 2-13...

  • Page 42: Ozone Release

    This product complies with RoHS (2002/95/EC) Directive. This device is not intended for use at a video workstation in compliance with BildscharbV. Das Gerat ist nicht fur die Benutzung am Bildschirmarbeitsplatz gemäß BildscharbV vorgesehen. 2-14 bizhub C451/C550/C650...

  • Page 43: Caution Notations And Labels

    Installation and operation precautions Caution notations and labels Safety precaution notations and labels appear on this machine at the following positions. Be very careful that an accident does not occur when operations such as removing paper misfeeds are performed. bizhub C451/C550/C650 2-15...

  • Page 44: Space Requirements

    958.3 391.9 1130 C451/C550/C650+FS-608+LU-301(+PI-503) Unit: mm 190.6 958.3 391.9 1130 C451+FS-519+SD-505+LU-301 Unit: mm Reminder Be sure to allow a clearance of 100 mm (4 in.) or more at the back of this machine for the ventilation duct. 2-16 bizhub C451/C550/C650...

  • Page 45: Operation Precautions

    Adhesive that contains solvent (e.g., spray glue) may dissolve the toner on copies. Color copies have a thicker layer of toner than normal black-and-white copies. Therefore, when a color copy is folded, the toner at the fold may peel off. bizhub C451/C550/C650 2-17...
  • Page 46 Installation and operation precautions 2-18 bizhub C451/C550/C650...

  • Page 47: Before Making Copies

    Before making copies...

  • Page 49: Part Names And Their Functions

    Before making copies Before making copies Part names and their functions Options The following table shows the available options for bizhub C451, bizhub C550 as well as bizhub C650. Option bizhub C451 bizhub C550 bizhub C650 Authentication unit (biometric type) AU-101...
  • Page 50 Before making copies bizhub C451 bizhub C451/C550/C650...
  • Page 51 Local interface kit EK-602* Used for connecting the authentication unit (biometric type) and the JScribe IC card reader/writer. Parts marked with an asterisk are internal options and therefore are not shown in the illustration. bizhub C451/C550/C650...
  • Page 52 Punch kit PK-513 Installed onto the finisher to allow hole punching to be used. Post inserter PI-503 Adds cover pages to copies when installed on the finisher. In ad- dition, this option allows the finisher to be operated manually. bizhub C451/C550/C650...
  • Page 53 Local interface kit EK-602* Used for connecting the authentication unit (biometric type) and the JScribe IC card reader/writer. Parts marked with an asterisk are internal options and therefore are not shown in the illustration. bizhub C451/C550/C650...

  • Page 54: Outside Of Machine

    Can be loaded with up to 500 sheets of plain paper. Can be loaded with up to 400 sheets of thick paper 1, 280 sheets of thick paper 1+, 250 sheets of thick paper 2, or 200 sheets of thick paper 3. bizhub C451/C550/C650...
  • Page 55 Opened when replacing the waste toner box and when replacing the imaging unit, when cleaning the print head. Upper front door Opened when replacing the toner cartridge. Output tray Collects printed pages. Control panel Used to specify the various machine settings. bizhub C451/C550/C650...
  • Page 56 Used to turn the machine on and off. Status indicator The machine’s current status is indicated by the color and light- ing/flashing of the indicator. Flashing in blue: Printing normally Flashing in orange: Warning Lit in orange: Stopping operating 3-10 bizhub C451/C550/C650...
  • Page 57 Supplies power to the machine. Dehumidifier heater power switch Used to turn the dehumidifier heater on and off. Turning on the (bizhub C451 and C550 only) dehumidifier heater reduces moisture in the paper. Jack for connecting a telephone Used for connecting the cord from a telephone.
  • Page 58 Used for connecting the modem for CS Remote Care. Network connector Used for connecting the network cable when this machine is (10Base-T/100Base-TX/1000Base-T) used for network printing and network scanning. Ozone filter Collects the ozone generated in the machine. 3-12 bizhub C451/C550/C650...

  • Page 59: Inside Of Machine

    There are four toner cartridges: cyan (C), magenta (M), yellow (Y) and black (K). The combination of the four toners generates full- color images. Left partition glass Used to scan the document image in this area when the ADF is used. bizhub C451/C550/C650 3-13...
  • Page 60 Before making copies Part name Description Document scales Position the document so that it is aligned with the scales. Also, use the scales to measure the loaded document. Misfeed-clearing dial Turned when clearing paper misfeeds within the ADF. 3-14 bizhub C451/C550/C650...

  • Page 61: Finisher Fs-517/Punch Kit Pk-512/Punch Kit Pk-513

    Removed from the stacker unit when clearing jammed staples or when replacing the staple cartridge. Handle FN7 Grabbed when removing and inserting the stacker unit. Misfeed-clearing dial FN6 Turned when clearing paper misfeeds within the finisher. Guide lever FN5 Opened when clearing paper misfeeds. bizhub C451/C550/C650 3-15...

  • Page 62: Punch Kit Pk-512/Punch Kit Pk-513

    Punches holes for filing printed pages when the punch kit is in- stalled onto Finisher FS-517. Punch scrap box Removed when emptying punch scraps that have accumulated from using the Punch settings. Finisher FS-608/Punch kit PK-512/Punch kit PK-513 3-16 bizhub C451/C550/C650...

  • Page 63: Finisher Fs-608

    Opened when clearing paper misfeeds. Stacker unit Pulled out when clearing paper misfeeds or jammed staples or when replacing the staple cartridge. Guide lever FN8 Opened when clearing paper misfeeds. Misfeed-clearing dial FN7 Turned when clearing paper misfeeds within the finisher. bizhub C451/C550/C650 3-17...

  • Page 64: Punch Kit Pk-512/Punch Kit Pk-513

    Punches holes for filing printed pages when the punch kit is in- stalled onto Finisher FS-608. Punch scrap box Removed when emptying punch scraps that have accumulated from using the Punch settings. Finisher FS-519/Output tray OT-602/Punch kit PK-510 3-18 bizhub C451/C550/C650...
  • Page 65 Part name Description Punch kit* Punches holes for filing printed pages when the punch kit is in- stalled onto finisher FS-519. Parts marked with an asterisk are internal options and therefore are not shown in the illustration. bizhub C451/C550/C650 3-19...

  • Page 66: Saddle Stitcher Sd-505/Mailbin Kit Mt-502

    Before making copies Saddle stitcher SD-505/Mailbin kit MT-502 Saddle stitcher SD-505 Part name Description Output tray Collects printed pages. Misfeed-clearing door Opened when clearing paper misfeeds within the saddle stitcher. 3-20 bizhub C451/C550/C650...
  • Page 67 Before making copies Mailbin kit MT-502 Part name Description Mailbins Collects printed pages. Misfeed-clearing door Opened when clearing paper misfeeds within the mailbin kit. Guide lever FN7 Moved when clearing paper misfeeds within the mailbin kit. bizhub C451/C550/C650 3-21...

  • Page 68: Post Inserter Pi-503

    Upper tray paper guide Slide to fit the size of paper being loaded when loading with cov- er sheets. Upper unit release lever Raised to slide the upper unit to the left when clearing paper mis- feeds. 3-22 bizhub C451/C550/C650...

  • Page 69: Large Capacity Unit Lu-301

    Paper-empty indicator Flashes in orange when very few pages remain in the paper tray, and lights up when the tray is empty. Large capacity unit release lever Used to slide the large capacity unit away from the machine. bizhub C451/C550/C650 3-23...
  • Page 70 Do not place objects on top of the finisher and below the paper output trays, otherwise the machine may be damaged. FS-517 FS-608 FS-519 Do not place your hand below or rest your foot on top of the output trays for finisher FS-519. FS-519 3-24 bizhub C451/C550/C650...

  • Page 71: Control Panel

    Flashes in blue while a print job is being received. Lights up in blue when a print job is queued to be printed or while it is being printed. The indicator lights up in blue when there is saved fax data or un- printed fax data. bizhub C451/C550/C650 3-25...
  • Page 72 Do not apply extreme pressure to the touch panel, otherwise it may be scratched or damaged. Never push down on the touch panel with force, and never use a hard or pointed object to make a selection in the touch panel. 3-26 bizhub C451/C550/C650...

  • Page 73: Basic Settings Screens

    When the machine is ready to begin making copies after being turned on, the Basic screen appears. To activate a function or to select a setting, lightly touch the desired button in the touch panel. Basic screen Quick Copy screen bizhub C451/C550/C650 3-27...
  • Page 74 The Quick Copy screen displays all of the settings from the Basic screen so that many settings can easily be specified. Detail For details on switching the basic settings screen, refer to "Custom display settings" on page 13-17. 3-28 bizhub C451/C550/C650...

  • Page 75: Icons That Appear In The Screen

    Indicates that paper is not loaded in the paper tray. Indicates that very little paper remains in the paper tray. When the optional image controller has been installed, touch this icon to display the image controller screen. Indicates that "Enhanced Security Mode" is set to "ON". bizhub C451/C550/C650 3-29...

  • Page 76: Adjusting The Angle Of The Control Panel

    4 Left tilt position To adjust the angle of the control panel Pull the control panel release lever toward you, and then push down on the control panel. Control panel release lever The control panel stops at the middle position. 3-30 bizhub C451/C550/C650...
  • Page 77 To return the control panel to the upper position, pull the control panel release lever toward you, and then pull up on the control panel. Reminder When tilting the control panel, do not grab the touch panel. bizhub C451/C550/C650 3-31...

  • Page 78: Turning On The Main Power And The Auxiliary Power

    After the machine has finished warming up, the scanned image will be printed. The machine takes about 30 seconds to warm up at normal room temperature (23 °C) when the [Power] (auxiliary power) key is turned on after the main power switch is turned on. 3-32 bizhub C451/C550/C650...

  • Page 79: Scanning During Warm-Up

    The print order can be changed or jobs can be deleted from the Detail screen of a job from the Current Jobs list in the Job List screen. For details, refer to "Managing jobs" on page 12-3. bizhub C451/C550/C650 3-33...

  • Page 80: Turning Off The Machine

    Detail The following are cleared when the main power switch and [Power] (auxiliary power) key are turned off. Settings that have not been programmed Jobs queued to be printed 3-34 bizhub C451/C550/C650...

  • Page 81: Automatically Clearing Settings (Automatic Panel Reset)

    Settings in the Administrator Settings mode can be changed to put the machine in Sleep mode instead. For details, refer to "System settings" on page 13-23. The Low Power mode can also be canceled by pressing any key in the control panel or by touching the touch panel. bizhub C451/C550/C650 3-35...

  • Page 82: Automatically Conserving Energy (Sleep Mode)

    As a default, the machine enters Low Power mode if no operation is performed for 15 minutes, and then the machine enters Sleep mode after 30 minutes have elapsed. The length of time until the machine enters Sleep mode can be changed. For details, refer to "System settings" on page 13-15 and page 13-23. 3-36 bizhub C451/C550/C650...

  • Page 83: Manually Conserving Energy

    As the factory default, the Weekly Timer is not set. For details on setting the Weekly Timer, refer to "System settings" on page 13-23. Press the [Power Save] key. Type in the password (up to 8 digits) for non-business hours. bizhub C451/C550/C650 3-37...
  • Page 84 From the Password for Non-Business Hours screen (displayed from Administrator Settings mode), the machine can be set so that the screen for entering the password for non-business hours is not displayed. The default setting for the "Password for Non-Business Hours" parameter is "No" (the screen is not displayed). 3-38 bizhub C451/C550/C650...

  • Page 85: Controlling Each User's Use Of This Machine (User Authentication)

    For details on specifying public user settings, refer to "Selecting an authentication method" on page 13-70 and "Public user access" on page 13-75. – If "Enhanced Security Mode" is set to "ON", [Public User Access] and [User Name List] do not appear. bizhub C451/C550/C650 3-39...
  • Page 86 Touch [Server Name] to display the names of the registered servers, and then select the desired server. For details on specifying settings for an external server authentication, refer to "Selecting an authentication method" on page 13-70. Type in the user name, and then touch [OK]. Touch [Password]. 3-40 bizhub C451/C550/C650...
  • Page 87 When you are finished printing, press the [Access] key. A message appears, requesting confirmation to log off. Touch [Yes], and then touch [OK]. The user authentication screen appears. Detail For details on specifying user authentication settings, refer to "User authentication/Account track" on page 13-30. bizhub C451/C550/C650 3-41...

  • Page 88: Controlling Each Account's Use Of This Machine (Account Track)

    Contact your administrator for passwords. A total of 1,000 users and accounts can be registered. Touch [Account Name]. – If the Administrator Settings mode settings have been set to "Password Only", touch [Password], and then continue with step 4. 3-42 bizhub C451/C550/C650...
  • Page 89 Before making copies Type in the account name, and then touch [OK]. Touch [Password]. Type in the password, and then touch [OK]. Touch [Login] or press the [Access] key. The Basic screen appears. bizhub C451/C550/C650 3-43...
  • Page 90 "Password Only", log on is possible by only entering the password. For details, refer to "User authentication/Account track" on page 13-30. For details on specifying account track settings, refer to "User authentication/Account track" on page 13-30. 3-44 bizhub C451/C550/C650...

  • Page 91: Controlling Use Of This Machine With Authentication Unit (Biometric Type)

    For details on specifying authentication settings for the authentication unit (biometric type) and on registering finger vein patterns, refer to the User manual provided with the authentication unit (biometric type). When "1-to-many authentication" has been specified Place your finger on the authentication unit (biometric type). The basic screen appears. bizhub C451/C550/C650 3-45...

  • Page 92: When "1-To-1 Authentication" Has Been Specified

    Place your finger on the authentication unit (biometric type). The basic screen appears. Note If the authentication unit (biometric type) cannot be used, it is possible to use this machine by entering a [User name] and [Password]. 3-46 bizhub C451/C550/C650...

  • Page 93: Controlling Use Of This Machine With The Authentication Unit (Ic Card Type)

    IC card information, refer to the manual provided with the authentication unit (IC card type). When "Card Authentication" has been specified Place the IC card horizontally on the card scanning area of the authentication unit (IC card type). The Basic screen appears. bizhub C451/C550/C650 3-47...

  • Page 94: When "Card Authentication + Password" Has Been Specified

    Type in the password, and then touch [Login] or press the [Access] key. The Basic screen appears. Note If the authentication unit (IC card type) cannot be used, it is possible to use this machine by entering a user name and password. 3-48 bizhub C451/C550/C650...

  • Page 95: Loading Paper Into Tray 1 And Tray 2

    Load the paper into the tray so that the side of the paper to be , mark printed on (the side facing up when the package was unwrapped) faces up. – Load letterhead paper so that the side to be printed on faces down. bizhub C451/C550/C650 3-49...
  • Page 96 8-3. For details on specifying the paper size for tray 1 and 2, refer to "Selecting a paper size setting ("Size" setting)" on page 8-10. To print on OHP transparencies, envelopes or postcards, use the bypass tray. 3-50 bizhub C451/C550/C650...

  • Page 97: Loading Paper Into Tray 3

    Be careful not to touch the surface of the paper take-up roller with your hands. Note To change the size of paper loaded in tray 3, contact your service representative. To print on OHP transparencies and envelopes, use the bypass tray. bizhub C451/C550/C650 3-51...
  • Page 98 Be careful not to touch the surface of the paper take-up roller with your hands. Note To change the size of paper loaded in tray 4, contact your service representative. To print on OHP transparencies and envelopes, use the bypass tray. 3-52 bizhub C451/C550/C650...

  • Page 99: Loading Paper Into The Lct

    If the machine is turned off, the bottom plate cannot be raised. When loading paper into the LCT, be sure that the machine is turned on with both the main power switch and the [Power] (auxiliary power) key. bizhub C451/C550/C650 3-53...

  • Page 100: Loading Paper Into The Bypass Tray

    How many sheets of paper and other media can be loaded? % Do not load so many sheets of plain paper that the top of the stack is higher than the , mark. Lateral guides Select the paper type. 3-54 bizhub C451/C550/C650...
  • Page 101 Push the paper guides firmly up against the edges of the paper. When loading postcards, load them in the w orientation, as shown in the illustration. Do not load postcards in the v orientation. A maximum of 50 postcards can be loaded into the bypass tray. bizhub C451/C550/C650 3-55...
  • Page 102 When loading envelopes, load them with the flap side up, as shown in the illustration. If the envelopes are loaded with the flap side down, a paper misfeed may occur. The flap side of envelopes cannot be printed on. A maximum of 10 envelopes can be loaded into the bypass tray. Flap side 3-56 bizhub C451/C550/C650...
  • Page 103 Detail For details on specifying the paper size for the bypass tray, refer to "Selecting a paper size setting ("Size" setting)" on page 8-10. For details on the paper sizes, refer to "Copy paper" on page 8-3. bizhub C451/C550/C650 3-57...
  • Page 104 Before making copies 3-58 bizhub C451/C550/C650...

  • Page 105: Basic Copy Operations

    Basic copy operations...

  • Page 107: General Copy Operation

    Some settings cannot be used together. For details on the settings that cannot be combined, refer to "Operations that cannot be combined" on page 4-6. Press the [Copy] key to display the Basic screen in Copy mode. Position the document to be copied. – For details on positioning the document, refer to page 4-8. bizhub C451/C550/C650...
  • Page 108 For details on specifying settings for the Application functions, refer to page 9-3. Using the keypad, type in the desired number of copies. – If the number of copies was incorrectly entered, press the [C] (clear) key in the keypad, and then specify the correct number of copies. bizhub C451/C550/C650...
  • Page 109 To stop the copy operation being performed, press the [Stop] key. For details, refer to page 4-86. – The next copy operation can be queued while a copy operation is being performed. For details, refer to page 4-85. bizhub C451/C550/C650...

  • Page 110: Operations That Cannot Be Combined

    Select the "2 Position" Staple setting. Set the "Booklet" function. The "2 Position" Staple setting is automatically canceled, and the "Booklet" function is set. To select the "2 Position" Staple setting, cancel the "Booklet" function, and then select the "2 Position" setting. bizhub C451/C550/C650...

  • Page 111: Operations Where The Setting Specified First Is Given Priority

    The message "Cannot be set with Booklet." appears and the "2 Position" Staple setting cannot be selected. The "Booklet" function remains selected and the "2 Position" Staple setting is canceled. To select the "2 Position" Staple setting, cancel the "Booklet" function, and then select the "2 Position" Staple setting. bizhub C451/C550/C650...

  • Page 112: Feeding The Document

    Slide the lateral guides to fit the size of the document. Load the document face up in the document feed tray. – Load the document pages so that the top of the document is toward the back or the left side of the machine. bizhub C451/C550/C650...

  • Page 113: Placing The Document On The Original Glass

    20° 20° Align the document with the mark in the back-left corner of the document scales. – For details on selecting the document orientation, refer to "Selecting the document orientation ("Original Direction" settings)" on page 4-23. Original scales bizhub C451/C550/C650...
  • Page 114 Close the ADF if it is installed. 4-10 bizhub C451/C550/C650...

  • Page 115: Scanning The Document In Separate Batches ("Separate Scan" Setting)

    For details on positioning the document, refer to "Feeding the document" on page 4-8. In the Basic screen, touch [Separate Scan]. – To cancel the "Separate Scan" setting, touch [Separate Scan] again to deselect it. Press the [Start] key. After the document has been scanned, the following message appears. bizhub C451/C550/C650 4-11...
  • Page 116 The amount of memory available can be checked beside "Memory" in the lower-left corner of the screen. To delete the image data, press the [Stop] key, and then delete the job. For details, refer to "Temporarily stopping scanning/printing" on page 4-86. After all document pages have been scanned, touch [Finish]. 4-12 bizhub C451/C550/C650...
  • Page 117 – If the "Separate Scan Output Method" parameter is set to "Batch Print", the copy settings can be changed. To change the copy settings, touch [Change Setting], and then touch [OK] after changing the settings as desired. bizhub C451/C550/C650 4-13...

  • Page 118: Scanning A Multi-Page Document From The Original Glass

    For details on positioning the document, refer to "Placing the document on the original glass" on page 4-9. When loaded in the w orientation When loaded in the v orientation 20° 20° Close the ADF if it is installed. In the Basic screen, touch [Duplex/Combine]. The Duplex/Combine screen appears. 4-14 bizhub C451/C550/C650...
  • Page 119 4-47. Touch [Original Direction], select the orientation of the loaded document, and then touch [OK]. – For details on specifying the document orientation, refer to "Selecting the document orientation ("Original Direction" settings)" on page 4-23. Touch [OK]. bizhub C451/C550/C650 4-15...
  • Page 120 The buttons that appear in the screen for changing the settings differ depending on the specified settings. Settings for the following can be changed. 1-Sided/2-Sided, Binding Position, Zoom, Frame Erase, Center Erase Original Size – To cancel changes to the settings, touch [Cancel]. After all document pages have been scanned, touch [Finish]. 4-16 bizhub C451/C550/C650...
  • Page 121 – If the "Separate Scan Output Method" parameter is set to "Batch Print", the copy settings can be changed. To change the copy settings, touch [Change Setting], and then touch [OK] after changing the settings as desired. bizhub C451/C550/C650 4-17...

  • Page 122: Specifying Document Settings

    Position the document to be copied. – For details on positioning the document, refer to "Feeding the document" on page 4-8. In the Basic screen, touch [Original Setting]. The Original Setting screen appears. Touch [Original Size]. The Original Size screen appears. 4-18 bizhub C451/C550/C650...
  • Page 123 Custom Size screen – To specify a photo size, touch [Photo Size] to display the Photo Size screen. Touch the button for the desired document size, and then touch [OK]. Photo Size screen The Original Size screen appears again. bizhub C451/C550/C650 4-19...

  • Page 124: Copying Documents Of Mixed Sizes ("Mixed Original" Setting)

    Slide the adjustable lateral guides against the edges of the document. – Load the document pages into the ADF so that the top of the pages is toward the back or the left side of the machine. Lateral guide 4-20 bizhub C451/C550/C650...
  • Page 125 Basic copy operations In the Basic screen, touch [Original Setting]. The Original Setting screen appears. Touch [Mixed Original]. – To cancel the "Mixed Original" setting, touch [Mixed Original] again to deselect it. bizhub C451/C550/C650 4-21...

  • Page 126: Loading Folded (Z-Folded) Documents

    For details on loading the document, refer to "Loading the document into the ADF" on page 4-8. In the Basic screen, touch [Original Setting]. The Original Setting screen appears. Touch [Z-Folded Original]. – To cancel the "Z-Folded Original" setting, touch [Z-Folded Original] again to deselect it. 4-22 bizhub C451/C550/C650...

  • Page 127: Selecting The Document Orientation ("Original Direction" Settings)

    ADF with the top of the document toward the right side of this machine. • Select this setting for a document placed on the original glass with the top of the document toward the left side of this machine. bizhub C451/C550/C650 4-23...

  • Page 128: To Select An Original Direction Setting

    The Original Setting screen appears. Touch [Original Direction]. The Original Direction screen appears. Touch the button for the orientation of the loaded document, and then touch [OK]. – To cancel the setting and select the default, press the [Reset] key. 4-24 bizhub C451/C550/C650...

  • Page 129: Selecting The Position Of The Binding Margin ("Binding Position" Settings)

    Note If "Auto" is selected, the binding margin is set at the top or at the left. When the document length is more than 297 mm: bizhub C451/C550/C650 4-25...

  • Page 130: To Select A Binding Position Setting

    The Original Setting screen appears. Touch [Binding Position]. The Binding Position screen appears. Touch the button for the desired binding margin position, and then touch [OK]. – To cancel the setting and select the default, press the [Reset] key. 4-26 bizhub C451/C550/C650...

  • Page 131: Reducing The Effects Of Dust On The Left Partition Glass

    For details on loading the document, refer to "Loading the document into the ADF" on page 4-8. In the Basic screen, touch [Original Setting]. Touch [Despeckle]. – To cancel the "Despeckle" setting, touch [Despeckle] again to deselect it. Note The scanning speed will be reduced. bizhub C451/C550/C650 4-27...

  • Page 132: Changing Scan Settings For Each Document

    "Separate Scan" setting is used. Position the document to be copied. In the Basic screen, touch [Separate Scan]. Press the [Start] key. Scanning begins. Touch [Change Setting]. A screen appears, allowing you to change the settings. 4-28 bizhub C451/C550/C650...
  • Page 133 The buttons that appear in the screen for changing the settings differ depending on the specified settings. Settings for the following can be changed. 1-Sided/2-Sided, Binding Position, Zoom, Frame Erase, Center Erase Original Size – To cancel changes to the settings, touch [Cancel]. Binding Position screen Zoom screen Frame Erase screen bizhub C451/C550/C650 4-29...
  • Page 134 "Frame Erase" setting, refer to "Erasing specified areas of copies ("Frame Erase" function)" on page 9-74. – The Center Erase screen appears only when the "Book Scanning" function is selected. – The Original Size screen appears only when the "Mixed Original" setting is selected. Touch [OK]. 4-30 bizhub C451/C550/C650...

  • Page 135: Selecting A Color Setting

    To select a color setting The following procedure describes how to select a Color setting. In the Basic screen, touch [Color]. The Color screen appears. bizhub C451/C550/C650 4-31...
  • Page 136 – To use the average brightness method for reproducing gradations in monocolor documents, touch [Solid]. – If the "Solid" setting is not selected, the relative luminosity method is selected. Touch [OK]. The Basic screen appears again. 4-32 bizhub C451/C550/C650...

  • Page 137: Selecting A Paper Setting

    If the "Full Size" Zoom setting was specified, paper of the same size as the document is selected. If the zoom ratio was increased or decreased, a paper size that corresponds to the specified zoom ratio is automatically selected. In the Basic screen, touch [Paper]. The Paper screen appears. Touch [Auto]. bizhub C451/C550/C650 4-33...

  • Page 138: Manually Selecting The Desired Paper Size

    "Automatically selecting the zoom ratio ("Auto" zoom setting)" on page 4-35. In the Basic screen, touch [Paper]. The Paper screen appears. Select the paper tray loaded with the desired paper. Touch [OK]. The Basic screen appears again. 4-34 bizhub C451/C550/C650...

  • Page 139: Specifying A Zoom Setting

    "Auto" Paper setting was selected, the Paper screen appears. In the Paper screen, specify the desired Paper setting. As the factory default, "Full Size" is selected. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch [Auto]. Touch [OK]. The Basic screen appears again. bizhub C451/C550/C650 4-35...

  • Page 140: Specifying The Zoom Ratio Of The Document ("Full Size" Setting)

    Touch [+] to enlarge the zoom ratio, and touch [-] to reduce the zoom ratio in 0.1% increments. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch [Full Size]. Touch [OK]. The Basic screen appears again. 4-36 bizhub C451/C550/C650...

  • Page 141: Typing In The Zoom Ratio ("Xy Zoom" Setting)

    4-43. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch [XY Zoom]. Using the keypad, type in the desired zoom ratio (between 25.0% and 400.0%). – To cancel changes to the settings, touch [Cancel]. bizhub C451/C550/C650 4-37...

  • Page 142: Slightly Reducing The Copy ("Minimal" Setting)

    "Minimal" setting or programming custom zoom ratios, refer to "Storing the desired zoom ratio" on page 4-43. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch [Minimal]. Touch [OK]. The Basic screen appears again. 4-38 bizhub C451/C550/C650...

  • Page 143: Selecting A Preset Zoom Ratio ("Enlarge And Reduce" Settings)

    As the factory default, "Full Size" is selected. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch the button for the appropriate zoom ratio beside "Enlarge" and "Reduce", depending on the document and paper sizes. Touch [OK]. The Basic screen appears again. bizhub C451/C550/C650 4-39...

  • Page 144: Typing In Separate X And Y Zoom Ratios ("Individual Zoom" Settings)

    If the value was incorrectly entered, press the [C] (clear) key to erase the value, and then specify the correct value. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch [XY Zoom]. 4-40 bizhub C451/C550/C650...
  • Page 145 Touch [Y] under "Set Individual Zoom", and then use the keypad to type in the desired zoom ratio (between 25.0% and 400.0%) for the Y direction. – To cancel changes to the settings, touch [Cancel]. Touch [OK], and then touch [OK] in the next screen that appears. The Basic screen appears again. bizhub C451/C550/C650 4-41...

  • Page 146: Selecting A Stored Zoom Ratio

    "Storing the desired zoom ratio" on page 4-43. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch the button for the desired zoom ratio under "Set Zoom Ratio". Touch [OK]. The Basic screen appears again. 4-42 bizhub C451/C550/C650...
  • Page 147 If a button stored with a zoom ratio is not touched before [OK] is touched, no setting is changed. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch [XY Zoom]. Using the keypad, type in the desired zoom ratio (between 25.0% and 400.0%). – To cancel changes to the settings, touch [Cancel]. bizhub C451/C550/C650 4-43...
  • Page 148 – To cancel the setting and select the default, press the [Reset] key. The specified zoom ratio is stored. Touch [OK], and then touch [OK] in the next two screens that appear. The Basic screen appears again. 4-44 bizhub C451/C550/C650...

  • Page 149: Selecting An Original > Copy Setting

    Select this setting to produce two single-sided copies from one double- sided document. 2-Sided > 2-Sided Select this setting to produce double-sided copies from double-sided documents. The following procedures describe how to select Original and Copy settings. bizhub C451/C550/C650 4-45...

  • Page 150: Selecting Single-Sided Copies

    If "Auto" is selected under "Original Bind Direction", the binding margin is set at the top or at the left. – For a double-sided document, touch [Binding Position], select the binding position of the document, and then touch [OK]. 4-46 bizhub C451/C550/C650...

  • Page 151: Selecting Double-Sided Copies

    297 mm, a binding position along the short side of the paper is selected. – If the binding position for the copy is set to "Auto", the binding position is set at the top or at the left. bizhub C451/C550/C650 4-47...
  • Page 152 Touch [Original Direction], select the orientation of the loaded document, and then touch [OK]. – For details on specifying the document orientation, refer to "Selecting the document orientation ("Original Direction" settings)" on page 4-23. Touch [OK]. The Basic screen appears again. 4-48 bizhub C451/C550/C650...

  • Page 153: Selecting A Combined Copy Setting

    Select this setting to print two document pages on one page. Horizontal Vertical 4in1 Select this setting to print four document pages on one page. The page arrangement (Num- bering Direction setting) can be specified. Horizontal Vertical bizhub C451/C550/C650 4-49...

  • Page 154: Copying Multiple Document Pages Onto A Single Page ("Combined Copy" Settings)

    ("Binding Position" settings)" on page 4-25. For details on specifying the document orientation, refer to "Selecting the document orientation ("Original Direction" settings)" on page 4-23. In the Basic screen, touch [Duplex/Combine]. The Duplex/Combine screen appears. Select the desired combined copy setting. 4-50 bizhub C451/C550/C650...
  • Page 155 If "2in1" was selected, the pages will be arranged as shown below. Horizontal Vertical – If "4in1 / 8in1" was selected, the 4in1/8in1 screen appears. Touch [Vertical] or [Horizontal] to select the page arrangement. – To cancel the setting, touch [No]. bizhub C451/C550/C650 4-51...

  • Page 156: Selecting The Quality Of The Document

    The copied text is reproduced so that it is darker, making it easier to read. Dot Matrix Original Select this setting when copying images (documents) printed with this machine. Copied Paper The following procedure describes how to select an Original Type setting. 4-52 bizhub C451/C550/C650...

  • Page 157: To Select An Original Type Setting

    For a document that contains only text, touch [Text]. – For a document that contains both text and photos, touch [Text/Photo] to display the Photo Type screen. Touch the button for the appropriate setting, and then touch [OK]. bizhub C451/C550/C650 4-53...
  • Page 158 – For a document that contains maps, touch [Map]. – For a document that contains faint text, touch [Dot Matrix Original]. – For a document printed with this machine, touch [Copied Paper]. The Quality/Density screen appears again. 4-54 bizhub C451/C550/C650...

  • Page 159: Selecting The Density Settings

    Touch [Standard] to select the middle setting of the nine levels. The following procedures describe how to specify the density settings. Adjusting the print density ("Density" settings) In the Basic screen, touch [Quality/Density]. The Quality/Density screen appears. bizhub C451/C550/C650 4-55...
  • Page 160 Each time [Light] or [Dark] is touched, the density is lightened or darkened by one level. – To select the center setting (default setting), touch [Standard]. – To cancel the setting and select the default, press the [Reset] key. Touch [OK]. 4-56 bizhub C451/C550/C650...

  • Page 161: Adjusting The Background Density ("Background Removal" Settings)

    To select the third setting from the right (default setting), touch [Standard]. – Touch [Auto] to automatically adjust the level of the background density according to the document being copied. – To cancel the setting and select the default, press the [Reset] key. Touch [OK]. bizhub C451/C550/C650 4-57...

  • Page 162: Adjusting The Reproduction Quality Of Text

    Each time [Lighter Text] or [Darker Text] is touched, the density is lightened or darkened by one level. To select the middle setting of the nine levels ("0"), touch [Standard]. – To cancel the setting and select the default, press the [Reset] key. Touch [OK]. 4-58 bizhub C451/C550/C650...

  • Page 163: Printing With A Glossy Finish ("Glossy" Setting)

    In the Basic screen, touch [Quality/Density]. The Quality/Density screen appears. Touch [Glossy]. – To cancel the "Glossy" setting, touch [Glossy] again to deselect it. – To cancel the setting and select the default, press the [Reset] key. bizhub C451/C550/C650 4-59...

  • Page 164: Selecting Finishing Settings

    For details on "Fold/Bind" and "Center Staple / Fold", refer to "Selecting a folding setting" on page 4-72. Note If the post inserter has been installed onto the finisher, the finisher can be operated manually. For details, refer to "Manually using the finisher" on page 4-81. 4-60 bizhub C451/C550/C650...
  • Page 165 The "Center Staple & Fold" setting can be used if the saddle stitcher is installed on optional finisher FS-519. Output Tray Select the output tray where the finished copies are to be fed. This setting can be used if optional finisher FS-519 is installed. bizhub C451/C550/C650 4-61...
  • Page 166 FS-519 + Punch kit + Mailbin o: Possible e: Not possible Note Available finishers for bizhub C550 and C650: FS-517 and FS-608 Available finisher for bizhub C451: FS-517, FS-519 and FS-608 For more information on available options see page 3-3. 4-62 bizhub C451/C550/C650...

  • Page 167: Separating Copies By Sets ("Sort" Setting)

    In the Basic screen, touch [Finishing]. The Finishing screen appears. Touch [Sort]. – To separate each set of copies, touch [Yes] under "Offset". Touch [OK]. The Basic screen appears again. bizhub C451/C550/C650 4-63...

  • Page 168: Separating Copies By Pages ("Group" Setting)

    In the Basic screen, touch [Finishing]. The Finishing screen appears. Touch [Group]. – To separate each set of pages, touch [Yes] under "Offset". Touch [OK]. The Basic screen appears again. 4-64 bizhub C451/C550/C650...

  • Page 169: Selecting The Output Tray

    The output tray can be selected only if optional finisher FS-519 is installed. In the Basic screen, touch [Finishing]. The Finishing screen appears. Touch [Output Tray]. Select the output tray where copies are to be fed, and then touch [OK]. The Basic screen appears again. bizhub C451/C550/C650 4-65...

  • Page 170: Stapling Copies ("Staple" Settings)

    50 sheets of 80 g/m paper 2 sheets of 200 g/m paper + 48 sheets of 80 g/m paper 16 sheets of 90 g/m paper 2 sheets of 200 g/m paper + 14 sheets of 90 g/m paper 4-66 bizhub C451/C550/C650...
  • Page 171 50 sheets of 90 g/m paper 2 sheets of 209 g/m paper + 48 sheets of 90 g/m paper Maximum of 30 sheets of 91 to 120 g/m paper In the Basic screen, touch [Finishing]. The Finishing screen appears. bizhub C451/C550/C650 4-67...
  • Page 172 Under "Staple", touch either [Corner] or [2 Position]. – To cancel the Staple setting, touch [None]. Touch [Position Setting]. – Select the stapling position, and then touch [OK]. – When the "2 Position" Staple setting is selected. 4-68 bizhub C451/C550/C650...

  • Page 173: Punching Holes In Copies ("Punch" Settings)

    Original Direction setting is not selected, holes may not be punched in the copies as desired. For details on specifying the document orientation, refer to "Selecting the document orientation ("Original Direction" settings)" on page 4-23. Note The Punch settings are available only if the punch kit is installed on the optional finisher. bizhub C451/C550/C650 4-69...
  • Page 174 90 g/m A3 w, A4 v, B5 w Thick paper 1/1+/2 (91 g/m to 209 g/m In the Basic screen, touch [Finishing]. The Finishing screen appears. Under "Punch", touch [4-Hole]. – To cancel the Punch setting, touch [None]. 4-70 bizhub C451/C550/C650...
  • Page 175 If desired, touch [Original Direction], and then select the setting appropriate for the document. – For details on specifying the document orientation, refer to "Selecting the document orientation ("Original Direction" settings)" on page 4-23. Touch [OK]. The Basic screen appears again. bizhub C451/C550/C650 4-71...

  • Page 176: Selecting A Folding Setting

    If options are installed, copies can be folded before being fed out. The following folding settings are available. The available settings differ depending on the options that are installed. Setting Description Compatible models bizhub C451 bizhub C550/C650 Half-Fold Select this setting to fold copies in half before feeding them out.

  • Page 177: Folding Copies In Half ("Half-Fold" Setting)

    When folding 3 sheets: 25 sets or less (with a paper length of 299 mm or less) 33 sets or less (others) In the Basic screen, touch [Finishing]. The Finishing screen appears. Touch [Fold/Bind]. The Fold/Bind screen appears. bizhub C451/C550/C650 4-73...
  • Page 178 In order for copies to be bound at the center or folded in half, all of the following conditions must be met. The paper width must be between 182 mm and 297 mm. The paper length must be between 257 mm and 431.8 mm. 4-74 bizhub C451/C550/C650...
  • Page 179 The Center Staple/Fold screen appears. Touch [Yes] below "Half-Fold". – As the factory default, the "Booklet" function is automatically specified when Half-Fold is selected. – To cancel the "Half-Fold" setting, touch [No] or the button for a different setting. bizhub C451/C550/C650 4-75...

  • Page 180: Binding Copies At The Center ("Center Staple & Fold" Setting)

    11 e 17 w, 8-1/2 e 14 w, 8-1/2 e 11 w, 81 g/m to 90 g/m 16 sheets 8K w In the Basic screen, touch [Finishing]. The Finishing screen appears. Touch [Fold/Bind]. The Fold/Bind screen appears. Touch [Center Staple & Fold]. 4-76 bizhub C451/C550/C650...
  • Page 181 In order for copies to be bound at the center or folded in half, all of the following conditions must be met. The paper width must be between 182 mm and 297 mm. The paper length must be between 257 mm and 431.8 mm. In the Basic screen, touch [Finishing]. The Finishing screen appears. bizhub C451/C550/C650 4-77...
  • Page 182 When the "Center Staple & Fold" setting is selected, the following Finishing settings are not availa- ble. Group Offset Staple Punch – To cancel the "Center Staple & Fold" setting, touch [No] or the button for a different setting. Touch [OK], and then touch [OK] again. 4-78 bizhub C451/C550/C650...

  • Page 183: To Fold Copies In Three ("Tri-Fold" Setting)

    When copies are to be folded in three, settings can be specified to select whether the printed side is on the inside or the outside. For details on selecting the setting, refer to "Copier settings" on page 13-18. In the Basic screen, touch [Finishing]. The Finishing screen appears. Touch [Fold/Bind]. The Fold/Bind screen appears. bizhub C451/C550/C650 4-79...
  • Page 184 When the "Tri-Fold" setting is selected, the following Finishing settings are not available. Group Offset Staple Punch – To cancel the "Tri-Fold" setting, touch [No] or the button for a different setting. Touch [OK], and then touch [OK] again. 4-80 bizhub C451/C550/C650...

  • Page 185: Manually Using The Finisher

    90 g/m PK-512 is installed: tray 1 Thick paper (91 to A3w to A5v, 128 g/m 11×17w to 5- 1/2×8-1/2w, 8×13w, 16Kw/v, 8Kw When Punch kit PK-513 is installed: A3w, B4w, A4v, B5v, 11×17w, 8-1/2×11v, 7-1/4×10-1/2v, 16Kv, 8Kw bizhub C451/C550/C650 4-81...

  • Page 186: Names Of Control Panel Parts

    If the paper is to be folded in three, load the paper so that the side that is to be the outside when folded in three is face up. – The loaded paper will be finished into one set. Slide the paper guides to fit the size of the paper. 4-82 bizhub C451/C550/C650...
  • Page 187 [Finishing] key is pressed. When only a Punch setting is selected, all indicators except the one on the [Punch] key go off. Press the [Start/Stop] key. – Press the [Start/Stop] key during an operation to stop the operation. bizhub C451/C550/C650 4-83...

  • Page 188: Selecting Not To Rotate The Image

    Copies can be printed with the image not rotated to fit the orientation of the loaded paper. Document Auto Rotate OFF Auto Rotate Note Depending on the paper size and zoom ratio, some parts of the image may be lost. In the Basic screen, touch [Auto Rotate OFF]. 4-84 bizhub C451/C550/C650...

  • Page 189: Scanning The Next Document To Be Copied While A Copy Job Is Being Printed (Next Job Reservation)

    Basic screen. – For details on specifying the screen that appears while printing, refer to "Custom display settings" on page 13-17. Press the [Start] key. After the current copy job is finished, the next copy job begins. bizhub C451/C550/C650 4-85...

  • Page 190: Temporarily Stopping Scanning/Printing

    For details on deleting a temporarily stopped job, refer to "Deleting a paused job" on page 4-87. Press the [Stop] key while a document is being scanned or a job is being printed. Scanning/printing stops. The Stopped Jobs screen appears. To continue all stopped jobs, press the [Start] key. 4-86 bizhub C451/C550/C650...

  • Page 191: Deleting A Paused Job

    Press the [Stop] key while a document is being scanned or a job is being printed. Scanning/printing stops. The Stopped Jobs screen appears. Select the job to be deleted, and then touch [Delete]. The selected job is deleted. bizhub C451/C550/C650 4-87...
  • Page 192 Basic copy operations 4-88 bizhub C451/C550/C650...

  • Page 193: Additional Copy Operations

    Additional copy operations...

  • Page 195: Checking The Copy Settings (Check Job)

    From the Check Job Details screens, the current copy settings can be checked and changed if desired. To check the settings Touch [Check Job] in the left panel, and then touch [Check Details]. The Check Job Settings screen appears. bizhub C451/C550/C650...
  • Page 196 Additional copy operations bizhub C451/C550/C650...

  • Page 197: To Change The Settings

    ] until the button for the function to be changed is displayed. Touch the button for the function whose setting is to be changed. The screen for specifying the setting appears. Follow the appropriate procedure to change the setting. bizhub C451/C550/C650...

  • Page 198: Printing A Proof To Check The Settings (Proof Copy)

    For details on stored jobs, refer to page 12-13. If "System Auto Reset" is set to "OFF", the job is stored if no operation is performed for 1 minute. – For details on the automatic system reset operation, refer to "Automatically conserving energy (sleep mode)" on page 3-36. bizhub C451/C550/C650...
  • Page 199 Press the [Proof Copy] key to print another proof copy. – To stop the proof copy while scanning or printing, perform the operation described in "Temporarily stopping scanning/printing" on page 4-86. Touch [Print]. The remaining copies are queued as a copy job. bizhub C451/C550/C650...

  • Page 200: Interrupting A Copy Job (Interrupt Mode)

    After the interrupting job has finished printing, press the [Interrupt] key. The indicator on the [Interrupt] key goes off. The copy settings return to those specified before printing was interrupted. Note If the interrupting job is cancelled, printing for the interrupted job automatically restarts. bizhub C451/C550/C650...

  • Page 201: Registering Copy Programs (Mode Memory)

    – If 30 copy programs have been registered, delete an unnecessary copy program. For details on deleting copy programs, refer to "Deleting a copy program" on page 5-11. The Register Copy Program screen appears. bizhub C451/C550/C650...
  • Page 202 % To change the entered copy program name, touch the button whose name is to be changed, and then touch [Edit Name]. The Edit Name screen appears. Return to step 4 and repeat the procedure to change the copy program name. 5-10 bizhub C451/C550/C650...

  • Page 203: Deleting A Copy Program

    Touch [Delete]. A message appears, requesting confirmation to delete the copy program. Touch [Yes], and then touch [OK]. The Recall Copy Program screen appears again. The copy settings registered in the copy program are erased. bizhub C451/C550/C650 5-11...

  • Page 204: Copying With Programmed Copy Settings (Mode Memory)

    To display the previous screen, touch [ Back]. To display the next screen, touch [Forward If the setting for a function has been changed from the default, the button for that function appears with a colored frame. 5-12 bizhub C451/C550/C650...
  • Page 205 The programmed copy settings are recalled and the Basic screen appears again. Press the [Start] key. Copying begins with the recalled copy settings. Note To stop recalling a copy program, press the [Reset] key or the [Mode Memory] key or touch [Cancel]. bizhub C451/C550/C650 5-13...

  • Page 206: Displaying Function Descriptions (Help)

    To display the next screen higher in the menu structure, touch [Close]. Touch [Exit] to exit the Help mode and return to the screen that was displayed before the [Help] key was pressed. 5-14 bizhub C451/C550/C650...
  • Page 207 Additional copy operations Help screen (2nd level) (Example: Function) bizhub C451 bizhub C550/C650 Description [Copy], [Scan/Fax], [Copy], [Scan/Fax], Displays the first Help screen for each description. [User Box], [Job List], [User Box], [Job List] [Print] Detail The items displayed in the Help menu for the name and function of each part differ depending on the options that are installed.

  • Page 208: Displaying Main Help Screens

    Displaying main help screens As an example, the following procedures describe the Help screens that are displayed for copy operations by using "Function". With the Basic screen displayed, press the [Help] key. The Help Menu screen appears. 5-16 bizhub C451/C550/C650...
  • Page 209 Touch [Copy] or [Open], or press the [1] key in the keypad. The Copy Help screen appears. Touch [Open] or the desired information, or press the key in the keypad for the number to the left of the desired information to display the corresponding Help screen. bizhub C451/C550/C650 5-17...
  • Page 210 Additional copy operations After checking the Help information, touch [Exit] or press the [Help] key again. The Basic screen appears again. 5-18 bizhub C451/C550/C650...

  • Page 211: Specifying Control Panel Settings (Accessibility Mode)

    Touch [Touch Panel Adjustment] or press the [1] key in the keypad. The Touch Panel Adj. screen appears. Why does the machine not respond when [Touch Panel Adj.] is touched? The touch sensors are not aligned on the touch panel. % Press the [1] key in the keypad. bizhub C451/C550/C650 5-19...
  • Page 212 Touch [Close] or press the [Accessibility] key. The Basic screen appears again. Note If the touch panel cannot be adjusted, contact the technical representative. Detail To cancel the touch panel adjustment, press the [Stop] key or the [Reset] key. 5-20 bizhub C451/C550/C650...

  • Page 213: Setting The "Key Repeat Start/Interval Time" Functions

    To reduce the time, touch [-]. – Both settings can be set between 0.1 and 3.0 seconds in 0.1-second increments. – To cancel changes to the settings, press the [Reset] key. Touch [OK]. The Accessibility Setting screen appears again. bizhub C451/C550/C650 5-21...

  • Page 214: Setting The "System Auto Reset Confirmation" Function

    For details on displaying the Accessibility Setting screen, refer to "Displaying the accessibility setting screen" on page 5-19. For details on the automatic system reset operation, refer to "Automatically conserving energy (sleep mode)" on page 3-36. Touch [System Auto Reset Confirmation] or press the [3] key in the keypad. 5-22 bizhub C451/C550/C650...
  • Page 215 The Enlarge Display mode is compatible with basic copy, scanning and fax functions. With the Enlarge Display mode, text and illustrations are displayed at a larger size so that they can be seen more easily. As the factory default, "No" is selected. bizhub C451/C550/C650 5-23...

  • Page 216: Setting The "Auto Reset Confirmation" Function

    3-35. Display the Accessibility Setting screen. – For details on displaying the Accessibility Setting screen, refer to "Displaying the accessibility setting screen" on page 5-19. Touch [Auto Reset Confirmation] or press the [4] key in the keypad. 5-24 bizhub C451/C550/C650...
  • Page 217 If the time setting is the same for the automatic panel reset operation and the automatic system reset operation, the display of the message requesting confirmation to exit Enlarge Display mode is given priority and the message requesting confirmation to reset the settings in Enlarge Display mode is not displayed. bizhub C451/C550/C650 5-25...

  • Page 218: Setting The "Enlarge Display Mode Confirmation" Function

    For details on displaying the Accessibility Setting screen, refer to "Displaying the accessibility setting screen" on page 5-19. Touch [Enlarge Display Mode Confirmation] or press the [5] key in the keypad. The Enlarge Display Mode Confirmation screen appears 5-26 bizhub C451/C550/C650...
  • Page 219 The Enlarge Display mode is compatible with basic copy, scanning and fax functions. With the Enlarge Display mode, text and illustrations are displayed at a larger size so that they can be seen more easily. If "OFF" is selected in the Enlarge Display Mode Confirmation screen, the screen is not displayed. bizhub C451/C550/C650 5-27...

  • Page 220: Setting The "Message Display Time" Function

    To cancel changes to the settings, press the [Reset] key. All changes to the settings are canceled. Touch [OK]. The Accessibility Setting screen appears again. Touch [Close] or press the [Accessibility] key. The Basic screen appears again. 5-28 bizhub C451/C550/C650...

  • Page 221: Setting The "Sound Setting" Functions

    – For details on displaying the Accessibility Setting screen, refer to "Displaying the accessibility setting screen" on page 5-19. Touch [Sound Setting] or press the [2] key in the keypad. The Sound Setting screen appears. bizhub C451/C550/C650 5-29...
  • Page 222 To cancel changes to the settings, press the [Reset] key. All changes to the settings are canceled. Touch [OK]. The Sound Setting screen appears again. Touch [Close]. The Accessibility Setting screen appears again. Touch [Close] or press the [Accessibility] key. The Basic screen appears again. 5-30 bizhub C451/C550/C650...

  • Page 223: Troubleshooting

    Troubleshooting...

  • Page 225: When The Message "An Internal Error Occurred." Appears (Call Service Representative)

    Display in Enlarge Display mode If the internal error occurs, the screen shown below appears. Reminder Since the machine may be damaged, contact the technical representative according to the procedure described below as soon as the call technical representative screen appears. bizhub C451/C550/C650...
  • Page 226 Write down the malfunction code (for example, C-0001) in the call technical representative screen. Turn the machine off by using the [Power] (auxiliary power) key and the main power switch. Unplug the machine. Contact the technical representative, and inform them of the malfunction code. bizhub C451/C550/C650...

  • Page 227: When The Message "Misfeed Detected." Appears

    Note The procedure for clearing misfed paper differs depending on where the misfeed occurs. Determine the misfeed location by looking at the illustration displayed with the error message, and then clear the misfeed according to the appropriate procedure. bizhub C451/C550/C650...

  • Page 228: Paper Misfeed Indications

    Troubleshooting Paper misfeed indications bizhub C451 The illustration above shows the main unit with optional Finisher FS-608 and the LCT installed. The illustration above shows optional finisher FS-519 and the mailbin kit installed. bizhub C451/C550/C650...
  • Page 229 Paper misfeed in tray 4 (p. 6-35) Paper misfeed in Finisher FS-517/Finisher FS-608 (p. 6-44 and p. 6-48) Paper misfeed in Finisher FS-519 (page 6-52) Paper misfeed in a mailbin (page 6-55) Paper misfeed in the saddle stitcher (page 6-56) bizhub C451/C550/C650...
  • Page 230 Paper misfeed in tray 3 (p. 6-34) Paper misfeed in the tray 3/4 horizontal transport unit (p. 6-36) Paper misfeed in tray 4 (p. 6-35) Paper misfeed in Finisher FS-517/Finisher FS-608 (p. 6-44 and p. 6-48) Paper misfeed in post inserter (p. 6-58) bizhub C451/C550/C650...

  • Page 231: Clearing A Paper Misfeed In The Adf (Feed Section)

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. Remove all document pages remaining in the document feed tray. Open the left-side cover. Raise the document feed tray as far as possible. bizhub C451/C550/C650...
  • Page 232 When pulling out misfed paper, be sure to pull it in the feed direction. Return the document feed tray to its original position. Close the left-side cover. Load the document into the document feed tray according to the instructions that appear on the screen. 6-10 bizhub C451/C550/C650...

  • Page 233: Clearing A Paper Misfeed In The Adf (Transport Section)

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. Remove all document pages remaining in the document feed tray. Open the left-side cover. Raise the document feed tray as far as possible. bizhub C451/C550/C650 6-11...
  • Page 234 Slowly remove any misfed document pages. – Since the document pages may be damaged, raise the document feed tray before pulling out any misfed pages. – When pulling out misfed paper, be sure to pull it in the feed direction. 6-12 bizhub C451/C550/C650...
  • Page 235 2 in the direction of the arrow to feed out the page. Misfeed-clearing dial 2 Return the document feed tray to its original position. bizhub C451/C550/C650 6-13...
  • Page 236 Troubleshooting Close the left-side cover. Load the document into the document feed tray according to the instructions that appear on the screen. 6-14 bizhub C451/C550/C650...

  • Page 237: Clearing A Paper Misfeed In The Adf (Scanning Section)

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. Remove all document pages remaining in the document feed tray. Open the left-side cover. Raise the document feed tray as far as possible. bizhub C451/C550/C650 6-15...
  • Page 238 If the edge of the paper is not visible in the document output tray, open the guide and pull out the edge of the paper, and then turn misfeed-clearing dial 1 in the direction of the arrow to feed out the document page. 6-16 bizhub C451/C550/C650...
  • Page 239 Troubleshooting Close the ADF. Return the document feed tray to its original position. Close the left-side cover. Load the document into the document feed tray according to the instructions that appear on the screen. bizhub C451/C550/C650 6-17...

  • Page 240: Clearing A Paper Misfeed In The Adf (Output Section)

    Remove all document pages remaining in the document feed tray. Raise the document feed tray as far as possible, and then slowly pull out any misfed document pages. If the misfed paper could not be removed, open the ADF. 6-18 bizhub C451/C550/C650...
  • Page 241 Misfeed-clearing dial 1 Close the ADF. Return the document feed tray to its original position. Load the document into the document feed tray according to the instructions that appear on the screen. bizhub C451/C550/C650 6-19...

  • Page 242: Clearing A Paper Misfeed In The Adf (Turnover Section)

    Raise the document output tray as far as possible, and then pull out any misfed document pages. – Raise the document feed tray as far as possible, and then raise the document output tray as far as possible. 6-20 bizhub C451/C550/C650...
  • Page 243 Return the document output tray to its original position. Return the document feed tray to its original position. Load the document into the document feed tray according to the instructions that appear on the screen. bizhub C451/C550/C650 6-21...

  • Page 244: Clearing A Paper Misfeed In The Fusing Unit

    – If the paper cannot be removed by pulling it down, pull it – If the paper is zigzag folded and jammed in the fusing unit, open the fusing unit cover, and then remove the paper. 6-22 bizhub C451/C550/C650...
  • Page 245 Be careful not to spill toner inside the machine or get toner on your clothes or hands. If your hands become soiled with toner, immediately wash them with soap and water. If toner gets in your eyes, immediately flush them with water, and then seek professional medical attention. bizhub C451/C550/C650 6-23...
  • Page 246 Be careful not to touch the surface of the image transfer belt or the image transfer roller. Image transfer belt Image transfer roller Be careful not to touch the film and surface of the paper take-up roller with your hands. 6-24 bizhub C451/C550/C650...

  • Page 247: Clearing A Paper Misfeed In The Main Unit

    Toner that did not pass through the fusing unit may get on your hands or clothes. Be extremely careful when removing the paper. – If the edge of the paper cannot be grabbed, turn the misfeed-clearing dial to feed out the paper. Close the upper right-side door. bizhub C451/C550/C650 6-25...
  • Page 248 Be careful not to spill toner inside the machine or get toner on your clothes or hands. If your hands become soiled with toner, immediately wash them with soap and water. If toner gets in your eyes, immediately flush them with water, and then seek professional medical attention. 6-26 bizhub C451/C550/C650...

  • Page 249: Clearing A Paper Misfeed In The Automatic Duplex Unit

    Clearing a paper misfeed in the automatic duplex unit Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. Open the door of the automatic duplex unit. Slowly remove any misfed paper from the automatic duplex unit. bizhub C451/C550/C650 6-27...
  • Page 250 Pull out the tray being used, and then remove all paper from the tray. Load the paper into the tray again, and then close the tray. Reminder Be careful not to touch the film and surface of the paper take-up roller with your hands. 6-28 bizhub C451/C550/C650...

  • Page 251: Clearing A Paper Misfeed In The Bypass Tray

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. Remove the paper from the bypass tray. Open the door of the bypass tray. Slowly remove any misfed paper from the bypass tray. Close the door of the bypass tray. bizhub C451/C550/C650 6-29...

  • Page 252: Clearing A Paper Misfeed In The Paper Transport Section

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. Open the door of the bypass tray. Open the lower right-side door. Slowly remove any misfed paper. Close the lower right-side door and the door of the bypass tray. 6-30 bizhub C451/C550/C650...
  • Page 253 Pull out the tray being used, and then remove all paper from the tray. Load the paper into the tray again, and then close the tray. Reminder Be careful not to touch the film and surface of the paper take-up roller with your hands. bizhub C451/C550/C650 6-31...

  • Page 254: Clearing A Paper Misfeed In Tray 1

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. Pull out tray 1. Remove any misfed paper. Remove any paper remaining in the tray. Load the paper into the tray again, and then close the tray. Reminder Be careful not to touch the film. 6-32 bizhub C451/C550/C650...

  • Page 255: Clearing A Paper Misfeed In Tray 2

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. Pull out tray 2. Remove any misfed paper. Remove any paper remaining in the tray. Load the paper into the tray again, and then close the tray. Reminder Be careful not to touch the film. bizhub C451/C550/C650 6-33...

  • Page 256: Clearing A Paper Misfeed In Tray 3

    Load the paper into the tray again, lower the paper take-up roller, and then close the tray. Reminder When removing misfed paper, remove it without lifting the paper take-up roller. Be careful not to touch the surface of the paper take-up roller with your hands. 6-34 bizhub C451/C550/C650...

  • Page 257: Clearing A Paper Misfeed In Tray 4

    Load the paper into the tray again, lower the paper take-up roller, and then close the tray. Reminder When removing misfed paper, remove it without lifting the paper take-up roller. Be careful not to touch the surface of the paper take-up roller with your hands. bizhub C451/C550/C650 6-35...

  • Page 258: Clearing A Paper Misfeed In The Tray 3/4 Horizontal Transport Unit

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. Pull out tray 4. Pull out the tray 3/4 horizontal transport unit. Open the cover for the tray 3/4 horizontal transport unit. Remove any misfed paper in the tray 3/4 horizontal transport unit. 6-36 bizhub C451/C550/C650...
  • Page 259 Load the paper into the tray again, lower the paper take-up roller, and then close the tray. Reminder When removing misfed paper, remove it without lifting the paper take-up roller. Be careful not to touch the surface of the paper take-up roller with your hand. bizhub C451/C550/C650 6-37...

  • Page 260: Clearing A Paper Misfeed In The Lct

    Clearing a paper misfeed in the LCT Slide the LCT away from the machine. Slowly remove any misfed paper from the feed slot of the LCT. Open the misfeed-clearing cover, and then slowly pull out any misfed paper. Close the misfeed-clearing cover. 6-38 bizhub C451/C550/C650...
  • Page 261 Load the paper into the tray again, lower the paper take-up roller, and then close the tray. Reminder When removing misfed paper, remove it without lifting the paper take-up roller. Be careful not to touch the surface of the paper take-up roller with your hand. bizhub C451/C550/C650 6-39...

  • Page 262: Clearing A Banner Paper Misfeed

    Pull up the upper right-side door release lever, and then open the upper right-side door. Slowly remove any misfed paper from the main unit. – If the edge of the paper cannot be grabbed, turn the mis- feed-clearing dial to feed out the paper. 6-40 bizhub C451/C550/C650...
  • Page 263 Troubleshooting – If the edge of the paper is not visible, open the door of the bypass tray, and then remove the paper. Slowly remove all paper from the fusing unit. bizhub C451/C550/C650 6-41...
  • Page 264 Troubleshooting – If the paper is zigzag folded and jammed in the fusing unit, open the fusing unit cover, and then remove the paper. Slowly remove any misfed paper. Close the upper right-side door. 6-42 bizhub C451/C550/C650...
  • Page 265 Be careful not to touch the surface of the image transfer belt or the image transfer roller. Image transfer belt Image transfer roller Be careful not to touch the film and surface of the paper take-up roller with your hands. bizhub C451/C550/C650 6-43...

  • Page 266: Clearing A Paper Misfeed In Finisher Fs-517

    Do not forcefully push or pull the sensor pin in the horizontal transport unit, otherwise the horizontal transport unit may be damaged. Open the machine’s front door. Lower guide lever FN2, and then remove any paper. Return guide lever FN2 to its original position. 6-44 bizhub C451/C550/C650...
  • Page 267 Return guide lever FN4 to its original position. Lower guide lever FN5, and then remove any paper. – If the paper cannot be removed, turn misfeed-clearing dial FN3 to feed out the paper. Return guide lever FN5 to its original position. bizhub C451/C550/C650 6-45...
  • Page 268 Grab handle FN7, and then pull out the stacker unit. – Slowly pull out the stacker unit as far as possible. Remove any misfed paper from the stacker unit. – If the paper cannot be removed, turn misfeed-clearing dial FN6 to feed out the paper. 6-46 bizhub C451/C550/C650...
  • Page 269 Troubleshooting Return the stacker unit to its original position. – When returning the stacker unit to its original position, grab handle FN7, otherwise your hand or fingers may be pinched. Close the front door. bizhub C451/C550/C650 6-47...

  • Page 270: Clearing A Paper Misfeed In Finisher Fs-608

    Do not forcefully push or pull the sensor pin in the Sensor pin horizontal transport unit, otherwise the horizontal transport unit may be damaged. Open the machine’s front door. Lower guide lever FN2, and then remove any paper. 6-48 bizhub C451/C550/C650...
  • Page 271 Return guide lever FN4 to its original position. Lower guide lever FN5, and then remove any paper. – If the paper cannot be removed, turn misfeed-clearing dial FN3 to feed out the paper. Return guide lever FN5 to its original position. bizhub C451/C550/C650 6-49...
  • Page 272 Slowly pull out the stacker unit as far as possible. Lower guide lever FN9, and then remove any paper. Open guide lever FN8, and then remove any paper. – If the paper cannot be removed, turn misfeed-clearing dial FN7 to feed out the paper. 6-50 bizhub C451/C550/C650...
  • Page 273 FN7 to feed out the paper. Return the stacker unit to its original position. – When returning the stacker unit to its original position, do not grab handle FN6, otherwise your hand or fingers may be pinched. bizhub C451/C550/C650 6-51...

  • Page 274: To Clear A Paper Misfeed In Finisher Fs-519

    To move the finisher away from the main unit, be sure to grab it at "2". Do not grab the mailbins or saddle stitcher to move the finisher, otherwise they may be damaged. Open the front door. 6-52 bizhub C451/C550/C650...
  • Page 275 Return guide FN3 to its original position. – If the punch kit is installed, insert the hole-punch waste container FN3.1 into its original position. Turn dial FN4 to feed the paper, open the transport unit cover, and then pull out any paper. bizhub C451/C550/C650 6-53...
  • Page 276 When returning the finisher to its original position, do not grab the handle on the front door, the control panel, the mailbins, or the saddle stitcher. Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. 6-54 bizhub C451/C550/C650...

  • Page 277: To Clear A Paper Misfeed In The Mailbin

    To clear a paper misfeed in the mailbin Open the front door. Turn dial FN5 or dial FN6 to feed out the paper. While pressing down lever FN7, pull out any paper. Pull handle FN8 to open the misfeed-clearing door. bizhub C451/C550/C650 6-55...

  • Page 278: To Clear A Paper Misfeed In The Saddle Stitcher

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. To clear a paper misfeed in the saddle stitcher Open the front door. Turn dial FN5 or dial FN6 to feed out the paper. 6-56 bizhub C451/C550/C650...
  • Page 279 Remove all paper from the finishing tray. Open the misfeed-clearing door, and then pull out any paper. Close the misfeed-clearing door. Close the front door. Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. bizhub C451/C550/C650 6-57...

  • Page 280: Clearing A Paper Misfeed In The Post Inserter

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 6-6. Raise the upper unit release lever, and then slide the upper unit to the left. Slowly remove any misfed paper. Return the upper unit to its original position. 6-58 bizhub C451/C550/C650...

  • Page 281: When The Message "Unable To Staple." Appears

    Troubleshooting When the message "Unable to staple." appears If a staple jam occurs in the finisher, the message shown below appears. Reminder Be careful when clearing jammed staples since injuries may result. bizhub C451/C550/C650 6-59...

  • Page 282: Clearing Jammed Staples In Finisher Fs-517

    For details on clearing misfed paper in Finisher FS-517, refer to "Clearing a paper misfeed in Finisher FS-517" on page 6-44. Remove all paper from the finisher. Open the front door. Grab handle FN7, and then pull out the stacker unit. – Slowly pull out the stacker unit as far as possible. 6-60 bizhub C451/C550/C650...
  • Page 283 Raise the shutter of the staple cartridge holder, and then pull out one sheet of staples. Return the shutter of the staple cartridge holder to its original position. Install the staple cartridge holder. – Check that the staple cartridge holder is securely inserted as far as possible. bizhub C451/C550/C650 6-61...
  • Page 284 Troubleshooting Return the stacker unit to its original position. – When returning the stacker unit to its original position, grab handle FN7, otherwise your hand or fingers may be pinched. Close the front door. 6-62 bizhub C451/C550/C650...

  • Page 285: Clearing Jammed Staples In Finisher Fs-608

    Grab handle FN6, and then pull out the stacker unit. – Slowly pull out the stacker unit as far as possible. Remove the staple cartridge holder. – Hold the lever on the staple cartridge holder, and then pull the holder down to remove it. bizhub C451/C550/C650 6-63...
  • Page 286 Return the shutter of the staple cartridge holder to its original position. Install the staple cartridge holder. – Check that the staple cartridge holder is securely inserted as far as possible. Return the stacker unit to its original position. 6-64 bizhub C451/C550/C650...
  • Page 287 Troubleshooting – When returning the stacker unit to its original position, do not grab handle FN6, otherwise your hand or fingers may be pinched. Close the front door. bizhub C451/C550/C650 6-65...

  • Page 288: Clearing Jammed Staples In Finisher Fs-519

    Turn the dial to the left to move the stapler toward the front. Remove the staple cartridge holder. – Pull the staple cartridge holder toward you to remove it. Raise the shutter of the staple cartridge holder, and then pull out one sheet of staples. 6-66 bizhub C451/C550/C650...

  • Page 289: Clearing Jammed Staples In The Saddle Stitcher

    6-52. Remove all paper from the finisher. Open the misfeed-clearing door, and then remove all paper. Close the misfeed-clearing door. Raise the output tray, and then push down the staple cartridge holder to remove it. bizhub C451/C550/C650 6-67...
  • Page 290 Return the shutter of the staple cartridge holder to its original position. Insert the staple cartridge holder, and then push it up until it locks into place. Return the output tray to its original position. 6-68 bizhub C451/C550/C650...

  • Page 291: When The Message "Replenish Paper." Appears

    For details on loading paper, refer to "Loading paper into tray 1 and tray 2" on page 3-49, "Loading paper into tray 4" on page 3-52, "Loading paper into the LCT" on page 3-53, and "Loading paper into the bypass tray" on page 3-54. bizhub C451/C550/C650 6-69...

  • Page 292: Message "Due To Insufficient Memory" Appears

    If the amount of memory available becomes limited while copy operations are being performed, the scanned job is erased. Check the number of pages counted for the document, and then adjust the number of pages in the document to be scanned. 6-70 bizhub C451/C550/C650...

  • Page 293: When The Message "Please Replace Following Unit(S)." Appears

    The number of pages that can be printed after the message "Please replace following unit(s)." appears and before the message "XXXX needs to be replaced." appears differs depending on the printing conditions, the consumables and the part to be replaced. bizhub C451/C550/C650 6-71...

  • Page 294: When The Message "Xxxx Needs To Be Replaced." Appears

    When the message appears, replace the specified consumables or part according to your maintenance agreement. Detail Do not throw away used consumables or parts. Instead, keep them in their boxes to be collected by your service representative. 6-72 bizhub C451/C550/C650...

  • Page 295: When The Message "Now Remote Operating. Please Do Not Turn Off The Power." Appears

    This message appears when the machine is being accessed in Administrator mode of PageScope Web Connection. Reminder Do not turn off the machine while this message is displayed. After access to the machine with PageScope Web Connection has ended, the Basic screen appears again. bizhub C451/C550/C650 6-73...

  • Page 296: Simple Troubleshooting

    Touch [Light] on the Back- ground Removal screen to select a lighter background density. (See p. 4-47.) Is the electrostatic charger wire Use the charger-cleaning tool to dirty? clean the electrostatic charger. (See p. 11-5.) 6-74 bizhub C451/C550/C650...
  • Page 297 Is the document one that does not Check that the document is one meet the specifications? that can be loaded into the ADF. (See p. 8-23 and p. 8-24.) Is the document correctly loaded? Position the document correctly. (See p. 4-8.) bizhub C451/C550/C650 6-75...
  • Page 298 If any message other than those listed above appears, perform the operation described in the message. If the problem is not corrected after the described operation is performed, contact your technical representative. 6-76 bizhub C451/C550/C650...

  • Page 299: Main Messages And Their Remedies

    An internal error occurred. Turn the The machine malfunctioned and is Inform your technical representative main switch OFF and ON. If the unable to make copies. of the code displayed on the touch trouble code appears again, contact panel. your Service Rep. bizhub C451/C550/C650 6-77...
  • Page 300 Turn off the main power switch, and attempts have failed the specified then wait about 10 seconds before number of times. turning it on again. If any message other than those listed above appears, perform the operation described in the message. 6-78 bizhub C451/C550/C650...

  • Page 301: Specifications

    Specifications...

  • Page 303: Main Unit

    **Can only be fed through the bypass tray or tray 3 or 4. (For tray 3 or 4, the setting must be changed by the technical representative.) ***Can only be fed through the bypass tray. (bizhub C451 only) Copy sizes...
  • Page 304 Specifications Specifications bizhub C451 bizhub C550 bizhub C650 Warm-up time Less than 30 seconds (at room temperature (23 °C)) (when the main power switch is turned on, then the [Power] (auxiliary power) key is turned on) Image loss width Leading edge: 4.2 mm; trailing edge: 3 mm; rear edge: 3 mm; front edge: 3 mm First copy Full color: 6.5 seconds or...

  • Page 305: Automatic Duplex Unit

    Width / Document Size A3 w A4 v B4 w B5 v A4 w A5 v B5 w A5 w o: Possible e: Not possible Note See page 3-3 for details on the available options for the several machines. bizhub C451/C550/C650...

  • Page 306: Large Capacity Unit Lu-301

    665.2 mm (790.5 mm) (W) e 656 mm (D) e 1027.5 mm (H) (Length in parentheses is with the paper tray pulled out) Weight 63 kg Consumables Staples SK-602 EH-590K (Product no. 505, Max Co., Ltd.) (containing 5,000 staples) e 2 bizhub C451/C550/C650...

  • Page 307: Finisher Fs-608

    There are five Foolscap sizes: 220 e 330 mm, 8-1/2 e 13 w, 8-1/4 e 13 w, 8-1/8 e 13-1/4 w, and 8 e 13 w. Any one of these sizes can be selected. For details, contact your technical representative. bizhub C451/C550/C650...

  • Page 308: Punch Kit Pk-512

    Power consumption Less than 66 W Dimensions 352 mm (W) × 471 mm (D) × 573 mm (H) When the tray is pulled out: 435 mm (W) Weight 33.2 kg Consumables Staples SK-602 (containing 5,000 staples) × 1 bizhub C451/C550/C650...

  • Page 309: Punch Kit Pk-510

    Plain paper (64 to 90 g/m ): Maximum 200 sheets Thick paper (91 to 256 g/m ), postcards, envelopes, OHP, or label sheets, letterheads: Maximum 20 sheets Dimensions 282 mm (W) × 368 mm (D) × 57 mm (H) Weight 0.7 kg bizhub C451/C550/C650...

  • Page 310: Maintenance Service

    – In addition, the minimum period of availability for performance parts required for repairs (parts required to maintain the efficiency of the machine) is 7 years after production of the copier ends. 7-10 bizhub C451/C550/C650...

  • Page 311: Copy Paper/Original Documents

    Copy paper/original documents...

  • Page 313: Copy Paper

    Tray 3 Tray 4 Double-sided copies 139.7 mm to 311.1 mm 148 mm to 457.2 mm bizhub C451: Banner paper Paper width: 210 mm to 297 mm Paper length: 457 mm to 1200 mm Standard-sized paper: Paper source Paper size...

  • Page 314: Paper Types And Paper Capacities

    2 Tray 3 1500 sheets 1150 sheets 800 sheets 700 sheets 600 sheets – Tray 4 1000 sheets 750 sheets 500 sheets 450 sheets 400 sheets – 3000 sheets 2500 sheets 1750 sheets 1550 sheets 1300 sheets – bizhub C451/C550/C650...
  • Page 315 Copy paper/original documents Paper type Transparencies Postcards Envelopes Label sheets Banner paper (bizhub C451 only) Paper 210 g/m source 256 g/m Bypass tray 20 sheets 50 sheets 10 sheets 50 sheets 1 sheet Tray 1 and – – – –...

  • Page 316: Special Paper

    A paper tray with this setting is not automatically selected when the "Auto" Paper setting is specified. Envelopes Select these settings when envelopes are loaded. A paper tray with this setting is not automatically selected when the "Auto" Paper setting is specified. bizhub C451/C550/C650...

  • Page 317: Precautions For Paper

    Paper that has not been loaded should be kept wrapped or placed in a plastic bag and stored in a cool, dark location with little humidity. Store the paper laying flat, not standing on its edge. Curled paper may cause paper misfeeds. Keep paper out of the reach of children. bizhub C451/C550/C650...

  • Page 318: Auto Tray Switch Feature

    Tray 1 % Tray 2 % Tray 3 % Tray 4 % LCT* * Appears only when the optional LCT is installed. Detail To change the order in which the paper trays are selected, refer to "System settings" on page 13-23. bizhub C451/C550/C650...

  • Page 319: Selecting The Paper Settings

    In the Basic screen, touch [Paper]. The Paper screen appears. Touch the button for tray 1. – To select the automatic paper detection setting for tray 2 or the bypass tray, touch the button for the corresponding paper tray. Touch [Change Tray Settings]. bizhub C451/C550/C650...

  • Page 320: Selecting A Paper Size Setting ("Size" Setting)

    The following procedure describes how to specify the setting for postcards loaded into the bypass tray. In the Basic screen, touch [Paper]. The Paper screen appears. Select the button for the bypass tray. 8-10 bizhub C451/C550/C650...
  • Page 321 Reminder If paper other than the specified paper size is loaded, a paper misfeed may occur since the paper size is not automatically detected. Detail For tray 1 and tray 2, "12-1/4 e 18 w" is available. bizhub C451/C550/C650 8-11...

  • Page 322: Specifying A Non-Standard Paper Size ("Custom Size" Settings)

    If wide paper is loaded, it will be necessary to enter the paper size. In the Basic screen, touch [Paper]. The Paper screen appears. Select the button for the bypass tray. Touch [Change Tray Settings]. Touch [Custom Size]. The Custom Size screen appears. 8-12 bizhub C451/C550/C650...
  • Page 323 % For details on storing paper sizes, refer to "Storing a non-standard paper size ("Custom Size" settings)" on page 8-14. Touch [OK], and then touch [OK] in the next two screens that appear. The Basic screen appears again. bizhub C451/C550/C650 8-13...

  • Page 324: Storing A Non-Standard Paper Size ("Custom Size" Settings)

    Storing paper sizes that are used often allows the paper size to be quickly selected, without having to re- enter the setting. In the Basic screen, touch [Paper]. The Paper screen appears. Select the button for the bypass tray. Touch [Change Tray Settings]. Touch [Custom Size]. The Custom Size screen appears. 8-14 bizhub C451/C550/C650...
  • Page 325 To cancel changes to the settings, touch [Cancel]. Touch the memory button where the paper size is to be stored. – To change the name of a memory key, touch [Change Custom Size Name], and then touch the key to be renamed. bizhub C451/C550/C650 8-15...

  • Page 326: Selecting A Setting For Oversized Paper ("Wide Paper" Settings)

    If wide paper is loaded, it will be necessary to enter the paper size. The following procedure describes how to specify the setting for wide paper loaded into the bypass tray. In the Basic screen, touch [Paper]. The Paper screen appears. 8-16 bizhub C451/C550/C650...
  • Page 327 – If tray 1 or 2 is set for wide paper, the size cannot be changed. To change the size, touch [Change Size]. The Change Size screen for oversized paper appears. bizhub C451/C550/C650 8-17...
  • Page 328 The Basic screen appears again. Note The selected size button is programmed with the entered paper size, so that the paper size is available to be selected again without being typed in. In addition, the size can be changed. 8-18 bizhub C451/C550/C650...

  • Page 329: Specifying A Setting For Special Paper

    "Single Side Only" setting is selected for the paper tray, that tray is given priority. – The auto tray switch feature applies only to paper trays specified with the same paper type setting. Touch [Change Tray Settings]. bizhub C451/C550/C650 8-19...
  • Page 330 For details on loading the paper into tray 3, refer to "Loading paper into tray 3" on page 3-51. For details on loading the paper into tray 4, refer to "Loading paper into tray 4" on page 3-52. 8-20 bizhub C451/C550/C650...

  • Page 331: Printing Double-Sided Copies Manually

    The Paper screen appears. Touch the button for the bypass tray. – A paper tray set to "2nd Side" is not selected when the "Auto" Paper setting is selected. Touch [Change Tray Settings]. Touch [Duplex 2nd Side]. bizhub C451/C550/C650 8-21...
  • Page 332 Copy paper/original documents Select the type of paper to be loaded. Touch [OK], and then touch [OK] in the next screen that appears. The Basic screen appears again. 8-22 bizhub C451/C550/C650...

  • Page 333: Original Documents

    Not possible Indicates the width of the widest document size of the mixed originals (width of the adjustable lateral guides of the automatic document feeder). Indicates document sizes that can be specified together with the maximum document width. bizhub C451/C550/C650 8-23...

  • Page 334: Precautions For Loading Documents Into The Adf

    Do not place objects exceeding 2 kg on the original glass, otherwise the original glass may be damaged. Do not press down extremely hard on a book spread on the original glass, otherwise the original glass may be damaged. 8-24 bizhub C451/C550/C650...

  • Page 335: Application Functions

    Application functions...

  • Page 337: Color Adjust Parameters And Samples

    (p. 9-19) inal (p. 9-21) Since the print samples provided are photographs, they may slightly differ in color with actual color copies. bizhub C451/C550/C650...

  • Page 338: General Information About Color

    As opposed to hue and brightness, saturation is the characteristic that indicates the degree of vividness. bizhub C451/C550/C650...
  • Page 339 2. Although the level of saturation differs for each hue and degree of brightness, creating a complex color model, we can get a better understanding of the conditions under which the hue, brightness and saturation vary. bizhub C451/C550/C650...

  • Page 340: Red" Parameter

    Application functions "Red" parameter This parameter can be used to adjust the degree of red in the image to one of 19 levels. For details on the setting procedure, refer to page 9-48. bizhub C451/C550/C650...

  • Page 341: Green" Parameter

    Application functions "Green" parameter This parameter can be used to adjust the degree of green in the image to one of 19 levels. For details on the setting procedure, refer to page 9-48. bizhub C451/C550/C650...

  • Page 342: Blue" Parameter

    Application functions "Blue" parameter This parameter can be used to adjust the degree of blue in the image to one of 19 levels. For details on the setting procedure, refer to page 9-48. bizhub C451/C550/C650...

  • Page 343: Color Balance" Parameter (Cmyk Color Adjustment)

    Changing the amount of each color of toner enables the tints in the copy to be finely adjusted. Each color can be adjusted to any of 19 levels. For details on the setting procedure, refer to page 9-48. Increasing the amount of black Adjusting the black tinge Decreasing the amount of black Black bizhub C451/C550/C650...
  • Page 344 Application functions 9-10 bizhub C451/C550/C650...

  • Page 345: Brightness" Parameter

    Application functions "Brightness" parameter This parameter can be used to finely adjust the brightness of the image to one of 19 levels. For details on the setting procedure, refer to page 9-48. bizhub C451/C550/C650 9-11...

  • Page 346: Contrast" Parameter

    Application functions "Contrast" parameter This parameter can be used to finely adjust the image to one of 19 levels between soft/smooth and crisp. For details on the setting procedure, refer to page 9-48. 9-12 bizhub C451/C550/C650...

  • Page 347: Saturation" Parameter

    Application functions "Saturation" parameter This parameter can be used to finely adjust the vividness of the image to one of 19 levels. For details on the setting procedure, refer to page 9-48.S bizhub C451/C550/C650 9-13...

  • Page 348: Sharpness" Parameter

    Application functions "Sharpness" parameter This parameter can be used to adjust the amount of contours in text and images to one of 7 levels. For details on the setting procedure, refer to page 9-48. 9-14 bizhub C451/C550/C650...

  • Page 349: Hue" Parameter

    Application functions "Hue" parameter This parameter can be used to finely adjust the hue of the image to one of 19 levels. For details on the setting procedure, refer to page 9-48. bizhub C451/C550/C650 9-15...

  • Page 350: Copy Density" Parameter

    Application functions "Copy Density" parameter This parameter can be used to finely adjust the light and shading of the image to one of 19 levels. For details on the setting procedure, refer to page 9-48. 9-16 bizhub C451/C550/C650...

  • Page 351: Single Color" Function

    This function allows you to copy an original using only one of the 21 colors available. For details on the setting procedure, refer to page 4-31. Sepia 1 Yellow Sepia 2 Magenta Camel Cyan Brown Forest Green Green Maroon Orange Copper Pumpkin Plum Yellow Green Purple Blue Pink Teal Aquamarine bizhub C451/C550/C650 9-17...

  • Page 352: Color" Function

    This setting allows you to produce copies with the black areas of the original printed in black and the color areas of the original printed in one of the six colors available. For details on the setting procedure, refer to page 4-31. Cyan Green Magenta Blue Yellow 9-18 bizhub C451/C550/C650...

  • Page 353: Background Color" Function

    This function allows you to copy an original using one of the 18 colors available as the color of the background (blank areas). For details on the setting procedure, refer to page 9-46. Yellow Camel Brown Magenta Cyan Forest Green Maroon Green Plum Purple Orange Pumpkin Pink Yellow Green Aquamarine Blue Teal bizhub C451/C550/C650 9-19...

  • Page 354: Neg-/Pos. Reverse" Function

    For details on the setting procedure, refer to page 9-41. Monotone copy Sepia 1 Yellow Sepia 2 Magenta Camel Cyan Brown Forest Green Green Maroon Orange Copper Pumpkin Plum Yellow Green Purple Blue Pink Teal Aquamarine Full-color copy and "Background Color" function 9-20 bizhub C451/C550/C650...

  • Page 355: Mirror Image" Function

    Application functions "Mirror Image" function This function allows you to copy a mirror image of the original. For details on the setting procedure, refer to page 9-43. bizhub C451/C550/C650 9-21...

  • Page 356: Inserting Paper Between Ohp Transparencies ("Ohp Interleave" Function)

    Select [Transparency] as the paper type for the bypass tray, and then touch [OK]. – For details on specifying the paper type settings, refer to "Specifying a setting for special paper" on page 8-19. Touch [Application], and then touch [Sheet/Cover/Chapter Insert]. 9-22 bizhub C451/C550/C650...
  • Page 357 To cancel the setting and select the default, press the [Reset] key. – To cancel the "OHP Interleave" function, touch [No]. Touch [OK]. Specify any other desired copy settings. – The number of copies is set to "1" and cannot be changed. Press the [Start] key. bizhub C451/C550/C650 9-23...

  • Page 358: Adding Cover Pages ("Cover Sheet" Function)

    Load the paper for the cover pages and the paper for the main body of the document into separate paper trays. – Use paper with the same size for the cover pages and for the main body of the document, and load them in the same orientation. 9-24 bizhub C451/C550/C650...
  • Page 359 – To cancel the "Cover Sheet" function, touch [No]. – The default setting for the paper tray loaded with cover pages can be specified from the Utility mode. For details, refer to "Copier setting" on page 13-33. bizhub C451/C550/C650 9-25...
  • Page 360 Select the paper tray loaded with the paper for the cover pages. Touch [OK], and then touch [OK] in the next two screen that appears. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 9-26 bizhub C451/C550/C650...

  • Page 361: Inserting Different Paper Into Copies ("Insert Sheet" Function)

    The specified paper is inserted as the 4th sheet of the copy. Double-sided copies The back side of the 2nd sheet of the copy is left blank, and the specified paper is insert- ed for the 3rd sheet of the copy. Blank bizhub C451/C550/C650 9-27...
  • Page 362 For details on using thick paper for the insertion sheets and on loading the paper, refer to "Paper types and paper capacities" on page 8-4 and "Loading paper into the bypass tray" on page 3-54. – To cancel the setting and select the default, press the [Reset] key. The Sheet/Cover/Chapter Insert screen appears. 9-28 bizhub C451/C550/C650...
  • Page 363 If "Copy" is selected, the document is copied with the specified paper inserted for the specified page. If "Blank" is selected, the specified paper is inserted after the specified page. Touch [Insert Paper]. The Insert Paper Settings screen appears. bizhub C451/C550/C650 9-29...
  • Page 364 Select the paper tray loaded with the paper for the insertion sheets, and then touch [OK]. Touch [OK], and then touch [OK] in the next screen that appears. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 9-30 bizhub C451/C550/C650...

  • Page 365: Inserting Copies Of A Different Document For A Specified Page ("Insert Image" Function)

    ("Separate Scan" setting)" on page 4-11. Touch [Application], and then touch [Sheet/Cover/Chapter Insert]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Sheet/Cover/Chapter Insert screen appears. bizhub C451/C550/C650 9-31...
  • Page 366 Touch [OK], and then touch [OK] in the next screen that appears. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. 9-32 bizhub C451/C550/C650...
  • Page 367 Scanning begins. Touch [Finish]. – To insert a multi-page document, repeat steps 9 and 10 until all pages of the insertion document are scanned in the order that they are to be inserted. Press the [Start] key. bizhub C451/C550/C650 9-33...

  • Page 368: Specifying Pages To Be Printed On The Front Side ("Chapters" Function)

    ("Separate Scan" setting)" on page 4-11. Touch [Application], and then touch [Sheet/Cover/Chapter Insert]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Sheet/Cover/Chapter Insert screen appears. 9-34 bizhub C451/C550/C650...
  • Page 369 – If "None" is selected, all pages of the copy are printed on the same paper. – To cancel the setting and select the default, press the [Reset] key. – To cancel the "Chapters" function, touch [No]. bizhub C451/C550/C650 9-35...
  • Page 370 [OK]. Touch [OK], and then touch [OK] in the next screen that appears. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 9-36 bizhub C451/C550/C650...

  • Page 371: Scanning Documents With Different Settings And Printing Copies All Together ("Program Jobs" Function)

    Touch [Application], and then touch [Sheet/Cover/Chapter Insert]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Sheet/Cover/Chapter Insert screen appears. bizhub C451/C550/C650 9-37...
  • Page 372 If the document was loaded on the original glass, touch [Finish] in the screen that appears, requesting confirmation that scanning is finished. – If "Retry" was selected, touch [Change Setting] to change the copy settings. Position the next document, and then touch [Change Setting]. 9-38 bizhub C451/C550/C650...
  • Page 373 After all document pages have been scanned, touch [Finish]. A message appears, requesting confirmation that scanning is finished. Touch [Yes], and then touch [OK]. – If "No" was selected, touch [Change Setting] to change the copy settings. bizhub C451/C550/C650 9-39...
  • Page 374 Using the keypad, type in the desired number of copies. Touch [Start] or press the [Start] key. – If [Cancel] is touched, a message appears, requesting confirmation to delete the data. To stop printing, touch [Yes], and then touch [OK]. 9-40 bizhub C451/C550/C650...

  • Page 375: Copying With Image Colors Inversed ("Neg./Pos. Reverse" Function)

    To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Edit Color screen appears. Touch [Neg./Pos. Reverse] and then touch [OK]. To cancel the "Neg./Pos. Reverse" function % Touch [Neg./Pos. Reverse] again. bizhub C451/C550/C650 9-41...
  • Page 376 Application functions Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 9-42 bizhub C451/C550/C650...

  • Page 377: Copying In A Mirror Image ("Mirror Image" Function)

    – To cancel changes to the setti – ngs for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Edit Color screen appears. Touch [Mirror Image]. The Mirror Image screen appears. bizhub C451/C550/C650 9-43...
  • Page 378 Custom Size screen, and then press the [Start] key. – To cancel the "Mirror Image" function, touch [No]. To cancel changes to the settings, touch [Cancel]. Original Size screen Custom Size screen 9-44 bizhub C451/C550/C650...
  • Page 379 [C] (clear) key in the keypad, and then specify the correct value. Specify any other desired copy settings. – To cancel the setting and select the default, press the [Reset] key. Using the keypad, type in the desired number of copies. Press the [Start] key. bizhub C451/C550/C650 9-45...

  • Page 380: Adding A Background Color To Copies ("Background Color" Function)

    Touch [Application], and then touch [Edit Color]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Edit Color screen appears. Touch [Background Color]. The Background Color screen appears. 9-46 bizhub C451/C550/C650...
  • Page 381 Touch [OK]. Specify any other desired copy settings. – To cancel the setting and select the default, press the [Reset] key. Using the keypad, type in the desired number of copies. Press the [Start] key. bizhub C451/C550/C650 9-47...

  • Page 382: Adjusting The Copy Color Quality ("Color Adjust" Parameters)

    Increasing the yellow tinge increases the amount of yellow or decreases the amount of magenta and cyan. • Increasing the black tinge increases the amount of black. Detail For sample images of the Color Adjust parameters, refer to "Color adjust parameters and samples" on page 9-3. 9-48 bizhub C451/C550/C650...

  • Page 383: To Adjust The Color Adjust Parameters

    To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Edit Color screen appears. Touch [Color Adjust]. The Color Adjustment screen appears. Touch [Brightness]. – From the Color Adjustment screen, select the desired parameter. The Brightness screen appears. bizhub C451/C550/C650 9-49...

  • Page 384: Checking The Print Result Of The Color Adjust Settings (Sample Copy)

    When the Sample Copy screen is displayed, no key other than [Reset] or [Start] can be used. Place the document on the original glass with the image to be checked positioned within the sample area. The sample copy will be printed even if the edges of the document extend off the original glass. 9-50 bizhub C451/C550/C650...
  • Page 385 Place the document within the sample area of the original glass. Press the [Start] key. The sample copy is printed. Touch [Close]. The screen for the function appears again. Note Each sample copy that is printed is counted in the print counter. bizhub C451/C550/C650 9-51...

  • Page 386: Producing Separate Copies Of Each Page In A Page Spread ("Book Copy" Function)

    How are the front and back covers copied? % Scan the front cover, then the back cover, and then scan the remainder of the document. Load the paper to be used into the desired paper tray. 9-52 bizhub C451/C550/C650...
  • Page 387 "OK". – When using the keypad to specify the settings, press the [C] (clear) key to erase the value, and then type in the setting. – To cancel the "Book Copy" function, touch [No]. bizhub C451/C550/C650 9-53...
  • Page 388 Position the next page and repeat step 10 until all pages of the document are scanned. Scanning begins. If "Book Spread" or "Separation" is selected, printing begins. If "Front Cover" or "Front and Back Cover" is selected, continue with step 11. 9-54 bizhub C451/C550/C650...
  • Page 389 – If "Front Cover" was selected, all page spreads are scanned in order after the front cover. Press the [Start] key. bizhub C451/C550/C650 9-55...

  • Page 390: Tiling Copy Images ("Image Repeat" Function)

    Load the paper to be used into the desired paper tray. Touch [Application], and then touch [Book Copy/Repeat]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Book Copy/Repeat screen appears. 9-56 bizhub C451/C550/C650...
  • Page 391 Under "Layout", touch [With Margin] or [Without Margin], or touch [2/4/8 Repeat]. – To cancel the "Image Repeat" function, touch [No]. – Touching [2/4/8 Repeat] displays the 2/4/8 Repeat screen, where the number of repeats and the interval can be selected. bizhub C451/C550/C650 9-57...
  • Page 392 What happens when a value outside of the allowable range is specified? % The message "Input error" appears. If "Input error" appears or if the value was incorrectly entered, press the [C] (clear) key in the keypad, and then specify the correct value. 9-58 bizhub C451/C550/C650...
  • Page 393 Specify any other desired copy settings. – To cancel the setting and select the default, press the [Reset] key. Using the keypad, type in the desired number of copies. Press the [Start] key. bizhub C451/C550/C650 9-59...

  • Page 394: Copying An Enlarged Image On Multiple Pages ("Poster Mode" Function)

    To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Book Copy/Repeat screen appears. Touch [Poster Mode]. – [Booklet Original] does not appear if optional Finisher FS-608 is not installed. The Poster Mode screen appears. 9-60 bizhub C451/C550/C650...
  • Page 395 Touching [Custom Size] displays the Custom Size screen. Touch [X] or [Y] to select the dimension, and then use the keypad to specify the desired value. – Touch [Paper Size], select the finished paper size, and then touch [OK]. – Touch to display a different list of paper sizes. bizhub C451/C550/C650 9-61...
  • Page 396 [Original Size], and then specify the document size from any of the screens. – Touch [Photo Size] to display the Photo Size screen. To cancel changes to the settings, touch [Cancel]. Original Size screen Custom Size screen 9-62 bizhub C451/C550/C650...
  • Page 397 [C] (clear) key in the keypad, and then specify the correct value. Specify any other desired copy settings. – The number of copies is set to "1" and cannot be changed. Press the [Start] key. bizhub C451/C550/C650 9-63...

  • Page 398: Copying Booklets ("Booklet Original" Function)

    4-72. – When using the original glass, position the pages in order, starting with the side that includes the first page, then the side that includes the second page, then the side that includes the third page. 9-64 bizhub C451/C550/C650...
  • Page 399 For details on scanning a document from the original glass, refer to "Scanning a multi-page document from the original glass" on page 4-14. After all document pages have been scanned, touch [Finish] and then press the [Start] key. bizhub C451/C550/C650 9-65...

  • Page 400: Adding A Binding Margin To Copies ("Page Margin" Function)

    For details on positioning the document, refer to "Feeding the document" on page 4-8. Touch [Application], and then touch [Page Margin]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Page Margin screen appears. 9-66 bizhub C451/C550/C650...
  • Page 401 – Touch [Left], [Right], [Top] or [Bottom] to select the direction to be adjusted, and then use the keypad or touch [-] and [+] to specify the adjustment amount. – To cancel the shift, touch [No Shift]. bizhub C451/C550/C650 9-67...
  • Page 402 For details on specifying the document orientation, refer to "Selecting the document orientation ("Original Direction" settings)" on page 4-23. Touch [OK]. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 9-68 bizhub C451/C550/C650...

  • Page 403: Adjusting The Image To Fit The Paper ("Image Adjust" Settings)

    If "Full Size" or "Center Zoom" is to be set, position the document on the original glass. Touch [Application], and then touch [Image Adjust]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Image Adjust screen appears. bizhub C451/C550/C650 9-69...
  • Page 404 If the document size cannot be detected automatically or to specify the document size, touch [Original Size], and then specify the document size from any of the screens. To cancel changes to the settings, touch [Cancel]. Original Size screen Custom Size screen 9-70 bizhub C451/C550/C650...
  • Page 405 [C] (clear) key in the keypad, and then specify the correct value. Specify any other desired copy settings. – To cancel the setting and select the default, press the [Reset] key. Using the keypad, type in the desired number of copies. Press the [Start] key. bizhub C451/C550/C650 9-71...

  • Page 406: Copying With The Page Layout Of A Booklet ("Booklet" Function)

    For details on positioning the document, refer to "Feeding the document" on page 4-8. Touch [Application], and then touch [Booklet]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. 9-72 bizhub C451/C550/C650...
  • Page 407 To cancel the setting and select the default, press the [Reset] key. – To cancel the "Booklet" function, touch [No]. Touch [OK]. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. bizhub C451/C550/C650 9-73...

  • Page 408: Erasing Specified Areas Of Copies ("Frame Erase" Function)

    % The same width is erased on all four sides of the original. The factory default setting is "Frame". Can the settings be combined? % "Frame" cannot be combined with the other settings ("Top", "Left", "Right" or "Bottom"). 9-74 bizhub C451/C550/C650...
  • Page 409 [C] (clear) key in the keypad, and then specify the correct value. Touch [OK]. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. bizhub C451/C550/C650 9-75...

  • Page 410: Printing The Date/Time Or Page Number On Copies ("Stamp/Composition" Functions)

    For details on printing a copy protection stamp, refer to page 9-86. To details on printing a repeating stamp, refer to page 9-92. For details on printing an overlay, refer to page 9-101. For details on printing a header/footer, refer to page 9-102. 9-76 bizhub C451/C550/C650...

  • Page 411: Printing The Date/Time ("Date/Time" Function)

    To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Stamp/Composition screen appears. Touch [Date/Time]. The Date/Time screen appears. Touch buttons under "Date Format", "Time Format" and "Pages" to specify the various settings. bizhub C451/C550/C650 9-77...
  • Page 412 What happens when a value outside of the allowable range is specified? % The message "Input error" appears. If "Input error" appears or if the adjustment value was incorrectly entered, touch [No Adjustment] or press the [C] (clear) key, and then specify the correct value. 9-78 bizhub C451/C550/C650...
  • Page 413 Touch [OK], and then touch [Close] in the next screen that appears. Specify any other desired copy settings. – To cancel the setting and select the default, press the [Reset] key. Using the keypad, type in the desired number of copies. Press the [Start] key. bizhub C451/C550/C650 9-79...

  • Page 414: Printing The Page Number ("Page Number" Function)

    To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. – The Stamp/Composition screen appears. Touch [Page Number]. – The Page Number screen appears. Using the keypad, type in the starting page number for printing. 9-80 bizhub C451/C550/C650...
  • Page 415 What happens when a value outside of the allowable range is specified? % The message "Input error" appears. If "Input error" appears or if the adjustment value was incorrectly entered, touch [No Adjustment] or press the [C] (clear) key, and then specify the correct value. bizhub C451/C550/C650 9-81...
  • Page 416 If "Skip the Page(s)" is selected, inserted pages are not counted and page numbers are not printed on them. – To specify the text color, touch [Text Color], and then select the color. – To specify the text size, touch [Text Size], and then select the size. 9-82 bizhub C451/C550/C650...

  • Page 417: Printing Previously Registered Stamps ("Stamp" Function)

    To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Stamp/Composition screen appears. Touch [Stamp]. – To cancel the "Stamp" function, touch [No]. The Stamp screen appears. bizhub C451/C550/C650 9-83...
  • Page 418 [–] and [+] to specify the adjustment setting, and then touch [OK]. What are the limits on the adjustment amount? % The print position can be finely adjusted in 0.1 mm increments. Can no adjustments be made? % To make no left/right or up/down adjustments, touch [No Adjustment]. 9-84 bizhub C451/C550/C650...
  • Page 419 2 Color count of the Total counter. If "Color" is set to "2 Color", copies where the second color is different from the stamp text color are included in the Full Color count of the Total counter. bizhub C451/C550/C650 9-85...

  • Page 420: Printing Copy Protection Text ("Copy Protect" Function)

    Touch [Application], and then touch [Stamp/Composition]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Stamp/Composition screen appears. Touch [Copy Protect]. The Copy Protect screen appears. 9-86 bizhub C451/C550/C650...
  • Page 421 Touching [Other] displays a screen for specifying settings for other stamps. Touch the button for the desired stamp, and then touch [OK]. – To cancel the changes to the settings in each copy protection settings screen, touch [No]. – To print the copy job number, touch [Yes] under "Job Number". bizhub C451/C550/C650 9-87...
  • Page 422 Text/Background Color: Black; Density: Std.; Copy Protect Pattern: Emboss Text; Text Size: Std.; Pattern Overwrite: Front (Overwrite); Background Pattern: Pattern 1 – The setting under "Pattern Contrast" in the Copy Protect Pattern screen can only be specified in single increments between –2 and +2. Text/Background Color screen 9-88 bizhub C451/C550/C650...
  • Page 423 Application functions Density screen Copy Protect Pattern screen Text Size screen Pattern Overwrite screen bizhub C451/C550/C650 9-89...
  • Page 424 If desired, touch [Change Pos./Delete] in the Position screen, and then change the arrangement of the text. – To change the arrangement order, touch [Change Position], select the copy protection text to be moved, and then touch either [Up] or [Down]. 9-90 bizhub C451/C550/C650...
  • Page 425 2 Color count of the Total counter. If "Color" is set to "2 Color", copies where the second color is different from the color of the copy protection text are included in the Full Color count of the Total counter. bizhub C451/C550/C650 9-91...

  • Page 426: Printing Repeating Stamps ("Stamp Repeat" Function)

    – To cancel the "Stamp Repeat" function, touch [No]. – Touch [Registered Stamp] or [Preset Stamp] to display a screen containing buttons for the available stamps. Touch the button for the desired stamp, and then touch [OK]. 9-92 bizhub C451/C550/C650...
  • Page 427 To print the serial number of this machine, touch [Yes] under "Serial Number". For details on specifying settings for the serial number, contact your technical representative. – To print the copy distribution number, touch [Yes] under "Distribution Control Number". A distribution number between 1 and 99,999,999 can be specified. bizhub C451/C550/C650 9-93...
  • Page 428 Detail Settings screen, and then change the setting in the screen that appears. – As the factory default, the following settings are selected. Text Color: Black; Density: Std.; Text Size: Std.; Pattern Overwrite: Font (Overwrite) Color screen Density screen Text Size screen 9-94 bizhub C451/C550/C650...
  • Page 429 If desired, touch [Change Pos./Delete] in the Position screen, and then change the arrangement of the text in the Change Position/Delete screen. – To change the arrangement order, touch [Change Position], select the repeating stamp text to be moved, and then touch either [Up] or [Down]. bizhub C451/C550/C650 9-95...
  • Page 430 2 Color count of the Total counter. The same will occur if the document is a single color other than black and the color for the repeating stamp is set to "Black". 9-96 bizhub C451/C550/C650...

  • Page 431: Printing The Image Scanned First Overlapped By The Remaining Document Pages ("Overlay" Function)

    – To cancel the "Overlay" function, touch [No]. The Overlay screen appears. Select the desired settings for "Pages" and "Color". – To print the overlay image only on the first copied page, touch [Cover Only] under "Pages". bizhub C451/C550/C650 9-97...
  • Page 432 To cancel changes to the settings, touch [Cancel]. Original Size screen Custom Size screen Photo Size screen Touch [Close]. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 9-98 bizhub C451/C550/C650...

  • Page 433: Saving A Scanned Image As A Registered Overlay ("Overlay" Function)

    The Image Name Registration screen appears. Type in the image name, and then touch [OK]. – Touch the buttons in the keyboard that appears in the screen to type. For details on typing in text, refer to "Entering text" on page 14-3. bizhub C451/C550/C650 9-99...
  • Page 434 Specify any other desired copy settings. Press the [Start] key. The document is scanned, then saved as a registered overlay. Note With the "Restrict User Access" parameter in Administrator mode, changes to a registered overlay without administrator permission can be prevented. 9-100 bizhub C451/C550/C650...

  • Page 435: Using A Registered Overlay ("Overlay" Function)

    After touching the button for the registered overlay, the date that the overlay was registered appears. Touch [OK] and then touch [Close] in the next screen that appears. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. bizhub C451/C550/C650 9-101...

  • Page 436: Printing A Header/Footer ("Header/Footer" Function)

    To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. – If no header/footer is registered in Administrator mode, [Header/Footer] does not appear. The Header/Footer screen appears. 9-102 bizhub C451/C550/C650...
  • Page 437 To check or temporarily change the header/footer settings, touch [Check/Change Temporarily]. Touch [OK], and then touch [Close]. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. bizhub C451/C550/C650 9-103...

  • Page 438: Saving The Scanned Document In A User Box ("Save In User Box" Function)

    To type in a user box number to specify the user box, touch [Enter User Box No.]. – It is not necessary to enter the password when saving data, even if a password has been specified for the box. 9-104 bizhub C451/C550/C650...
  • Page 439 The name specified as the default appears beside "Document Name". – For details on typing in text, refer to "Entering text" on page 14-3. After typing in the name, touch [OK]. – To cancel the "Save in User Box" function, touch [No]. bizhub C451/C550/C650 9-105...
  • Page 440 If [Yes] beside "Page Print" was selected, the scanned document is copied and the document data is saved in the specified user box. If [No] beside "Page Print" was selected, the data for the scanned document is saved in the specified user box. 9-106 bizhub C451/C550/C650...

  • Page 441: Replacing Toner Cartridges And Staples And Emptying Punch Scrap Box

    Replacing toner cartridges and staples and emptying punch scrap box...

  • Page 443: Replacing The Toner Cartridge

    When it is time to replace the toner cartridge, an advanced warning message similar to the one shown below appears. Note When the message appears, replace the toner cartridge according to your maintenance agreement. In addition, do not replace the toner cartridge for any color not indicated in the message. bizhub C451/C550/C650 10-3...
  • Page 444 Display in Enlarge Display mode When the toner is about to run out, a screen similar to the one shown below appears. When it is time to replace the toner cartridge, a screen similar to the one shown below appears. 10-4 bizhub C451/C550/C650...
  • Page 445 Be careful not to spill toner inside the machine or get toner on your clothes or hands. If your hands become soiled with toner, immediately wash them with soap and water. If toner gets in your eyes, immediately flush them with water, and then seek professional medical attention. bizhub C451/C550/C650 10-5...

  • Page 446: To Replace The Toner Cartridge

    Can a toner cartridge of a different color be installed? % The toner cartridge of a color different than the one that was removed cannot be installed. If the wrong toner cartridge is installed with extreme force, the machine may be damaged. 10-6 bizhub C451/C550/C650...
  • Page 447 Align the toner cartridge with the slots in the cartridge compartment, and then insert the cartridge. – When inserting the new toner cartridge, fully insert it until it snaps into place. Close the upper front door. bizhub C451/C550/C650 10-7...

  • Page 448: Replacing The Waste Toner Box

    When it is time to replace the waste toner box (and if it is replaceable by the user), the message "Waste toner box needs to be replaced. Replace it following the instructions." appears and the machine stops operating. 10-8 bizhub C451/C550/C650...
  • Page 449 Replacing toner cartridges and staples and emptying punch scrap box Display in Enlarge Display mode When it is almost time to replace the waste toner box, the screen shown below appears. When the time to replace the part is reached, the following screen appears. bizhub C451/C550/C650 10-9...

  • Page 450: To Replace The Waste Toner Box

    Release the securing levers for the waste toner box, and then remove the waste toner box. Attach the enclosed cap to the waste toner box removed in step 2. Place the waste toner box with the cap attached into the plastic bag. 10-10 bizhub C451/C550/C650...
  • Page 451 If toner gets in your eyes, immediately flush them with water, and then seek professional medical attention. Reminder Do not tilt the removed waste toner box, otherwise waste toner may spill. Be sure that the waste toner box is firmly secured by its securing levers. bizhub C451/C550/C650 10-11...

  • Page 452: Replacing An Imaging Unit

    If it is time to replace an imaging unit other than the black imaging unit, printing can continue in black. Touch [Continue Operation], and then select the job to be printed. Detail For details on replacing the imaging unit, refer to "To replace the imaging unit (black)" on page 10-14. 10-12 bizhub C451/C550/C650...
  • Page 453 Be sure to replace the imaging unit only after the message "Please replace following unit(s)." appears. In addition, do not replace the imaging unit of any color other than the one indicated in the message on the touch panel. bizhub C451/C550/C650 10-13...

  • Page 454: To Replace The Imaging Unit (Black)

    Check that an imaging unit of the same color as the one to be replaced has been prepared. Release the securing levers for the waste toner box, and then remove the waste toner box. Release the securing lever for the imaging unit. Remove the imaging unit. 10-14 bizhub C451/C550/C650...
  • Page 455 Do not hold the top part of the imaging unit, otherwise the PC drum may be damaged, resulting in decreased image quality. Peel off the tape, and then remove the packing material. Remove the imaging unit from the black protective bag. Remove the packing material and securing material. bizhub C451/C550/C650 10-15...
  • Page 456 – Do not insert the imaging unit into its compartment at an angle. – Make sure that the imaging unit is fully inserted into its compartment. Close the securing lever for the imaging unit. 10-16 bizhub C451/C550/C650...
  • Page 457 % Do not throw away used imaging units. Instead, keep them in their boxes to be collected by your technical representative. Adjust the gradation levels. – For details on adjusting the gradation levels, refer to "Gradation adjustment" on page 13-63. bizhub C451/C550/C650 10-17...

  • Page 458: To Replace The Imaging Unit (Yellow, Magenta And Cyan)

    Check that an imaging unit of the same color as the one to be replaced has been prepared. Release the securing levers for the waste toner box, and then remove the waste toner box. Release the securing lever for the imaging unit. 10-18 bizhub C451/C550/C650...
  • Page 459 – Do not hold the top part of the imaging unit, otherwise the PC drum may be damaged, resulting in decreased image quality. Remove the packing material. Remove the imaging unit from the black protective bag. bizhub C451/C550/C650 10-19...
  • Page 460 Remove the securing material and tape. Remove the tape from the protective sheet for the PC drum. Remove the protective sheet for the PC drum. 10-20 bizhub C451/C550/C650...
  • Page 461 Do not insert the imaging unit into its compartment at an angle. – Make sure that the imaging unit is fully inserted into its compartment. Close the securing lever for the imaging unit. Install the waste toner box. Close the lower front door. bizhub C451/C550/C650 10-21...
  • Page 462 Be careful not to spill toner inside the machine or get toner on your clothes or hands. If your hands become soiled with toner, immediately wash them with soap and water. If toner gets in your eyes, immediately flush them with water, and then seek professional medical attention. 10-22 bizhub C451/C550/C650...

  • Page 463: Replacing The Staple Cartridge

    When the staple cartridge is empty, the message "Replace staple cartridge." appears. Replace the staple cartridge. Display in Enlarge Display mode Reminder Be sure to replace the staple cartridge only after the message appears, otherwise the machine may be damaged. bizhub C451/C550/C650 10-23...

  • Page 464: To Replace The Staple Cartridge In Finisher Fs-517

    Grab handle FN7, and then pull out the stacker unit. – Slowly pull out the stacker unit as far as possible. Remove the staple cartridge holder. – Hold the lever on the staple cartridge holder, and then pull the holder down to remove it. 10-24 bizhub C451/C550/C650...
  • Page 465 Slowly peel off the stopper tape. Install the staple cartridge holder. – Check that the staple cartridge holder is securely inserted as far as possible. bizhub C451/C550/C650 10-25...
  • Page 466 Replacing toner cartridges and staples and emptying punch scrap box Return the stacker unit to its original position. – When returning the stacker unit to its original position, grab handle FN7, otherwise your hand or fingers may be pinched. Close the front door. 10-26 bizhub C451/C550/C650...

  • Page 467: To Replace The Staple Cartridge In Finisher Fs-608

    Grab handle FN6, and then pull out the stacker unit. – Slowly pull out the stacker unit as far as possible. Remove the staple cartridge holder. – Hold the lever on the staple cartridge holder, and then pull the holder down to remove it. bizhub C451/C550/C650 10-27...
  • Page 468 Slowly peel off the stopper tape. Install the staple cartridge holder. – Check that the staple cartridge holder is securely inserted as far as possible. 10-28 bizhub C451/C550/C650...
  • Page 469 Replacing toner cartridges and staples and emptying punch scrap box Return the stacker unit to its original position. – When returning the stacker unit to its original position, grab handle FN6, otherwise your hand or fingers may be pinched. Close the front door. bizhub C451/C550/C650 10-29...

  • Page 470: To Replace The Staple Cartridge In Finisher Fs-519

    Remove the empty cartridge from the staple cartridge holder. Load the new staple cartridge into the staple cartridge holder. – Do not remove the remaining staples, otherwise the machine will not be able to staple after the cartridge is replaced. 10-30 bizhub C451/C550/C650...
  • Page 471 Check that the staple cartridge holder is securely installed. Close the front door. Reminder Replace the staple cartridge only after the message has appeared. If the staple cartridge is replaced before the message appears, the machine may be damaged. bizhub C451/C550/C650 10-31...

  • Page 472: To Replace The Staple Cartridge In Saddle Stitcher

    Press in the area marked "PUSH" to unlock the staple cartridge holder. Remove the empty staple cartridge from the staple cartridge holder. Load the new staple cartridge into the staple cartridge holder. 10-32 bizhub C451/C550/C650...
  • Page 473 When inserting the staple cartridge holder, be sure to insert it so that it faces the correct direction. Return the copy output tray to its original position. Pull the handle of the misfeed-clearing door to open it, and then close it. bizhub C451/C550/C650 10-33...

  • Page 474: Emptying The Punch Scrap Box

    The setting for emptying the punch scrap box should be specified by the technical representative. For details, contact the technical representative. The default setting is "Service". If a message appears, immediately contact the technical representative. Screen when a Punch setting is selected 10-34 bizhub C451/C550/C650...
  • Page 475 Replacing toner cartridges and staples and emptying punch scrap box Screen while a job is being performed bizhub C451 bizhub C550/650 Detail When performed by user If the punch scrap box has become full while a job is being performed, the job being performed is paused.
  • Page 476 Replacing toner cartridges and staples and emptying punch scrap box Display in Enlarge Display mode bizhub C451 bizhub C550/C650 10-36 bizhub C451/C550/C650...

  • Page 477: To Empty The Punch Scrap Box In Finisher Fs-517/Fs-608

    Follow the procedure described below to empty the punch scrap box. Open the front door. Pull out the punch scrap box. Empty the punch scrap box. Insert the punch scrap box into its original position. Close the front door. bizhub C451/C550/C650 10-37...

  • Page 478: To Empty The Punch Scrap Box In Finisher Fs-519

    Follow the procedure described below to empty the punch scrap box. Open the front door. Pull out the punch scrap box FN3.1. Empty the punch scrap box. Insert the punch scrap box into its original position. Close the front door. 10-38 bizhub C451/C550/C650...

  • Page 479: Care Of The Machine

    Care of the machine...

  • Page 481: Cleaning

    Clean the surface of the original glass by wiping it with a soft, dry cloth. Reminder Never use solvents, such as benzene or thinner, to clean the original glass. Left partition glass Clean the left partition glass with the left partition glass cleaner. bizhub C451/C550/C650 11-3...

  • Page 482: Control Panel

    Never use solvents, such as benzene or thinner, to clean the document pad. Paper take-up rollers Clean the paper take-up rollers by wiping them with a soft, dry cloth. Reminder Never use solvents, such as benzene or thinner, to clean the paper take-up rollers. 11-4 bizhub C451/C550/C650...

  • Page 483: Electrostatic Charger Wire

    Securely insert the charger-cleaning tool, and then close the front door. Print head If the print head becomes dirty, decreased print quality may result. If this occurs, clean the print head according to the following procedure. Pull out tray 1. Remove the cleaning tool from tray 1. bizhub C451/C550/C650 11-5...
  • Page 484 Care of the machine Insert the cleaning tool into the print head cleaning opening, pull it out, and then repeat this back-and-forth movement two or three times. 11-6 bizhub C451/C550/C650...

  • Page 485: Viewing Counters (Meter Count)

    % Touch [Print List], select the paper size, and then press the [Start] key. Touch [Close], and then touch [Close] in the next screen that appears. The Basic screen appears again. Note The list of counters can be displayed even while the machine is copying or printing. bizhub C451/C550/C650 11-7...

  • Page 486: Viewing The Coverage Rate

    Touch [Meter Count], and then touch [Check Details] in the left panel. The Meter Count screen appears. Touch [Coverage Rate]. Touch [Close], and then touch [Close] in the next screen that appears. The Basic screen appears again. 11-8 bizhub C451/C550/C650...

  • Page 487: When The Message "It Is Time For The Scheduled Inspection Of The Device." Appears

    When the message "It is time for the scheduled inspection of the device." appears If the message "It is time for the scheduled inspection of the device." appears, contact your technical representative and request a periodic maintenance inspection. bizhub C451/C550/C650 11-9...
  • Page 488 Care of the machine 11-10 bizhub C451/C550/C650...

  • Page 489: Managing Jobs

    Managing jobs...

  • Page 491: Overview Of Job List Screen

    *The values listed above are for reference and may differ from the actual values depending on other settings. When one job is finished being printed, the next queued job automatically begins. Note Up to 251 jobs, including print jobs, scanner transmission jobs, fax transmission jobs and received fax/save jobs, can be queued. bizhub C451/C550/C650 12-3...

  • Page 492: Job List Screens

    Job History list. The types of jobs that can be selected differ depending on the selected tab. The function of each button in the Job List screens is described below. 12-4 bizhub C451/C550/C650...
  • Page 493 Job History lists. For details, refer to "Checking job details" on page 12-10. [Close] button Touch to quit Job List mode and returns to the screen that was displayed before [Job List] was touched. Displayed when the Current Jobs list is displayed. bizhub C451/C550/C650 12-5...

  • Page 494: Left Panel Job List

    To display the Job List screen, touch [Job Details]. – To delete a job, select the job from the job list, and then touch [Delete]. – When there are more jobs than the seven that can be displayed at one time, touch display other jobs. 12-6 bizhub C451/C550/C650...
  • Page 495 As the factory default, the display for the sub display area is that when "Job Display Setting" is set to "List Display". For details on specifying the default display for the left panel and the display method for the left panel Job List, refer to "Custom display settings" on page 13-17. bizhub C451/C550/C650 12-7...

  • Page 496: Performing Operations On Jobs

    – If an incorrect job was selected, select a different job or touch the button for the selected job again to deselect it. A message requesting confirmation to delete the job appears. 12-8 bizhub C451/C550/C650...
  • Page 497 If user authentication settings have been applied and the machine is set so that jobs cannot be deleted by other users, the job is not deleted. A job being performed can also be deleted by selecting the job in the sub display area, then touching [Delete]. bizhub C451/C550/C650 12-9...

  • Page 498: Checking Job Settings

    Displayed only for jobs on the Current Jobs list Displayed only for jobs on the Job History list Displayed only for jobs on the Currently Jobs list transmitted to multiple destinations Displayed only with external server authentication 12-10 bizhub C451/C550/C650...

  • Page 499: Displaying The Current Jobs List (Stored Jobs And Active Jobs)

    The Current Jobs list of received print jobs for Copy mode and Fax mode and for computer printing is displayed. Touch [Job List] in the left panel, and then touch [Job Details]. The Job List screen appears. Touch the button for the desired list. bizhub C451/C550/C650 12-11...

  • Page 500: Displaying The Job History List

    The Job History list of the Print tab appears. Touch the button for the desired list. – Deleted Jobs: Displays only jobs that were deleted before they were finished. – Finished Jobs: Displays only jobs that were correctly completed. – All Jobs: Displays all jobs. 12-12 bizhub C451/C550/C650...

  • Page 501: Printing A Stored Job

    How is printing of a proof copy stopped? % Press the [Stop] key. Detail To change the settings, touch [Check Job Set.] in the Release Held Job screen. For details, refer to "Printing a stored job" on page 12-14. bizhub C451/C550/C650 12-13...
  • Page 502 If an incorrect job was selected, select a different job or touch the button for the selected job again to deselect it. – To continue without changing the specified copy settings, continue with step 6. Touch [Change Setting]. The Change Setting screen appears. 12-14 bizhub C451/C550/C650...
  • Page 503 In the Release Held Job screen, touch [OK] or press the [Start] key. The stored job appears in the Current Jobs list and is printed. How is the removal of a job from the Held Jobs list stopped? % Touch [Cancel]. bizhub C451/C550/C650 12-15...

  • Page 504: Increasing Printing Priority

    If an incorrect job was selected, select a different job or touch the button for the selected job again to deselect it. The selected job moves to the top of the list and printing of the job begins. How can the change in the printing priority be stopped? % Touch [Cancel]. 12-16 bizhub C451/C550/C650...

  • Page 505: Utility Mode

    Utility mode...

  • Page 507: Overview Of Utility Mode Parameters

    [2] Custom Display Set- [1] Copier Settings Refer to "Custom display tings settings" on page 13-17. [2] Scan/Fax Settings [3] Copy Screen [4] Fax Active Screen [5] Color Selection Set- tings [6] Left Panel Display De- fault bizhub C451/C550/C650 13-3...
  • Page 508 [4] PS Setting [5] Print Reports [6] Change Password Changes the password for the user who is currently logged on. [7] Change E-Mail Address E-Mail Address Changes the e-mail ad- dress for the user who is currently logged on. 13-4 bizhub C451/C550/C650...

  • Page 509: Create One-Touch Destination

    Refer to "Network setting" on page 13-32. [2] NetWare Settings [3] HTTP Server Settings [4] FTP Setting [5] SMB Setting [6] LDAP Settings [7] E-Mail Settings [8] SNMP Settings [9] AppleTalk Settings [0] Bonjour Settings (next screen) bizhub C451/C550/C650 13-5...
  • Page 510 Settings [4] Check Consumable Print List Refer to "Check consuma- Life ble life" on page 13-39. [6] Banner Printing Allow For details on the banner (bizhub C451) printing, refer to the User Restrict Manual – Print Operations. 13-6 bizhub C451/C550/C650...

  • Page 511: Access Level

    Using the Access Level settings on this machine, the security of registered destinations can be managed by permitting/prohibiting viewing of the destination information or fax transmissions to the destination. Access permission levels can be set to one of six levels between 0 and 5, with the higher number indicating higher security. bizhub C451/C550/C650 13-7...

  • Page 512: Level Settings

    A destination can be registered in only one group. However, a user can be registered in multiple groups. Access Allow Level 3 Destination 1 User 1 User 3 User 2 Destination 2 13-8 bizhub C451/C550/C650...

  • Page 513: Specifying A Group Setting

    Touch the button for the desired group, and then touch [Edit]. The Edit screen appears. Touch [Group Name]. – For details on typing in text, refer to "Entering text" on page 14-3. The Group Name screen appears. bizhub C451/C550/C650 13-9...

  • Page 514: Specifying A Destination Level

    The User Authentication/Account Track screen appears. Touch [7 Limiting Access to Destinations]. The Limiting Access to Destinations screen appears. Touch [2 Apply Levels/Groups to Destinations]. The Apply Levels/Groups to Destinations screen appears. Touch the button for the desired destination. 13-10 bizhub C451/C550/C650...
  • Page 515 Touch the button for a group, touch [Details], and then check the destinations and names of users belonging to that group. – To specify the destination group, touch [Apply Group]. Touch the button for the desired group, and then touch [OK]. bizhub C451/C550/C650 13-11...

  • Page 516: Specifying A User Level

    To specify the user level, touch [Apply Level]. Touch [Yes], touch the button for the desired level, and then touch [OK]. – Touch the button for a group, touch [Details], and then check the destinations and names of users belonging to that group. 13-12 bizhub C451/C550/C650...

  • Page 517: Displaying The Destination Registration Screen

    Touch [1 One-Touch/User Box Registration]. – An item can also be selected by pressing the key in the keypad for the number beside the desired button. For [1 One-Touch/User Box Registration], press the [1] key in the keypad. bizhub C451/C550/C650 13-13...
  • Page 518 The One-Touch/User Box Registration screen appears. Note To finish specifying settings in the Utility mode, press the [Utility/Counter] key. Otherwise, exit the Utility mode by touching [Close] in each screen until the screen for the Copy, Fax/Scan or Box mode appears. 13-14 bizhub C451/C550/C650...

  • Page 519: Specifying User Settings

    Auto Color Level Adjustment Description Default Setting Adjust the reference level for detecting a color or black-and-white document when the Standard (3) "Auto Color" setting is selected. The reference level can be set to one of 5 settings. bizhub C451/C550/C650 13-15...
  • Page 520 The document size is determined to be A4, and copies are produced on A4-size pa- per. • Prohibit Copy: Copies cannot be produced since the document size cannot be detected. Before pressing the [Start] key, the paper tray (paper to be printed on) must be selected. 13-16 bizhub C451/C550/C650...

  • Page 521: Custom Display Settings

    Copy mode is displayed. Fax Active Screen Parameter Description TX Display Specify settings for faxing. For details, refer to the User manual – Fax Operations (Op- tion) and the User manual – Network Fax Operations (Option). RX Display bizhub C451/C550/C650 13-17...
  • Page 522 Select" setting selected. • Print: The Zoom setting is automatically set and the copy is printed on paper of the specified size in the specified orientation. • Delete Job: The job is deleted, and no copies are printed. 13-18 bizhub C451/C550/C650...
  • Page 523 • Accept: Print data and fax data can be accepted and printed. • Receive Only: Print data and fax data is printed after the copy opera- tion is finished. bizhub C451/C550/C650 13-19...

  • Page 524: Printer Settings

    Specify settings for printing. For details, refer to the User manual – Print Op- erations. Paper Settings PCL Settings PS Setting Print Reports The Print function settings can be printed as a report. For details, refer to the User manual – Print Operations. 13-20 bizhub C451/C550/C650...

  • Page 525: Change Password

    The e-mail address for the user who is currently logged on can be changed. This parameter appears only when a user other than a public user is logged on. Note [Change E-Mail Address] appears only if the "Administrator Security Levels" parameter in Administrator mode is set to "Level 2" bizhub C451/C550/C650 13-21...

  • Page 526: Displaying The User Settings Screen

    The User Settings screen appears. Note To finish specifying settings in the Utility mode, press the [Utility/Counter] key. Otherwise, exit the Utility mode by touching [Close] in each screen until the screen for the Copy or Box mode appears. 13-22 bizhub C451/C550/C650...

  • Page 527: Specifying Administrator Settings

    The "Bin Assignment" parameter is set to "Tray 2" only if the optional output tray is installed. Date/Time Settings Description Default Setting Specify the current date and time. In addition, the time zone can be set between -12:00 Time Zone: +00:00 and 13:00 (in 30-minute increments). bizhub C451/C550/C650 13-23...
  • Page 528 Change Regis- Select whether or not to allow registered image Allow tered Overlay overlays to be changed. Restrict Op- Restrict Broad- Select whether to prevent multiple recipients from eration casting being specified for fax transmissions. 13-24 bizhub C451/C550/C650...
  • Page 529 Cover Sheet Feed- Adjust the sensors for detecting the size of paper Upper Tray, A4 w er Size Adjustment loaded in the paper trays of the post inserter. bizhub C451/C550/C650 13-25...
  • Page 530 Adjust shifting if it can be seen at the trailing edge of the print result. Appears when optional finisher is installed. Appears when optional finisher is installed with the saddle stitcher attached. Appears when optional post inserter is installed 13-26 bizhub C451/C550/C650...
  • Page 531 Select the setting (between 1 and 9 minutes or Copy: 1 minute "OFF") for the desired length of time until the au- Scan/Fax: 1 minute tomatic panel reset operation is performed for each mode (Copy and Scan/Fax). bizhub C451/C550/C650 13-27...
  • Page 532 1 day Time Document Hold Setting Stamp Settings Parameter Description Default Setting Header/Footer Settings Program or delete header/footer settings. Fax TX Settings Select whether or not the stamp settings are canceled when Cancel a fax is sent. 13-28 bizhub C451/C550/C650...

  • Page 533: Administrator/Machine Settings

    As the factory default, the machine name is specified as "KMBT_C550" ( "KMBT_C451" on bizhub C451). The registered e-mail address is used with Internet faxing.

  • Page 534: One-Touch/User Box Registration

    [Stop Job]. • Number of User Counters Assigned: Adjust the number of users and accounts that can be registered. Example: When "# of Counters Assigned for Users" is set to "50", 950 accounts can be registered. 13-30 bizhub C451/C550/C650...
  • Page 535 This parameter appears only if user authentication or account track settings have been Tray 1/1-Sided specified. The use for each user or account can be checked. External Server Settings Description Specify the external server that performs user authentication. bizhub C451/C550/C650 13-31...

  • Page 536: Network Setting

    SMB Settings LDAP Settings E-mail Settings SNMP Settings AppleTalk Settings Bonjour Setting TCP Socket Settings Detail Settings Network Fax Setting Specify settings for using network faxing. For details, refer to the User manual – Network Fax Operations (Option). 13-32 bizhub C451/C550/C650...

  • Page 537: Copier Setting

    If the "Auto" Zoom setting is selected, the image is auto- matically rotated to fit the orientation of the paper. Printer settings Parameter Description USB Timeout Specify settings for registering print destinations. For details, refer to the User manual – Print Operations. Network Timeout bizhub C451/C550/C650 13-33...

  • Page 538: Fax Settings

    Automatic Image Rotation, Copy Operating Screen, Change E-mail Address are available to users. • Prohibit: None of the parameters that are available to users with "Level 1" or "Level 2" are available. * Available only if optional finisher FS-608 is installed. 13-34 bizhub C451/C550/C650...
  • Page 539 When the machine is turned off, then on again with the main power switch, wait at least 10 seconds to turn the machine on after turning it off. The machine may not operate correctly if it is turned on immediately after being turned off. bizhub C451/C550/C650 13-35...
  • Page 540 Box operations using the PageScope Web Connection (The User Box tab does not appear.) Stamp Settings Parameter Description Apply Stamps Select whether or not a stamp is added when printing or sending. Delete Registered Stamp Select whether or not stamps registered for copy protection can be deleted. 13-36 bizhub C451/C550/C650...

  • Page 541: Displaying The Administrator Settings Screen

    An item can also be selected by pressing the key in the keypad for the number beside the desired button. For [3 Administrator Setting], press the [3] key in the keypad. Type in the administrator password, and then touch [OK]. – For details on typing in text, refer to "Entering text" on page 14-3. bizhub C451/C550/C650 13-37...
  • Page 542 The default administrator password is "12345678". The administrator of this machine should change the administrator password. Be sure to keep the administrator password in a safe place. If the administrator password is lost, it must be specified by the technical representative. For details, contact the technical representative. 13-38 bizhub C451/C550/C650...

  • Page 543: Check Consumable Life

    Touch [4 Check Consumable Life]. – An item can also be selected by pressing the key in the keypad for the number beside the desired button. For [4 Check Consumable Life], press the [4] key in the keypad. bizhub C451/C550/C650 13-39...
  • Page 544 To print the list of usage levels, touch [Print List], and then touch [Start] or press the [Start] key. To finish specifying settings in the Utility mode, press the [Utility/Counter] key. Otherwise, exit the Utility mode by touching [Close] in each screen until the screen for the Copy, Fax/Scan or Box mode appears. 13-40 bizhub C451/C550/C650...

  • Page 545: Overview Of Weekly Timer Settings

    Set "Weekly Timer ON/OFF Settings" to "ON". Specify times for "Time Settings". Specify dates for "Date Settings". Specify the desired settings for "Select Time for Power Save" and "Password for Non-Business Hours". The weekly timer is set. bizhub C451/C550/C650 13-41...

  • Page 546: Printer Adjustment

    If the distance is more than 4.2 mm, touch [-] to reduce the adjustment (between -0.2 mm and -3.0 mm). – Each time [+] or [-] is touched, the value is increased or decreased by one increment. Press the [Start] key. The adjusted test pattern is printed. 13-42 bizhub C451/C550/C650...

  • Page 547: Centering

    Touch [2 Centering]. The Centering screen appears. Touch the button for the paper tray to be set. Press the [Start] key. – Only paper loaded into the bypass tray can be used. A test pattern is printed. bizhub C451/C550/C650 13-43...

  • Page 548: Leading Edge Adjustment (Duplex Side 2)

    The System Settings screen appears. Touch [7 Expert Adjustment]. The Expert Adjustment screen appears. Touch [2 Printer Adjustment]. The Printer Adjustment screen appears. Touch [3 Leading Edge Adjustment (Duplex Side 2)]. The Leading Edge Adjustment (Duplex Side 2) screen appears. 13-44 bizhub C451/C550/C650...

  • Page 549: Centering (Duplex 2Nd Side)

    – For details on displaying the Administrator Settings screen, refer to "Displaying the administrator settings screen" on page 13-37. Touch [1 System Settings]. The System Settings screen appears. Touch [7 Expert Adjustment]. The Expert Adjustment screen appears. bizhub C451/C550/C650 13-45...
  • Page 550 If more adjustment is necessary, repeat steps 8 and 9. – To adjust the print position for a different paper tray, return to step 6. Touch [OK]. – To cancel the setting and select the default, press the [Reset] key. The print position is adjusted. 13-46 bizhub C451/C550/C650...

  • Page 551: Finisher Adjustment

    Use the "2 Position" Staple setting to print another sample copy. Check the print result. – Check that the distance between the staples was adjusted. – If more adjustment is necessary, repeat steps 6 through 9. bizhub C451/C550/C650 13-47...

  • Page 552: Center Staple Position Adjustment

    For details on displaying the Administrator Settings screen, refer to "Displaying the administrator settings screen" on page 13-37. Touch [1 System Settings]. The System Settings screen appears. Touch [7 Expert Adjustment]. The Expert Adjustment screen appears. Touch [3 Finisher Adjustment]. The Finisher Adjustment screen appears. 13-48 bizhub C451/C550/C650...
  • Page 553 If the staple position is too far to the left of the center of the paper, touch [+] to increase the adjustment. – Each time [+] or [-] is touched, the value is increased or decreased by one increment. bizhub C451/C550/C650 13-49...

  • Page 554: Half-Fold Position

    For details on the "Center Staple & Fold" setting, refer to "Binding copies at the center ("Center Staple & Fold" setting)" on page 4-76. Before making any adjustments, use the "Half-Fold" setting to print a single sample copy. Perform the adjustment while checking the sample that was created. 13-50 bizhub C451/C550/C650...
  • Page 555 Compare the width of the left pages of the copy sample with the width of the right pages to check for the center of the paper. – If the folding position is too far to the left of the center of the paper, touch [+] to increase the adjustment. bizhub C451/C550/C650 13-51...

  • Page 556: Tri-Fold Position Adjustment

    Display the Administrator Settings screen. Touch [1 System Settings]. The System Settings screen appears. Touch [7 Expert Adjustment]. The Expert Adjustment screen appears. Touch [3 Finisher Adjustment]. The Finisher Adjustment screen appears. 13-52 bizhub C451/C550/C650...
  • Page 557 If no adjustment of the folding positions were necessary in step 7, this completes the procedure. Use the "Tri-Fold" setting to print another sample copy. Check the print result. – Check that the folding positions were adjusted. – If more adjustment is necessary, repeat steps 6 through 9. bizhub C451/C550/C650 13-53...

  • Page 558: Punch Vertical Position Adjustment

    Check the sample copy for the punch positions and for the center of the paper. – If the punch positions are too far above the center of the paper, touch [+] under "Adjust Value" to increase the adjustment (between 0.1 mm and 5.0 mm). 13-54 bizhub C451/C550/C650...

  • Page 559: Punch Horizontal Position Adjustment

    For details on displaying the Administrator Settings screen, refer to "Displaying the administrator settings screen" on page 13-37. Touch [1 System Settings]. The System Settings screen appears. Touch [7 Expert Adjustment]. The Expert Adjustment screen appears. Touch [3 Finisher Adjustment]. The Finisher Adjustment screen appears. bizhub C451/C550/C650 13-55...
  • Page 560 To increase width A, touch [+] to increase the adjustment (between 0.1 mm and 5.0 mm). – Each time [+] or [-] is touched, the value is increased or decreased by one increment. – To decrease width A, touch [-] to decrease the adjustment (between -0.1 mm and -5.0 mm). 13-56 bizhub C451/C550/C650...

  • Page 561: Punch Resist Loop Size Adjustment

    For details on displaying the Administrator Setting screen, refer to "Displaying the administrator settings screen" on page 13-37. Touch [1 System Settings]. The System Settings screen appears. Touch [7 Expert Adjustment]. The Expert Adjustment screen appears. Touch [3 Finisher Adjustment]. The Finisher Adjustment screen appears. bizhub C451/C550/C650 13-57...
  • Page 562 To cancel the setting and select the default, press the [Reset] key. The angle of the punched holes is adjusted. If no adjustment of the angle of the punched holes was necessary in step 6, this completes the procedure. Use a Punch setting to print another sample copy. 13-58 bizhub C451/C550/C650...

  • Page 563: Punch Edge Sensor Adjustment

    Touch [1 System Settings]. The System Settings screen appears. Touch [7 Expert Adjustment]. The Expert Adjustment screen appears. Touch [3 Finisher Adjustment]. The Finisher Adjustment screen appears. Touch [8 Punch Edge Sensor Adjustment]. The Punch Size Detect Sensor screen appears. bizhub C451/C550/C650 13-59...

  • Page 564: Cover Sheet Feeder Size Adjustment

    ], and then touch [4 Cover Sheet Feeder Size Adjustment]. The Cover Sheet Tray Size Adjustment screen appears. Load the selected paper in the paper tray for the post inserter, and then press the [Start] key. Touch [Close]. 13-60 bizhub C451/C550/C650...

  • Page 565: Color Registration Adjust

    X and Y directions. – If the lines are shifted in the X direction as shown below, touch [-] under "X" to reduce the adjustment (between -1 dot and -6 dots). bizhub C451/C550/C650 13-61...
  • Page 566 If there is no shift between the black and cyan lines, continue with step 11. – If more adjustment is necessary, repeat steps 8 and 9. Touch [OK]. – To cancel the setting and select the default, press the [Reset] key. 13-62 bizhub C451/C550/C650...

  • Page 567: Gradation Adjustment

    The Gradation Adjustment screen appears. Press the [Start] key. – The gradation levels cannot be adjusted if an image stabilization operation is not performed. The image stabilization operation begins. Touch the button for the mode to be adjusted. bizhub C451/C550/C650 13-63...
  • Page 568 Close the ADF. Press the [Start] key. The printed test pattern is scanned. When the test pattern is scanned, the gradation levels are automatically adjusted based on the scanned image. Repeat steps 6 through 11 three times. Touch [Close]. 13-64 bizhub C451/C550/C650...

  • Page 569: Header/Footer Settings

    The System Settings screen appears. Touch [Forward ], and then touch [2 Stamp Settings]. The Stamp Settings screen appears. Touch [1 Header/Footer Settings]. The Header/Footer Settings screen appears. Touch [New]. The Header/Footer Settings > New screen appears. bizhub C451/C550/C650 13-65...
  • Page 570 Under "Header Settings" or "Footer Settings", touch [Print], and then select the type of header/footer to be printed. Select the desired setting under "Pages", and specify the desired settings for "Text Color" and "Text Size". Touch [OK]. Detail To print the header/footer only on the first page, touch [Cover Only]. 13-66 bizhub C451/C550/C650...

  • Page 571: Editing Headers/Footers

    Utility mode Editing headers/footers In the Header/Footer Settings screen, touch the button of the header/footer to be edited. Touch [Check/Edit]. – To delete the header/footer, touch [Delete]. The Check/Edit screen appears. Touch [OK]. bizhub C451/C550/C650 13-67...

  • Page 572: Authentication Method

    Select "ON (External Server)" or "ON (MFP)". Account Track Select "ON", and then specify the account name and pass- word. Synchronize User Authentication & Account Track Select "Synchronize". Account Name (on User Registration screen) Select an account name if "ON (MFP)" was selected. 13-68 bizhub C451/C550/C650...

  • Page 573: When User Authentication And Account Track Are Used Separately

    Parameter on Authentication Method screen Settings User Authentication Select "ON (External Server)" or "ON (MFP)". Account Track Select "ON", and then specify the account name and pass- word. Synchronize User Authentication & Account Track Select "Do Not Synchronize". bizhub C451/C550/C650 13-69...

  • Page 574: Selecting An Authentication Method

    If "External Server Authentication" is set and "Account Track" is set to "ON", this setting allows the machine to be used simply by entering user authentication information after the machine has been used once with the appropriate user authentication and account track information entered. 13-70 bizhub C451/C550/C650...
  • Page 575 "Number of User Counters Assigned" appears if "User Authentication" is set to "ON (External Server)" or "ON (MFP)" and "Account Track" is set to "ON". If the number of user counters is set to "50", up to 950 accounts can be registered. bizhub C451/C550/C650 13-71...
  • Page 576 If "ON (MFP)" is set and "Account Track" is set to "ON", but the corresponding account was not specified when the user was registered, user authentication and account track information must be entered each time that the machine is used, even if "Synchronize User Authentication & Account Track" has been set to "ON". 13-72 bizhub C451/C550/C650...

  • Page 577: User Authentication Setting

    "OFF". Touch [1 Administrative Settings]. Touch [User Name List]. Buttons for the available settings appear. Touch the button for the desired setting. Whether or not a user name list button appears is set. bizhub C451/C550/C650 13-73...

  • Page 578: Default Function Permission

    % [2 User Authentication Settings] is not available if "User Authentication" on the General Settings screen is set to "OFF". Touch [1 Administrative Settings]. Touch [Default Function Permission]. The Function Permission screen appears. Touch the button for the desired settings. Touch [OK]. The default function permissions are set. 13-74 bizhub C451/C550/C650...

  • Page 579: Public User Access

    Touch [2 User Authentication Settings]. The User Authentication Setting screen appears. Why is [2 User Authentication Settings] not available? % [2 User Authentication Settings] is not available if "User Authentication" on the General Settings screen is set to "OFF". bizhub C451/C550/C650 13-75...
  • Page 580 Type in the e-mail address (up to 320 characters), and then touch [OK]. The e-mail address is set. If the e-mail address exceeds 100 characters, [Detail] appears in the User Registration screen. Touch [Details] to display the E-Mail Address Details screen and the entire e-mail address. 13-76 bizhub C451/C550/C650...
  • Page 581 If both color and black printing are restricted, the message "Copying is prohibited." appears, even if authentication was completed correctly. – If "Color" is set to "Restrict" under "Send", color scanning is not possible. Touch [OK]. The output permissions are set. Touch [Max. Allowance Set]. The Max. Allowance Set screen appears. bizhub C451/C550/C650 13-77...
  • Page 582 When using authentication unit (biometric type), place a finger on the authentication unit and register the vein patterns. – When using authentication unit (IC card type), place an IC card on the authentication unit and register the card information. Touch [Function Permission]. The Function Permission screen appears. 13-78 bizhub C451/C550/C650...
  • Page 583 If no operation is permitted, user authentication cannot be performed. Touch [OK]. The function permissions are set. Touch [OK]. – To cancel the settings in the current screen, touch [Cancel]. – To delete the selected user information, touch [Delete] in the User Registration screen. bizhub C451/C550/C650 13-79...

  • Page 584: User Counter

    If "Public User Access" on the General Settings screen was set to "Allow", "public" is added to the list of counters. If "User Box Administrator Setting" was set to "Allow", "Box Admin" is added to the list of counters. 13-80 bizhub C451/C550/C650...

  • Page 585: Viewing User Counters

    To clear the counters for all users, touch [Yes] in the confirmation message screen, and then touch [OK]. The maximum number allowed is not cleared. Touch [Close]. bizhub C451/C550/C650 13-81...

  • Page 586: Account Track Setting

    The Edit screen for the account appears. If "Account Name & Password" was selected: – If "Account Name & Password" was selected, the same account name cannot be used more than once. If "Password Only" was selected: 13-82 bizhub C451/C550/C650...
  • Page 587 Type in the password (up to 8 characters long), and then touch [OK]. A screen for retyping the password appears. Retype the password specified in step 9, and then touch [OK]. The user password is set. Touch [Output Permission]. The Output Permission screen appears. bizhub C451/C550/C650 13-83...
  • Page 588 Accounts], touch [OK], and then touch [OK] in the next screen that appears in order to display a message and apply the settings to all accounts. At this time, do not turn off the machine with the main power switch. 13-84 bizhub C451/C550/C650...

  • Page 589: Account Track Counter

    Original Counter This counter shows the number of document pages that were scanned. Paper Counter This counter shows the number of pages used for printing. Fax TX Fax TX Count: Total number of pages transmitted with fax operations bizhub C451/C550/C650 13-85...

  • Page 590: Viewing Account Counters

    A confirmation message appears, asking whether the counters should be cleared. To clear the counters for all accounts, touch [Yes] in the confirmation message screen, and then touch [OK]. The maximum number allowed is not cleared. Touch [Close]. 13-86 bizhub C451/C550/C650...

  • Page 591: Password Rules

    Specify 8 characters (numbers, * or #) as the fax transmission password for boxes. Confidential document passwords Limitations on the number of characters Limitations on registering/changing 8 alphanumeric characters and symbols • A password that consists of a repetition of the same charac- ter cannot be registered. bizhub C451/C550/C650 13-87...

  • Page 592: Enhanced Security Mode

    "Account Name & Password". If "Password Only" is selected, the setting for "Prohibit Functions When Authentication Failed" is not changed, even when "Enhanced Security Mode" is set to "ON". [SSL] appears when a certificate is registered with PageScope Web Connection. 13-88 bizhub C451/C550/C650...
  • Page 593 Operations. For details on the limitations placed on the user for printing, refer to the User manual – Print Operations. For details on canceling operation restrictions applied when authentication failed, refer to "Security settings" on page 13-34. bizhub C451/C550/C650 13-89...
  • Page 594 Utility mode 13-90 bizhub C451/C550/C650...

  • Page 595: Appendix

    Appendix...

  • Page 597: Entering Text

    The keypad can also be used to type in numbers. Any of the following keyboards may appear. Example Password input screen Screen for entering the name of a custom paper size bizhub C451/C550/C650 14-3...

  • Page 598: Enlarging The Keyboard

    To cancel the enlarged display and return the keyboard to its normal size, touch [Enlarge OFF] while the keyboard is displayed enlarged. Note The keyboard is used in the same way, even when it is displayed enlarged. 14-4 bizhub C451/C550/C650...

  • Page 599: To Type Text

    To change a character in the entered text, touch to move the cursor to the character to be changed, touch [Delete], and then type in the desired letter or number. List of available characters Type Characters Alphanumeric charac- ters/symbols bizhub C451/C550/C650 14-5...

  • Page 600: Glossary

    Set this function to print hidden text in order to prevent improper copying. When an original printed with copy protection text is copied, the hidden text appears clearly repeated in all pages of the copies so that the reader knows that it is a copy. 14-6 bizhub C451/C550/C650...
  • Page 601 Set this function to produce a copy in the mirror image of the original. Mixed Original Select this setting to detect the size of each original page and print a copy on paper of the appropriate size when an original with different page sizes is loaded together into the ADF. bizhub C451/C550/C650 14-7...
  • Page 602 Select this setting when loading thick originals or original pages pasted together into the ADF. If this setting is selected when thick originals are scanned with the ADF, there is a smaller chance of a paper misfeed occurring. 14-8 bizhub C451/C550/C650...
  • Page 603 Appendix XY Zoom Touch this button to use the keypad to specify the zoom ratio for producing an enlarged/reduced copy of the loaded original. Zoom Specify the zoom ratio of the copy. bizhub C451/C550/C650 14-9...
  • Page 604 Appendix 14-10 bizhub C451/C550/C650...
  • Page 605 Index...
  • Page 607 6-63 10-27 Finisher FS-608 10-37 Caution notations and labels 2-15 4-60 Finishing Center staple & fold 4-72 4-76 4-72 Folding 13-48 Center staple position 9-74 Frame erase Centering 13-43 Full color 4-31 13-45 Centering (duplex 2nd side) bizhub C451/C550/C650 15-3...
  • Page 608 Program jobs 9-37 9-50 Proof copies Mailbin kit MT-502 3-20 6-55 7-10 Proof copy 3-32 Main power switch 13-59 Punch edge sensor adjustment Maintenance 11-3 13-55 Punch horizontal position adjustment 1-12 Manual conventions Punch kit 3-15 3-16 15-4 bizhub C451/C550/C650...
  • Page 609 System auto reset confirmation 5-22 13-34 System connection System settings 13-15 13-23 4-86 Temporarily stopping 4-55 Text enhancement 14-3 Text entry Toner cartridge 10-3 3-27 5-19 Touch panel Tray 1 3-49 6-32 3-49 6-33 Tray 2 Tray 3 3-51 6-34 bizhub C451/C550/C650 15-5...
  • Page 610 Index 15-6 bizhub C451/C550/C650...

This manual is also suitable for:

Bizhub c550Bizhub c650

Table of Contents
