CONTENTS SAFETY INSTRUCTIONS ............................ 3 PARTS LIST ................................4 HARDWARE PACKING LIST ..........................6 EXPLODED VIEW ..............................7 ASSEMBLY INSTRUCTIONS ..........................8 INSTRUCTION MANUAL FOR TZ-6139 ......................12 MAINTENANCE ..............................15 TROUBLESHOOTING ............................16 WARM UP AND COOL DOWN ROUTINE ...................... 16 TERMS AND CONDITIONS OF WARRANTY, WARRANTY CLAIMS ............
IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s manual for future reference. The specifications of this product may vary from this photo, subject to change without notice. SAFETY INSTRUCTIONS Basic precautions should always be followed, including the following safety instructions when using this equipment: Read all instructions before using this equipment.
PARTS LIST Description Main Frame Front Stabilizer Rear Stabilizer Idle Wheel Bracket Seat Post Seat Sliding Tube Handlebar Post Handlebar U Bracket Washer Ø16xØ8x1.5 Eyebolt M8x85 End Cap For Front Stabilizer End Cap For Rear Stabilizer Big Curve Washer Ø8 Adjustable Leveler M8 Spring Ø6 Bolt M8x70...
Page 5
Washer Ø24xØ40x3.0 Washer Ø23xØ34.5x2.5 Hexagon Nut 7/8" Belt Pulley with Crank Ø240J6 AC Adapter Power supply wire Bolt M5X10 Handlebar Foam Grip Ø24xØ30x490 Left Pedal YH-30X Right Pedal YH-30X End Cap for Handlebar Cover Cap Round Knob M16 Hand Pulse Sensor with Wire L=750mm Sensor with Wire L=750mm Left Chain Cover Right Chain Cover...
ASSEMBLY INSTRUCTIONS STEP 1: FRONT AND REAR STABILIZERS INSTALLATION Position the Front Stabilizer (2) in front of the Main Frame (1) and align bolt holes. Attach the Front Stabilizer (2) onto the front curve of the Main Frame (1) with two M8x70 Bolts (17), two Ø8 Big Curve Washers (14), and two M8 Cap Nuts (30).
Page 9
STEP 2: SEAT POST, SEAT POST COVER, SEAT CUSHION, AND SEAT SLIDING TUBE INSTALLATION Slide the Seat Post Cover (59) onto the tube of the Main Frame (1). Insert the Seat Post (5) into the Seat Post Bushing (53) on the tube of the Main Frame (1) and then attach the Seat Post Knob (48) onto the tube of the Main Frame (1) by turning it in a clockwise direction with Multi Hex Tool provided to lock the Seat Post (5) in the suitable position.
Page 10
STEP 3: HANDLEBAR POST, HANDLEBAR POST COVER Remove four M8x15 Bolts (19), four Ø20xØ8x2.0 Washers (14) from the Main Frame (1). Remove bolts with the S6 Allen Wrench provided. Slide the Handlebar Post Cover (58) up to the Handlebar Post (7). Connect the Sensor Wire (69) from the Main Frame (1) to the Extension Sensor Wire (63) from the Handlebar Post (7).
Page 11
STEP 4: HANDLEBAR INSTALLATION Insert the Hand Pulse Sensor Wires (49) into the hole on the Handlebar Post (7) and then pull them out from the top end of the Handlebar Post (7). Place the Handlebar (8) through clamp on the Handlebar Post (7) with hand pulse sensors facing the seat.
Remove two M5x10 Bolts (42) from the Computer (62). Remove bolts with the Multi Hex Tool with Phillips Screwdriver provided. Connect the Hand Pulse Sensor Wires (49) and Extension Sensor Wire (63) to the wires that come from the Computer (62). Tuck wires into the Handlebar Post (7). Attach the Computer (62) onto the top end of the Handlebar Post (7) with two M5x10 Bolts (42) that were removed.
SETTING WORKOUT PARAMETERS After selecting your desired program, you may pre-set several workout parameters for desired results. WORKOUT PARAMETERS: TIME / DISTANCE / CALORIES / WATT /AGE Note: Some parameters are not adjustable in certain programs. Time and Distance cannot be set up at the same time. Once a program has been selected, pressing ENTER, will make “Time”...
Page 14
** (If user sets up the target time to workout, then the next parameter of Distance cannot be adjusted) Continue through all desired parameters, pressing START/STOP to start workout. Note: One of workout parameters counts down to be zero, it will have bi sounds and stop the workout automatically.
One of workout parameters counts down to be zero, it will have bi sounds and stop the workout automatically. Press START/STOP to continue the workout to reach unfinished workout parameter. HEART RATE CONTROL PROGRAM There are 2 selections for target pulse: P16- 65% TARGET H.R= 65% of (220-AGE) P17- 85%...
TROUBLESHOOTING The upright bike wobbles Turn the adjustable leveler on the rear stabilizer as needed to level the upright when in use. bike. 1. Remove the computer console and verify the wires that come from the computer console are properly connected to the wires that come from the handlebar post.
Page 17
SHOULDER LIFTS Lift your right shoulder toward your ear for one count. Then lift your left shoulder up for one count as you lower your right shoulder. SIDE STRETCHES Open your arms to the side and lift them until they are over your head. Reach your right arm as far toward the ceiling as you can for one count.
Page 18
INNER THIGH STRETCH Sit with the soles of your feet together and your knees pointing outward. Pull your feet as close to your groin as possible. Gently push your knees toward the floor. Hold for 15 counts. TOE TOUCHES Slowly bend forward from your waist, letting your back and shoulders relax as you stretch toward your toes. Reach as far as you can and hold for 15 counts.
CALF/ACHILLES STRETCH Lean against a wall with your left leg in front of the right and your arms forward. Keep your right leg straight and the left foot on the floor; then bend the left leg and lean forward by moving your hips toward the wall. Hold, then repeat on the other side for 15 counts.
The Seller provides the Buyer a 24 months Warranty for Goods Quality, unless otherwise specified in the Certificate of Warranty, Invoice, Bill of Delivery or other documents related to the Goods. The legal warranty period provided to the Consumer is not affected. By the Warranty for Goods Quality, the Seller guarantees that the delivered Goods shall be, for a certain period of time, suitable for regular or contracted use, and that the Goods shall maintain its regular or contracted features.
Page 21
Date of Sale: Stamp and Signature of Seller:...
