Ck2 Board Connectors - Lexmark C920 Service Manual

5056-XXX

CK2 board connectors

Conn # Orientation
CN1 Horizontal
CN2 Horizontal
CN3 Horizontal
CN4 Horizontal
CN5 Horizontal
CN6 Horizontal
CN7 Horizontal
CN8 Horizontal
CN9 Vertical
5-10
Service Manual
Board Cable
connector connector
color color
Tan Tan
Tan Tan
Magenta Red
Green Green
White White
White White
Yellow Yellow
White
Blue Blue
# Wires Wire color
8 • 8 green
12 • 12 green Controller board
2 • 2 red
2 • 2 green
3 • 3 gray
3 • 1 black
• 1 red
• 1 yellow
2 • 2 blue
2
6 • Yellow
• Black
• White
• Gray
• Blue
• Brown
Connector
Controller board
Duplex
Face up
Paper exit
Motor fan
Face U/D solenoid
Flicker 230 V only
Motor drive
