information to the platform or mobile phone.
Distance Tracking Set distance interval, the unit will, in accordance with the preset distance report location
information to the platform.
Turn Report Set turn angle, when the vehicle turn angle is greater than the preset angle, the unit will
report location information. It will implement the real trace in turn corner.

2.3.2 Alarms

Function
Disassemble Alarm
Speeding
Geo-Fence
SOS
Low Power Alarm
Terminal Status Alarm

2.3.3 Integrated Functions

Function Description
Listen-in Helps driver to know the status inside the car when it has been stolen.
OTA OTA (Over the Air) enable terminal firmware upgrade to match the latest firmware.
GPS Log When tracker obtained a valid GPS position, the terminal will record the log into buffer by
interval.
Tracking log can be read by Meitrack Manager and stored up to 130,000 records.
GPS&GSM Wherever GPS position is not available, GSM base station will use signal tower to provide an
(LBS)Tracking approximate coordinate to ensure it can be located anytime.
GPS Blind Spot When entering and exiting an area without GPS signal, the terminal will send report to
Report platform.
GSM Blind area Within a GSM blind area when normal report can't be sent to platform, reports will be
Storage/Replenish automatically stored and resume sending out reports wherever GSM signal available. Built-in
Alarm flash memory 8M, maximum GPRS 8,000 and SMS 256 reports.
Mileage Report Each GPRS data contains mileage of the vehicle. When first use, user can modify tracker's
default mileage value to match the vehicle odometer value.
ACC ON Report Select ACC ON report, the device will send ACC ON report to platform or mobile phone while
ACC ON.
ACC OFF Report Select ACC OFF report, the device will send ACC OFF report to platform or mobile phone
while ACC OFF.
SMS Text (This Trip) : Mileage, average speed, time so start, max speed, etc.
Maintenance Report Set mileage and time of maintenance via platform, the device will prompt maintenance while
time is up.
Copyright © 2014 Meitrack Group All rights reserved.
File Name MEITRACK TC68S User Guide
Project TC68S
Sub Project User Guide
Revision V1.2
Description
An alarm will be generated when the device is removed from the OBD socket.
An alarm will be generated when the speed exceeds preset speed value.
Geo-fence can be set with center coordinate and radius. In or out of the Geo-fence can
be reported to platform or mobile phone. User can set up to 8 circular Geo-fence.
Press the SOS button to generate alarm.
An alarm will be generated when the external power is less than 11.6V.
Terminal power on, restart alarm etc.
Creator
Creation Date
Update Date
Page
Confidential External Documentation
Renny Lee
2012-07-13
2014-02-26
5 of 16
