9.5.3. Schedule Menu

Use this menu to configure a schedule for capturing images from the camera to be stored.
Enable
1
Schedule
Click "Apply" at the bottom right of the page to save modified settings.
9.5.3.1.

Snapshot Menu

2
Send To
Interval
File Name
Click "Apply" at the bottom right of the page to save modified settings.
© 2014 Wirepath Surveillance
1
2
Check box to Enable Scheduling feature.
Grid with Days of the Week and Time of day for snapshots to be recorded. Enabled dates and time
appear as a Green box.
NOTE: This Schedule can also act to provide days/times when motion Events are allowed to send
notifications and send or save media. See Only in Schedule times in section .
Select the method used to send or save JPEG snapshots based on the schedule defined above.
Available options include Email, FTP, SD Card and Network Share.
Sets the interval between the snapshots for the scheduled day. Example: when set to 60 seconds, a
snapshot will be sent or saved every 60 seconds.
Enter a name to use to identify the snapshot files. Use this menu to configure the Cameras Contact &
Relay connections.
