9.
Specifications
Video
Standard .................................................................................................... DVI 1.0
Color depth ................................................................................ 24 bits, 8 bit/color
Format ..................................................................................................... RGB only
Data rate ........................................... all between 25 Mbps and 1.65 Gbps /color
Resolutions (single link) .................. all between 640x480 and 1920x1200@60Hz
HDTV resolutions .................................................................... 720p, 1080i, 1080p
HDCP compliant ................................................................................................ No
Input equalization ...................................................................... +40 dB, automatic
Reclocking ....................................................................................................... Yes
+5V output current (DVI) ..............500 mA continuous with overcurrent protection
EDID Emulation ............................ Yes, 50 factory preset, 50 user programmable
EDID Support ................................................................. 256 Byte Extended EDID
General
Connectors ............................. 29-pole DVI-I digital only and USB Type B Female
Number of DVI inputs........................................................................................... 1
Number of DVI outputs ........................................................................................ 2
Power adaptor ............................... 100-240 V AC 50/60 Hz 0.6A to +5V DC 2.6A
Power consumption ............................................................................... 4W typical
....................................... 9W max when powering fiber extenders on DVI outputs
Compliance ....................................................................................................... CE
EMI/EMC ................................................................................... EN 55022 Class B
Safety ....................................................... UL, CUL, GS, CR, RCM, PSE, Class II
Warranty ................................................................................................... 3 years
Enclosure
Rack mountable .................................................................................Yes, 1U high
Material ............................................................................................... 1 mm Metal
Dimensions .................................................... 120 mm W x 180 mm D x 42 mm H
Net Weight .................................................................................................... 700 g
Page 42 / 43
