Format:
Example:
Note: (E_S_C) arrives only if the new and the old EDID don't match.

4.8.5. Route EDID to the input (dynamic)

Description: It copies EDID from location <loc> to input <in>.
In case of DA2DVI-Pro: <in> must be 1, <loc> must be 101
Format:
Example:
Info: DVI OUTPUT 1 is mapped to logical address 101.
After choosing dynamic EDID routing for the input, the DA2DVI-Pro will follow the
EDID changes that occur on DVI OUTPUT 1.

4.8.6. Save EDID from output to memory location (Learn EDID)

Description: Learn EDID from <out> to the specified location <loc>.
In case of DA2DVI-Pro: <out> must be 1
Format:
Example:
→ {<in>:<loc>}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {1:10}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {<in>:<loc>}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {1:101}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {<out>><loc>}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
Save the EDID from DVI OUTPUT 1 to user memory address 51.
→ {1>51}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
DA2DVI-Pro
User's Manual Rev. 1.3
Page 27 / 43
