2.3. Switching the EDID

1.
2.
Info If an invalid EDID is selected, the DA2DVI-Pro does NOT transmit a HOT PLUG
signal to the source connected to the DVI INPUT.
Info After every EDID change, DA2DVI-Pro toggles the HOT PLUG signal for
approximatley 1 second. Some graphic cards or DVD players do not sense the
HOT PLUG signal, and even if EDID has been changed, the set resolution is not
affected. In this case the source device must be restarted, or powered OFF and
ON again.

2.4. Factory preset EDID list

Lightware factory preloaded EDID are specially provided to force graphic cards to
output only the exact pixel resolution and refresh rate.
Universal EDID (address 49) allows multiple resolutions including all common
VESA defined resolutions. In addition, it also features audio support. The use of
universal EDID is advised for fast and easy system setup.
MEMORY
Page 16 / 43
Use a screwdriver to change the memory address on the front side of the
DA2DVI-Pro.
After either one of the rotary switches has been rotated the unit waits
approximately 2 seconds before the selected EDID becomes active. If the
EDID status is unchanged the EDID STATUS LED does not blink.
The address 00 (zero zero) has a special function. If a monitor is connected
to DVI OUTPUT 1, then its EDID is copied to the DVI INPUT. If no monitor is
connected to the Monitor output then the EDID provided on the DVI INPUT
connector is the EDID of the last connected monitor.
Resolution
01 640x480@60 Hz
02 640x480@75 Hz
03 848x480@60 Hz 16:9
04 800x600@50 Hz
05 800x600@60 Hz
06 800x600@75 Hz
07 1024x768@50 Hz
08 1024x768@60 Hz
09 1024x768@75 Hz
10 1152x864@75 Hz
11 1280x768@50 Hz
12 1280x768@60 Hz
13 1280x768@75 Hz
14 1360x768@60 Hz
15 1364x768@50 Hz
16 1364x768@60 Hz
17 1364x768@75 Hz
18 1280x1024@50 Hz
19 1280x1024@60 Hz
20 1280x1024@75 Hz
21 1366x1024@60 Hz
22 1400x1050@50 Hz
23 1400x1050@60 Hz
24 1400x1050@75 Hz
25 1680x1050@50 Hz
Table 3. Factory Preset EDID list
MEMORY Resolution
26 1600x1200@50 Hz
27 1600x1200@60 Hz
28 1920x1200@60 Hz
29 1920x1200@50 Hz
30
31 640x480@59.94 Hz
32 720x480p@60 Hz
33
34 720x576p@50 Hz
35 1280x720p@50 Hz
36 1280x720p@60 Hz
37 1920x1080i1 @50 Hz
38 1920x1080i2 @50 Hz
39 1920x1080i@60 Hz
40 1920x1080p@24 Hz
41 1920x1080p@25 Hz
42 1920x1080p@30 Hz
43 1920x1080p1 @50 Hz
44 1920x1080p2 @50 Hz
45 1920x1080p@60 Hz
46 2048x1080p1 @50 Hz
47 2048x1080p2 @50 Hz
48 2048x1080p@60 Hz
49 UNIVERSAL EDID
50 2560x1600@60 Hz
480i@59.94 Hz
576i@50 Hz
