10. Specifications

General
Power ................................................................. 100-240 V AC; 50~60 Hz; 0.8 A
Power consumption ............................................................ 75 W (256 BTU/hour)
Compliance ..................................................................................... CE, UL, FCC
EMI/EMC ..................................................................... EN 55103-1, EN 55103-2
Safety ....................................................................................... EN 60065 Class I
Warranty ................................................................................................... 3 years
Operating temperature ................................................................. -20°C ~ +50°C
Humidity ........................................................................................... 10 ~ 90% RH
Enclosure (router)
Rack mountable ............................................................................... Yes, 4U high
DC power connector ........................................... Neutrik 4 pole Speakon NL4MP
Material ................................................................. 2 mm aluminum alloy (AlMg3)
Dimensions ....................... 482W x 32.8D x 176.5H mm (19W x 1.3D x 7H inch)
Net Weight ................................................................................... 1.85 kg (4.1 lbs)
Enclosure (power supply)
Rack mountable ............................................................................................... Yes
Material .............................................................................................. 1 mm metal
AC power connector ........................................................IEC receptacle (filtered)
DC power connector ........................................... Neutrik 4 pole Speakon NL4MP
Dimensions ......................... 200W x 110D x 86H mm (7.9W x 4.3D x 3.4H inch)
Net Weight (power supply) ........................................................... 1.42 kg (3.1 lbs)
Net Weight (power cable) ............................................................. 0.35 kg (0.8 lbs)
Inputs
Connectors ................................................................... 29-pole DVI-I digital only
Input cable equalization ............................................................ Yes, +12dB fixed
EDID emulation .................................................... Yes, for each input connector
Outputs
Connectors .................................................................... 29 pole DVI-I digital only
Output preemhasis ...................................................................... Yes, +6dB fixed
Reclocking ........................................................................................................ No
+5V output current ............ 500 mA continuous each, with overcurrent protection
