Description: The DA2DVI-Pro is set to be controlled via the USB port by SW1 of
the DIP switch.
Format:

4.10. Input and output port status

4.10.1.

Check the status of the inputs

Description: Use this command to determine the actual status of the input port.
Format:
Example:
Legend:
4.10.2.

Check the status of the outputs

Description: Use this command to determine the actual status of the output ports.
Format:
Example:
Legend:
← (NOK)CrLf
→ {:ISD}
← (ISD STATUS_TABLE)CrLf
●
→ {:ISD}
← (ISD 00112333233300033330022000000000)CrLf
0 PWR5V signal is not present on this input.
1 PWR5V signal is present on this input.
2
Active DVI signal is present at this input (data enable signal is
successfully recovered from the TMDS stream) but there is no
PWR5V.
3 Active DVI signal is present at this input (Data enable signal is
successfully recovered from the TMDS stream) with PWR5V.
→ {:OSD}
← (OSD●STATUS_TABLE)CrLf
→ {:OSD}
← (OSD 00110111001100011100011000000000)CrLf
0 There is no attached monitor
1
There is an attached monitor
DA2DVI-Pro
User's Manual Rev. 1.3
Page 31 / 43
