1200 keypad model
Installation
1) Before installing fully, test the range of the system. Wire the unit as
per wiring diagram, place the equipment in the desired location and
test operation.
2) Ensure that the gate base station is installed to facilitate line of sight
with the property or reception area. To achieve best results, mount the
base as high as possible from the ground. Should you need to extend
range, you can mount the base on a small pole to elevate it a few
meters from the ground.
Note: Wood
Entrance
and glass only
Pillar
reduce signal
strength by 10-
20%. Masonry
will reduce
signal strength
Speech
by 20-50% per
Unit
wall. Metal can
totally block
signals.
3) Power up the master charging base, then install the supplied Mi-MH
AAA batteries into the handset as shown. For best battery life, it is advised
to charge for 12 hours before use.
Call Button
Optional keypad
module
ARCHITECTURAL
HOODED
MODEL
MODEL
5) Wiring
Mount AB model to
wall with 10mm x
50mm large wall
anchors to prevent
removal or theft.
Keep short as possible for best audio performance
Microphone
connections
IMPORTANT:
MIC
-
+
Observe polarity!
Tamper
INT Lock
N/C
Sense
(-)GND
DU out
N/O
K or A
OUT3
COM
N/C
+ -
OUT1 OUT2
Note: Keypad volt free output(s) needs connected to gate control panel or electric door
lock as well as relay output from the intercom controller PCB. Parallel connect C and N/O
contacts for electric gate controller or strike lock. Series connect C and N/C contacts for
magnetic lock.
Installation Manual
602AB, ABK, HB, HBK Wireless Intercom System
House or
300m
reception
MAX
area
Base Station
(Keep away from
For longer range
ground, as high as
applications, locate
possible)
charging base near a
window at front of property.
4) Remove the top two security
screws as shown. Do NOT remove
the bottom screws.
The front door will hinge downwards
to allow access for mounting holes
and connection terminals.
Note: The protective film on the front
of the intercom should not be removed
until fully installed.
Never drill holes in
the top of the
enclosure. Cable
entry should be
through the bottom.
8 meters max Shielded CAT5
Gate Base Station Connections
MIC
-
+
Shielded CAT5
Connect CAT5
screen wire to 0V
Mains input if
Do not use 12v d.c. here.
optional
For 12v d.c. connect to
transformer
PWR IN above. Switch
fitted.
for
Testing
When the door station is powered on, the door station will attempt to ring
the handset(s). Provided the handset(s) and charging base are both
already on, and within range, the handset(s) should ring.
Press the
two way speech. Press and HOLD the
gate release function.
Handset Coding
The supplied handsets will already be coded to work with the door
station. Should you have purchased an additional handset individually,
please follow this procedure...
1) To register a new or additional handset, first put the charging base into
learn mode. To do this, press and hold the
the charging base for 7 seconds or more, then release it..
2) On the new handset, press
3) Press
to select.
4) Press
and press
5) If the base is found, and the handset has successfully registered, you
will be prompted to enter a pin code. The default is 0000.
The base will now assign a number to the handset, and the handset will
return to normal operation mode.
Handset 3
Intercom
charger
Transmitter
Master Base is a REPEATER. Locate
602 Range
it in a strategic position.
Gate/Door Station Coding
The supplied gate/door station should already be coded with your master
PWR IN
base station. If for some reason the system does not work, or you
experience interference, it may be necessary to code the gate station.
1) On the master charging base station, press and hold
seconds (found underneath).
2) Switch on the power to the gate / door station, and it will begin
attempting to ring.
3) On the printed circuit board of the gate/door base station, you will find
a micro switch. Press and hold this button after the door station has made
12v ac or
2-3 ring tones.
24v ac
4) Continue holding the code button for at least 5-7 seconds. You should
IMPORTANT:
hear a short melody De-Du-Do. This is confirmation of success.
If the process is unsuccessful, it may be necessary to clear the
mode PSU not
previous coded door station (usually saved as HS2) from the master
recommended.
base (see section below), and then repeat the steps above.
Deleting a door station or handset
1) On a registered handset, press
options until you reach BS SETTINGS.
2) Press
to select.
3) Enter the PIN code 0000 and press
4) Select the device you wish to delete and press
button on a handset to answer the call, and check for
button to activate the door/
key.
or
repeatedly to choose REGISTER, then press
or
to scroll through the base name list (1-4).
to select base 1.
Handset 2
Handset 1
Charger
Base 1
MASTER
and then
to enter. You will see the option TERMINATE HS. Press
button on the bottom of
Gate/Door Station
Transmitter
Intercom
Transmitter
602 Range
Short cable
Intercom
Transmitter
602 Range
Short cable
button for 7
to scroll through
to delete.
