Installation Instructions
603 SPARTAN Intercom
PROFESSIONAL INSTALL ONLY
Do NOT give this manual to end user!
,
Models 603-IBK
AB, ABK, HB, HBK, FB, FBK, IMP, IMPK
The manufacturer cannot legally offer technical support to non-qualified gate
or door installers. End users should employ the services of a professional
install company to commission or support this product!
Tip: Site Survey BEFORE you begin. See Page 3!
P a g e
| 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 603 SPARTAN and is the answer not in the manual?

Questions and answers

Summary of Contents for AES 603 SPARTAN

  • Page 1 Installation Instructions 603 SPARTAN Intercom PROFESSIONAL INSTALL ONLY Do NOT give this manual to end user! Models 603-IBK AB, ABK, HB, HBK, FB, FBK, IMP, IMPK The manufacturer cannot legally offer technical support to non-qualified gate or door installers. End users should employ the services of a professional install company to commission or support this product! Tip: Site Survey BEFORE you begin.
  • Page 2: Table Of Contents

    Contents …………….Pg 3 Overview of System …………….Pg 3 Site Survey …………….Pg 3 Wall / Pillar Mounting …………….Pg 4 Gooseneck / Pedestal Mounting …………….Pg 5 Mounting Speech Panels …………….Pg 6 Wiring …………….Pg 7 Keypad Overview …………….Pg 7 Keypad Programming …………….Pg 9 Using the Keypad …………….Pg 9 The Handset...
  • Page 3: Site Survey

    Site Survey Before installing this system, you need to be sure that the range of the system will be sufficient. The transmitter and speech unit can be powered up, call button pressed, and then check that the handset will ring from all areas in which it will be used. Walls causing weak signal Up to 200m / yards Speech...
  • Page 4: Wall/Pillar Mounting

    Keypad Module in Detail Full / Auto (keypad illumination) Not used Relay 2 N/O and N/C Relay3 selection (100 codes) 24v dc Power (Pre-wired) Egress Wire N/O exit button to here & GND (-) Relay1 (1000 codes) Relay2 (100 codes) Wall/Pillar Mounting P a g e...
  • Page 5: Gooseneck / Pedestal Mounting

    Transmitter CAUTION! Competent person only! Speech point Intercom Screened CAT5 Transmitter 603 Range 24v dc PSU Keep high! Power cable (2x1mm / 16 gauge) Lightning prone areas must use 110v Surge protector and connect earth rod to internal 24v surge protector Gooseneck / Pedestal Mounting transmitter Intercom...
  • Page 6 Intercom Transmitter 24v dc PSU 603 Range Keep High! Power (2x1mm / 16 gauge) Lightning prone areas must use 110v Surge protector and connect earth rod to internal 24v surge protector Mounting Architectural Panels Loosen top 2 screws only Hinge front door Side View Mounting Hooded Panels Loosen top 2 screws only...
  • Page 7: Wiring

    Call Button Optional keypad module Remove Side View Flush with surface Tip: Use appropriate fixings to ensure the intercom cannot be removed from the wall. Pedestal Style Mounting 5/16 (M8) bolts Hinge Hinge front front door 3" hole 3" hole door centres centres...
  • Page 8: Keypad Overview

    Relay Connections Example Electric Gates Intercom board Keypad board Gate Controller Separate lock Magnetic Lock (Not supplied) Other control device Keypad overview This keypad has 3 outputs. The diagram below shows the LED indicators which indicate programming and relay status information. RED when incorrect codes entered and outputs are locked out.
  • Page 9 Quick start guide Tip: The engineer code 1) Enter programming mode (amber LED should be ON) must be the same length as user codes. So if using a 6 digit engineers code, then 2) Enter a new user code... user codes must also be 6 digits long etc.
  • Page 10: Using The Keypad

    0 = start / stop toggle mode (latching) 51=relay1 Validate 1-99999 = seconds momentary operation 52=relay2 53=relay3 Delete a user code even if you don’t know the code… 10=relay1 Delete code ID location to be deleted Validate 20=relay2 30=relay3 Delete an entire group of codes 10=relay1 group Super delete code Validate...
  • Page 11: The Handset

    Activate output 1 Activate output 2 Activate output 3 The Handset The handset should be charged for 8 hours before use. It is recommended to give it at least 1 hour charge before range testing. Ring Another Handset Change Ring Volume Battery Press and the unit will...
  • Page 12: 603 Audio Monitor Wiring & Mounting

    603 Audio Monitor Wiring and Mounting Re-coding Handset/Adding Extra Handset Occasionally a system may need re-coded once installed. If the handset does not ring when the call button is pressed, it may need re-coded. The procedure for doing this is the same as for adding an additional handset as follows…...
  • Page 13: Testing

    Testing Press the call button on the intercom and all coded handsets should ring (max 4 handsets). 12.21 12.21 12.21 12.21 Calling….. Answer the call on any handset by pressing and check for good 2 way speech. Adjust volume while on a call with up and down arrow buttons on the handset and press the same button again to end the call.
  • Page 14: Voicemail

    Voicemail To turn your voicemail ON, press and hold Relay 2 button for 3 seconds, scroll through the menu until you see ‘Re’. Press OK to select ‘Re’ and adjust your setting to ON or OFF. Press OK to select. Press the right arrow end the process. P a g e | 14...
  • Page 15: Troubleshooting Guide

    Troubleshooting guide Q. The unit will not ring the handset. A. Try re-coding the handset and transmitter as per instructions. - Check push button wiring to the transmitter with multi-meter. -Check power cable distance from power adaptor to transmitter is less than 4 metres. Q.
  • Page 16 Regulatory Compliance FCC Id: 2ALPX-603TX and 2ALPX-603EH Grantee: Advanced Electronic Solutions Global Ltd This device complies with Part 15D of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 17 The manufacturer cannot legally offer technical support to non-qualified gate or door installers. End users should employ the services of a professional install company to commission or support this product! P a g e | 17...
