Summary of Contents for AES 705
- Page 1 Installation & User Manual 6 0 5 / 7 0 5 D E C T + 2 . 4 G I n t e r c o m W ireless Video Inter com System Models 605AB, 605ABK,705ABK,705AB P a g e...
- Page 2 Contents …………….Pg 3 Overview of system …………….Pg 3 Site Survey …………….Pg 3 605/705 Installs …………….Pg 3 Installations …………….Pg 4 Mounting Panels ….………….Pg5 Power Supply ….………….Pg5 Doorstation Wiring Diagram 705 Monitor .…………….Pg7 605 Handset ...………….Pg7 …………….Pg8 Answering Calls …………….Pg8 Setting …………….Pg 9 Optional Audio Handset/Monitor .………….Pg 9...
-
Page 3: Overview Of System
705 Monitors Installations Intercom Antenna Tip: The 705 monitor has a built-in antenna/receiver, it is best to use this for short range installs. (see diag.1) For longer range installs, fit an external antenna (see below, check local radio authority). External antenna... -
Page 4: Installation
Installation Assuming satisfactory operation at full range, you are ready to fully install the product. Mount the intercom at the desired height for pedestrian or car users. The camera angle is wide at 90 degrees to cover most scenarios. Loosen top 2 screws only Hinge front door Side View Tip: Do not drill holes in the wall with the intercom in position, otherwise dust may get... -
Page 5: Power Supply
Power Supply TIP: Most technical calls received are due to installers using CAT5 or alarm cable to power the unit. Neither are rated to carry enough power (1.5 amp peak). Please use following cable sizes… Up to 2 metres (6 feet) – Use minimum 0.75mm (18 gauge) Up to 4 metres (12 feet) –... - Page 6 705 Video Monitor Wiring and Mounting 705 Video Monitor Adjust speaker ringtone volume Answer Monitoring Gate/Door Trigger Microphone The Video Handset Microphone The Video handset should be charged Gate/Door for 8 hours before Trigger use. It is recommended to Monitoring...
-
Page 7: Answering Calls
Answering Calls 1. When the intercom calls, identify the visitor on the screen. 2. Press the OK button to answer the call. 3. Speak clearly into the top of the handset at a distance of 10-20cm. 4. During the call press < or > to increase or decrease volume. 5. -
Page 8: Adjusting The Time
Voicemail When a call is not answered within 40 seconds, the visitor can leave a message. Once complete, the handset will display the symbol. The unit can store up to 16 messages. To listen to voicemail, press MENU to play. If there are more than 1 message, press to select the message required and press MENU to play. -
Page 9: Wiring Tips
Re-coding the Handsets / Adding an Extra Handset Occasionally a system may need re-coded when it arrives on site. If the handset does not ring when the call button is pressed, please perform the following steps.. 1. Press and hold the code button on the speech panel as shown for 3 seconds. 2. -
Page 10: Keypad Overview
Note: The manufacturer can only support the use, operation and functionality of the intercom and keypad themselves. Professional wiring to door release or automatic gate systems is the responsibility of the installer. Please consult a security integrator for further support. Keypad overview This keypad has 3 outputs. -
Page 11: Full Keypad Programming
Full Keypad programming Enter programming mode.. The unit is now in programming mode. Amber LED on the keypad should remain permanently on. 0000 is the default programming passcode. Exit programming mode.. The unit should exit programming mode and the amber LED should start flashing again. -
Page 12: Using The Keypad
Delete an entire group of codes 10=relay1 group Super delete code Validate 20=relay2 group 30=relay3 group Programming super user codes… A super user code can activate any of the 3 relays Location 4-8 digit code Validate Restoring defaults When in programming mode, you can enter the following sequence… When the master code is forgotten…. - Page 13 Advanced Keypad Connections Tamper INT Lock Advanced connections INT Lock – Used to operate a door in conjunction with O/P1 inhib Sense OUT2 another keypad. 24v dc max voltage, 100mA sink. Relay (-)GND O/P1 inhib – When closed, this disables all codes for relay Select DU out group 1.
-
Page 14: Troubleshooting Guide
Maintenance of the Intercom The stainless steel can dull or discolour over time in weather conditions or in winter if exposed to road salt. This can be polished with a suitable stainless steel cleaner or re-brushed with an abrasive pad or sand paper, observing the directionality of the grain.. Take care when cleaning the acrylic face. - Page 15 Q. The unit will not power up / there is a short circuit on the power supply A. This can be caused by the inbuilt surge protection being short circuited due to a surge, over voltage, or wiring fault. Disconnect all wiring, check, and re-wire again. If the fault still appears, contact your dealer for service.
- Page 16 EU-RED Declaration of Conformity Manufacturer: Advanced Electronic Solutions Global Ltd Address: Unit 4C, Kilcronagh Business Park, Cookstown, Co Tyrone, BT809HJ, United Kingdom We/I declare, that the following equipment (DECT & 2.4G intercom, handset, charging base and intercom door station), part numbers: Multiple Model kit part numbers: 605-AB, 605-ABK, 605-BE, 605-BEK, 605-BFT, 605-BFTK, 605-IMP, 605-IMPK,605-EDG, 605- EDGK, 605-EH.
