PANEL LAYOUT

2
1
34
33
32
31 30 29
1
FRONT PANEL
1
MASTER VOLUME
and the headphones output.
2 [SONG MODE] activates/deactivates SONG mode.
3 [CHAIN MODE] activates/deactivates CHAIN mode.
4
sets the overall volume level of the active track.
LEVEL
Also used for scrolling in menus and setting various
parameter values.
5 [TEMPO] opens the TEMPO menu. [FUNCTION] + [TEMPO]
makes it possible to tap the tempo.
6 [YES/SAVE] key. Used for entering sub-menus and for
confirming choices.
7 [NO/RELOAD] key. Used for exiting an active menu
and backing one step.
4
3 4 5 6 7
28 27 26 25
2 3
sets the volume for the main outputs
8 9 10 11
24 23 22
4 5 6
8 The LCD screen.
9 The [ARROW] keys. Used for menu navigation. They
are called [UP], [DOWN], [LEFT] and [RIGHT].
10 [PERFORMANCE] activate PERFORMANCE mode. A sec-
ond press on the key opens the track mixer.
11 [ARP] key. Controls for the arpeggiator of the active
track are found here.
12 [NOTE] key. Note settings for the active track are
made here.
13 [PARAMETER] keys switch between the PARAMETER
pages of the active track. The upper white text leg-
end indicates the pages for the four synth tracks. The
gray text is for the FX track pages and the white text
line beneath indicates the CV track pages. A second
12 13 14
21
7 8 9 10
15 16
17
18
19
20
11
